Acrel ARD2F Operating Manual

Intelligent motor protector
Hide thumbs Also See for ARD2F:

Advertisement

Quick Links

Download this manual
444
444
444
444
ARD2F
Intelligent motor Protector
V1.1
Operating Manual
ACREL Co., Ltd

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARD2F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acrel ARD2F

Summary of Contents for Acrel ARD2F

  • Page 1 ARD2F Intelligent motor Protector V1.1 Operating Manual ACREL Co., Ltd...
  • Page 2 Declaration All rights reserved. Without the written permission of the Company, the contents of any paragraph or section in this manual shall not be copied, copied or disseminated in any form. Otherwise, all consequences shall be borne by the violator. Our company reserves all legal rights.
  • Page 3 Catalog 1、Overview....................1 2、Product Features..................1 3、Model Description................1 4、Main parameters..................3 5、Overall dimensions and installation............5 6、Protection function description............11 7、Function setting and description............26 8、Communication Settings and instructions.......... 45 9、Typical applications................83 10、Features and Functions..............87 11、Examples of ordering................ 89...
  • Page 4 Overview Overview Overview The ARD2F intelligent motor protector (hereinafter referred to as the protector) is suitable for low-voltage motor circuits with rated voltage up to 660V and integrates protection, measurement, control, communication, operation and maintenance.Its perfect protection function ensures the safe operation of the motor, with logic programmable function, can meet a variety of control methods.
  • Page 5 Additional functions (Table 2) Current Specification (Table 1) Split Design serial number Enterprise code The corresponding relation between ARD2F current specification and the rated current and power of the applicable motor is shown in Table 1: Table 1 Protector current Ratio...

