DIMENSIONS
96"
TOP VIEW
MATERIALS LIST
Pressure
Treated
4x4, 10 ft.
• 1 post
51"
LONG SIDE VIEW
Pressure
3/8" Lag Bolt,
Treated
3-1/2" long
• 40 bolts
2x6, 8 ft.
• 6 boards
GARDEN BOX
11"
20"
3/8" Flat Washer
End Cut Wood
• 40 washers
Preservative
• 1 can
home.crs
SHORT SIDE VIEWS
Heavy Duty Plastic
Sheeting
• 25 sq.ft.
3/8" Staples
• 150 staples
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Co-op Garden Box
Summary of Contents for Co-op Garden Box
- Page 1 GARDEN BOX home.crs DIMENSIONS 11" 51" 20" 96” TOP VIEW LONG SIDE VIEW SHORT SIDE VIEWS MATERIALS LIST Heavy Duty Plastic Sheeting • 25 sq.ft. Pressure Pressure 3/8" Lag Bolt, 3/8" Flat Washer End Cut Wood • 40 washers Treated Treated 3-1/2"...
- Page 2 GARDEN BOX CONSTRUCTION • The dimensions of this raised Garden Box can be altered to suit the user's preferences. • The assembly sequence will work as long as all side and end boards are uniform in length. • This design has extended posts to anchor the box and keep the side walls from bowing outward.
- Page 3 GARDEN BOX ASSEMBLY STEP 1. SIDE ASSEMBLY STEP 2. END ASSEMBLY NOTE: Lag bolts require the drilling of clearance and pilot holes prior to installation. 1½” Overhang on both ends 46½” 3/8" x 3½” Lag Bolts - 16 3½” Lag Bolts - 24 3/8"...
- Page 4 Please ensure the manufacturer's instructions are followed in the ® use of all tools and materials and heed all recommended safety guidelines. ®CO-OP and design trademark are registered trademarks of Federated Co-operatives Limited, Saskatoon S7K 3M9...
