Chamberlain 050ACTWFATS Installation Manual

Installation
1
Before you begin
Your new myQ serial number is located on the replacement label with your replacement logic board. You will need this new myQ
®
have a STEP SAVER SETUP label that must be adhered to your end panel directly under the yellow LEARN button for future identification. This second label indicates your board has been updated, and a
new Product Label should be placed over the current Product Label. Your product may look different.
To prevent possible SERIOUS INJURY or
DEATH:
• Disconnect ALL electric and battery
power BEFORE performing ANY service
or maintenance.
To prevent damage to the receiver/logic
board, DO NOT touch printed circuit board
of replacement receiver/logic board during
installation.
ALWAYS wear protective gloves and eye
protection when changing the battery or
working around the battery compartment.
2
Remove the receiver logic board
2.1 Disconnect the wires from the quick-connect terminals (A).
Remove the receiver logic board end panel from the door
operator.
A
To insert or
remove the wires
from the terminal,
push in the tab with
a screwdriver tip.
1.1 Remove the light lens by pulling the
top sides of the light lens and rotate the
light lens down. Squeeze the light lens
clips to remove lens from end panel.
WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer or birth
defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
2.2 Unplug the wire harnesses from the receiver logic
board. You may need needle-nosed pliers to remove
the harnesses.
RECEIVER LOGIC BOARD REPLACEMENT
serial number to connect your operator to the network. You will also
®
1.2 To maintain your warranty, place the
provided label over the existing label
on the end panel of the door operator.
Place the STEP SAVER SETUP label on
the end panel directly below the yellow
LEARN button.
TO ERASE ALL ELIMINACIÓN DE
RECEIVER CODES TODOS LOS CÓDIGOS DEL
1. Press and HOLD RECEPTOR
receiver orange
1. MANTENGA PRESIONADO
ERASE button
el botón naranja "ERASE"
6 seconds. Indicator del receptor durante 6
light will turn ON. segundos. La luz del
indicador se encenderá.
2. Release button
when light turns OFF . 2. Suelte el botón cuando la
luz se apague.
PART NO.: NO. DE PIEZA:
CANADA: DATE:
DANGER PELIGRO
THE CHAMBERLAIN
GROUP, INC., USA
Ensamblado en México
RECEIVER CODES TO ERASE ALL TODOS LOS CÓDIGOS DEL ELIMINACIÓN DE
1. Press and HOLD receiver orange RECEPTOR Assembled in Mexico
ERASE button 1. MANTENGA PRESIONADO el botón naranja "ERASE"
light will turn ON. 6 seconds. Indicator del receptor durante 6 segundos. La luz del
2. Release button indicador se encenderá.
when light turns OFF . 2. Suelte el botón cuando la luz se apague. 132C2280-3D
PART NO.: NO. DE PIEZA:
CANADA: DATE:
DANGER PELIGRO
THE CHAMBERLAIN
GROUP, INC., USA Ensamblado en México
Assembled in Mexico
132C2280-3D
2.3 Remove the receiver
logic board from the
end panel by removing
the 2 screws and
releasing the 2 clips.
1
Model 050ACTWFATS
1.3 Disconnect power to the door operator.
Wire clip
Screws
Clips