  • Page 6: Technical Indicators

    2m±10cm. If other lengths are needed, please contact the manufacturer. 4 4 4 4 M M M M ain parameters parameters ain parameters parameters 4.1 Technical indicators ARD2F technical indicators are shown in Table 4: Table 4 Technical parameters Technical indicators Protector auxiliary AC85-265V/DC100-350V...
  • Page 7 Main body IP20, split display module IP54 (installed on the cabinet Protection grade panel) Installation category Level III 4.2 Functional configuration The ARD2F functional configuration is shown in Table 5 Table 5 Type Functional configuration Function Standard function Optional function Fixed time overload √...
  • Page 8 5 5 5 5 Overall Overall dimensions installation Overall Overall dimensions dimensions dimensions and and installation installation installation 5.1The product composition of ARD2F is shown in Figure 1, Figure 2 FIG. 1 Composition of products with 100A and below specifications...
  • Page 9 Back view Hole size Fig.3 The shape and hole size of 90L display unit 5.3 Size of main body module (unit: mm) The ARD2F main body is installed with 35mm guide rail, and its external dimensions are shown in Figure 4:...
  • Page 10 Front view Side view Fig.4 ARD2F main body dimensions 5.4 The external dimensions of current transformers of 100A and the following specifications are shown in FIG. 5 (unit: mm) :： 5.4.1 The current transformer with the current specification of the protector is 100A, with the standard secondary connection line length of 1m±10cm.
  • Page 11 Fig. 6 External dimensions of current transformer 250A 5.4.3 The external dimensions of the current transformer (800A) are shown in FIG. 7 (unit: mm) : The current specification of the protector is 800A and the current transformer is not equipped with secondary connection.
  • Page 12 Table 6 Dimmen Overall Go through Installation sion Tolerance size(mm) size(mm) size(mm) Weight （g） (mm) Φ Φ2 Spec. L-45 200±10 L-80 ±1 380±20 L-150 850±50 5.5 Terminal The wiring terminal arrangement of the ARD2F main body is shown in Figure 9:...
  • Page 13 Fig. 9 ARD2F terminal arrangement See Table 7 for the ARD2F terminal number and function definition: Table 7 Terminals Function definition Remark Power input L (+ at DC time) The auxiliary power supply is connected to the two terminals Power input N (- at DC time)
  • Page 14 First channel MODBUS communication Second channel MODBUS communication T1（PTC input A） Temperature protection (thermistor T2（PTC input B） input) Leakage current measurement COM3(common terminal of current、leakage current input ) Ia Phase current input Three phase current input Ib Phase current input Ic Phase current input 6 6 6 6 Protection Protection...
  • Page 15 Table 9 Optional tripping curve grade K Tripping delay （S）tolerance Three - phase balanced load, starting from the cold state ±10% Rated value 1000 Ie×1.2 ×1.5 ×2 ×3 ×4 2.26 4.52 6.78 11.3 22.5 33.8 56.3 67.5 78.8 ×5 1.44 2.88 4.32 14.4...
  • Page 16 Note： Imax：Maximum three-phase current Is：Overload starting fixed value Heat：Percentage heat capacity Hs：Heat capacity alarm value TS：Starting shield time tE Time protection For the increased safety type motor, after the ac winding reaches the rated operating stable temperature at the highest ambient temperature, the time required from the beginning of passing through the blocking current until it rises to the limit temperature is tE time.The tE time of the increased safety motor is usually provided by the motor manufacturer, and the user can find this data on the motor nameplate.
  • Page 17 Fig.11 tE Protection delay to blocking current ratio IA/Ie Current-time characteristic curve Instructions:tEp：7 times of the rated current allowed lock-in time;IA：Locked-rotor current; Ie：Rated current of the motor. Table10 2（S） 3（S） 4（S） 5（S） 6（S） 8（S） 10 （S） 12（S） 15（S） IA/Ie 20.27 30.4 40.54 50.67...
  • Page 18 about 15%. （ ）The action time of tE protection is achieved by setting "motor type" and "trip level", and the corresponding trip curve is selected by setting tEp (trip level) according to Table 9.(When the motor type is selected as "increased security motor", the tripping level will automatically change to tEp setting;Otherwise, the trip curve is the reverse time-limit overload trip curve of ordinary motor.
