BA-Nr.: 02.05.126/2021-09-A01
Figure similar
Read this User Manual
user as well as for future use and subsequent sales.
User Manual

Walking frames

Jumbo-Yano
188.99.00
150 kg
before using the device for the first time
REBOTEC
®
Rehabilitationsmittel GmbH
DE-49610 Quakenbrück, Artlandstr. 57- 59
Telephone: +49 (0) 5431/9416-
Fax: +49 (0) 5431/9416- 66
Web:
www.rebotec.de
Email:
info@rebotec.de
and keep it at hand for the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 188.99.00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rebotec 188.99.00

Summary of Contents for Rebotec 188.99.00

  • Page 1: Walking Frames

    BA-Nr.: 02.05.126/2021-09-A01 Email: info@rebotec.de User Manual Walking frames Jumbo-Yano 188.99.00 150 kg Figure similar Read this User Manual before using the device for the first time and keep it at hand for the user as well as for future use and subsequent sales.