  • Page 19 6.3 Locked-rotor protection In the process of starting, if the motor shaft is stuck due to excessive load or mechanical reasons, and the fault is not removed in time, the motor will overheat and the insulation will be reduced and the motor will be burned out.The locked-rotor protection is applicable to the motor when such faults occur in the starting stage.
  • Page 20 Note： Iav：Three-phase mean current Is1：Alarm action threshold Is2：Tripping threshold Ts：Alarm action delay time 6.5 Underload protection The protector provides underload protection when the motor is loaded with pumping load. When the average three-phase current is lower than the set value, the protector should trip or alarm within the set time.
  • Page 21 Note: P: Total active power Ps1: Alarm action threshold Ps2: Trip action threshold Ts1: Delay time of alarm action Ts2: Delay time of trip action 6.7 Overload protection In addition to reverse Overload protection, the protector can also provide time-limit overload protection.
  • Page 22 Note: P: Total active power Ps1: Alarm action threshold Ps2: Trip action threshold Ts1: Delay time of alarm action Ts2: Delay time of trip action 6.9 Ground fault protection The protector is protected by the ground current according to the three-phase current vector and the calculation of the ground current.The grounding protection can set the starting shielding time.
  • Page 23 Note: IL: Leakage current Is1: Alarm action threshold Is2: Tripping threshold Ts1: Shield time for leakage starting Ts2: Delay time of alarm action Ts3: Delay time of trip action 6.11 I unbalance protection The protector calculates the current imbalance degree. When the three-phase current imbalance degree is greater than the set value, it will trip or alarm within the set time.The calculation formula of current imbalance degree is as follows: Imax(min)
  • Page 24 Uuf is the voltage imbalance, Umax is the maximum line voltage, Umin is the minimum line voltage, and Uav is the average line voltage. Note: Uuf: Voltage imbalance degree Us1: Alarm action threshold Us2: Trip action threshold Ts1: Delay time of alarm action Ts2: Delay time of trip action 6.13 Phase fail protection When the phase fault runs, it will do great harm to the motor.
  • Page 25 Ts1: Delay time of alarm action Ts2: Delay time of trip action 6.14 Phase sequence protection When the error of three-phase voltage phase sequence is detected, the protector will trip or alarm within the set time to protect the safety of the motor. Note: Angle: The Angle between any two - phase voltage Ts1: Delay time of alarm action...
  • Page 26 6.16 Undervoltage protection Too low voltage will cause the motor to slow down, or even stop running.When the minimum line voltage of the motor is lower than the set value, the protector will trip or alarm within the set time. Note: Umin: Minimum line voltage Us1: Alarm action threshold...
  • Page 27 Is4: Threshold of short-circuit trip during operation Ts1: Delay time of alarm action Ts2: Delay time of trip action 6.18 Temperature protection Temperature protection is based on the thermistor resistance embedded in the stator windings or bearings of the motor.According to the type of thermistor selected, the protection logic is different: when the thermistor is PTC, when the detected resistance value is greater than the set value, the protector will trip or alarm within the set time;When the thermistor is NTC, when the detected resistance value is less than the set value, the protector will trip or alarm within the set time...
  • Page 28 Note: Ts1: Delay time of alarm action Ts2: Delay time of trip action 6.20 Overflow protection When the fault occurs, the current exceeds the breaking current of the contactor, and the contactor will be damaged if the contactor is forcibly disconnected.At this point, the breaker should be broken first, and then disconnect the contactor after the fault current is removed.
  • Page 29 Example: Set the time limit of 1 hour to allow 3 starts. Figure above: It has been started for 3 times between 13:00 and 14:00, and there is no number of starts at the fourth time, so the fourth time fails. Figure below: Before the fourth start, the remaining number of starts is restored to 1, so the fourth start is successful.
  • Page 30 Reset button press Use in fault state and restore the fault 7.2 The 90L display module button and LED indicator light are shown in Table 12: Table 12 Serial Name State Function Description Manual mode, two-part mode, two-speed mode, star Start 1 button press triangle operation start 1 relay...
  • Page 31 0.000kW 0.000kvar 0.0 A 0.0V 0.000kVA 0.0 A 0.0V 1.000 0.0A 0.0V 0 %Ie 0.0V Start mode manual Permission 2020-xx-xx xx:xx:xx DI status DO status 0.00Hz 65535Ω N: O N: O Heat Cap Fig.12 90L display unit data display interface 7.3.2 Parameter viewing and setting When you need to view or set a parameter, first press "OK"...
  • Page 32 Premission Start mode Self start Restart Permission Permission Comm Fig.13 Shows the operation diagram of Ethernet communication parameters 7.4 Menu description See Table 13 for the ARD2F menu: Table 13 Seria Main Default Function Type Setting Range Unit l No.
  • Page 33 Total stop time —— —— —— Start qty —— —— —— Trip qty —— —— —— Maximum start —— —— —— current Maximum —— —— —— running current 0.1~5000 0.1~5000 6.3~25 Rated current —— 25-100 63~250 250~800 Rated voltage —— 57-1200V Rated power ——...
  • Page 34 Ubc、 Uca、 Uav、 PTC、 Heat capacity、P、F 2 times Full value 1 rated current a、Ib、Ic、Iav、Uab、 Type 2 Ubc、 Uca、 Uav、 PTC、 Heat capacity、P、F 2 times Full value 2 rated current Language —— Chinese, English Chinese selection 1-30s，0 is normally backlight —— Liquid crystal ——...
  • Page 35 Start setting 100~800% Reset method Off/on Cooling time 0-30min 1min Alarm threshold 1-99% Start: Allow allowed/forbidden Run: Action stage Allow allowed/forbidden Stop:allowed/forbidde Forbidden Starting screen 0-25.0s 0.5s time Alarm:allowed/forbid Allow Alarm, trip allowed Trip:allowed/forbidde Allow Alarm delay 0.1-600.0s 1.0s Trip delay 0.1-600.0s 5.0s Alarm threshold...
  • Page 36 Alarm:allowed/forbid Allow Alarm, trip allowed Trip:allowed/forbidde Allow Tripping delay 0.1~600 Alarm on/off Tripping on/off Alarm threshold 10~80% Alarm threshold 10~80% Tripping delay 0.1~600 Current Start: Forbidden imbalance allowed/forbidden Run: Action stage Allow allowed/forbidden Stop: Forbidden Allowed/forbidden Alarm on/off Tripping on/off Alarm delay 0.1-600.0s 0.1s...
  • Page 37 allowed/forbidden Stop: Forbidden Allowed/forbidden Trip mode: circuit circuit breaker/contactor breaker Return coefficient Starting screen 0.0-600s time Alarm:allowed/forbid Allow Alarm,Tripping allowed Trip:allowed/forbidde Allow Alarm delay 0.1-600.0s 0.1s Tripping delay 0.1-600.0s 0.5s Alarm threshold 100-1000mA 200mA Trip Threshold 100-1000mA 300mA Start: Allow allowed/forbidden Run: Allow...
  • Page 38 Run trip 500% Start: Allow allowed/forbidden Run: Action stage Allow allowed/forbidden Stop: Forbidden allowed/forbidden Return coefficient Alarm:allowed/forbid Allow Alarm,Tripping allowed Trip: Allow allowed/forbidden Protec threshold 100~700% Alarm:allowed/forbid Overflow Allow Alarm, trip protection allowed Trip: Allow allowed/forbidden Alarm delay 0.1-600.0s 0.1s Tripping delay 0.1-600.0s 5.0s...
  • Page 39 quantity Time range 10-300min 30min Alarm:allowed/forbid Allow Alarm, trip allowed Trip: Allow allowed/forbidden Alarm delay 0.1-600.0s 0.1s Tripping delay 0.1-600.0s 5.0s Alarm threshold 110-150% 110% Trip Threshold 110-150% 120% Start: Allow allowed/forbidden Run: Action stage Allow allowed/forbidden overvoltage Stop: Allow allowed/forbidden Return coefficient...
  • Page 40 Start: Allow allowed/forbidden Run: Action stage Allow allowed/forbidden Stop: Allow allowed/forbidden Return coefficient Alarm:allowed/forbid Forbidden Alarm, trip allowed Trip: Forbidden allowed/forbidden Alarm delay 0.1-25.0s 0.1s Tripping delay 0.1-25.0s 1.0s ° Alarm threshold 0.5-5.0° 5.0° ° Trip Threshold 0.5-5.0° 9.9° Start: Allow allowed/forbidden Run:...
  • Page 41 allowed/forbidden Alarm delay 0.1-600.0s 0.1s Tripping delay 0.1-600.0s 5.0s Alarm threshold 0-100% Trip Threshold 0-100% Start: Allow allowed/forbidden Run: Action stage Allow allowed/forbidden under-power Stop: Forbidden allowed/forbidden Return coefficient Alarm:allowed/forbid Forbidden Alarm, trip allowed Trip: Forbidden allowed/forbidden NTC/PTC NTC/PTC Alarm delay 0.1-600.0s 0.1s Tripping delay...
  • Page 42 allowed/forbidden Alarm:allowed/forbid Forbidden Alarm, trip allowed Trip: Forbidden allowed/forbidden Alarm time 0.1-600.0s 0.1s delay Tripping delay 0.1-600.0s 5.0s Start: Forbidden allowed/forbidden Run: Action stage Forbidden Insulation fault allowed/forbidden Stop: Allow allowed/forbidden Alarm:allowed/forbid Forbidden Alarm, trip allowed Trip: Forbidden allowed/forbidden Alarm threshold 10000h Start: Allow...
  • Page 43 Alarm on/off Tripping on/off PTC type on/off Return 0（Shut down）、 Ω resistanse value 100-30000 Alarm 100~30000 1600 Ω resistance value Temperature Tripping protection 100~30000 3600 Ω resistance value Tripping delay 0.1~600 Alarm on/off Tripping on/off Tripping delay 0.1~600 External fault Alarm on/off Tripping...
  • Page 44 Restart delay 1.0-60.0s 30.0 Immediate 0.1-10.0s restart time Restart function on/off Normally Normally DI1 type on/normally off 1-Ordinary DI, 2-starting 1(in situ), 3-starting 1(remote), 4-starting 2(in situ), 5-starting 2(remote), 6-parking (in situ), 7-parking (remote), 8-reset, 9-emergency stop, 10-external fault, 11-single point 1 (in situ) start-stop, Stop 12-single point 1...
  • Page 45 0-No input, 1-star 1, 2-start 2,3-start3, 4-parking,5-starting jumped contactor,6-circuit breakers,7-fault Alarm output,8-tripping fault output,9-the output state DO setting stopped,10-the starting state output,11-the output operation state,12-the communication control output,13-the output device DO1 Definition self-checking,14-the start1 device output power,15-nowhere electric process output chain,16-electric reset signal output,17-protected...
  • Page 46 Ditto trip Close;DI1-19;DO1 - DO6;Starting 1;Starting 2;Starting 3;Stop,Emergency shutdown;Stop state;Starting Input A state;Running definition state;Alarm status;Trip status;Trip type (choose one of 22 fault types);Alarm types (choose one of 24 Alarm types)） Input A Positive Positive logic logic/Reserve logic logic Input A 0.0-60.0s 0.0s delay...
  • Page 47 Off、 A、 A*B、 A+B、 A*B*C、(A+B)*C、 (A*B)+C、A+B+C、 A*B*C*D、 (A+B)*C*D、 (A*B+C)*D、 (A+B+C)*D、 A*B*C+D、 (A+B)*C+D、 A*B+C+D、 A+B+C+D、 A*B*C*D*E、 (A+B)*C*D*E、 Logic diagram1 (A*B+C)*D*E、 (A+B+C)*D*E、 (A*B*C+D)*E、 ((A+B)*C+D)*E、 (A*B+C+D)*E、 (A+B+C+D)*E、 A*B*C*D+E、 (A+B)*C*D+E、 (A*B+C)*D+E、 (A+B+C)*D+E、 A*B*C+D+E、 (A+B)*C+D+E、 A*B+C+D+E、 A+B+C+D+E Logic diagram 2 Ditto Logic diagram 3 Ditto Off/on Off/on Off/on...
  • Page 48 Each byte bit: 1 bit start, 8 bit data (least significant bit sent first), no parity, 1 bit stop MODBUS function code supported by ARD2F: 01 (0x01) Function code: Read coil state (relay output DO, address 0 corresponds to DO1)
  • Page 49 Example 3: Register read using the 03 or 04 function: read 01 ARD2F and read 3 data from address 00 Check data frame 01 03 00 00 00 03 11 5D Return data 01 03 06 00 00 00 00 00 00 OE D1...
  • Page 50 L3 Phase current (full word scaling factor is the actual 0x02 wave/fundamental value word wave) leakage current 0-3000mA 0x03 word Ground current percent 0-100% Uab Line voltage (full 0x04 wave/fundamental 0~1999.9 word wave) Ubc Line voltage (full 0x05 wave/fundamental 0~1999.9 word wave) Uca Line voltage (full...
  • Page 51 Bit0 reverse time overload trip Bit1 ground trip Bit2 underload trip Bit3 phase break trip Bit4 underpressure trip Bit5 overpressure trip Bit6 blocking trip 0x14 Trip fault indication 1 Bit7 blocking trip word Bit8 unbalanced trip Bit9PTC temperature trip Bit10 external fault trip Bit11 start timeout trip Bit12 overpower trip Bit13 underpower trip...
  • Page 52 indication 2 alarm Bit1 voltage imbalance alarm Bit2 overflow alarm Bit3 insulation monitoring alarm Start times of Bit4 alarm Bit5 running time alarm Bit6 failure times alarm Bit7 leakage current alarm 0-1.6、1-6.3、2-25、3-100、 Current specification 4-250、5-800、6-1、7-5 0x18 word Current scaling factor 1、10、100 Phase overload...
  • Page 53 0x31 Month 1-12 word 0x32 1-31 0x33 Hour 0-23 word 0x34 0-59 word 0x35 Second 0-59 word 0x36-0x 54-93 Reserve word 0-Ia、1-Ib、2-Ic、3-Iav、 4-Uab 、 5-Ubc 、 6-Uca 、 Variable feed type 0x5E word 7-Uav 、 8-PTC 、 9-Heat setting capacity、10-P、11-F Mark the input of the 0x5F residual...
  • Page 54 Bit0 reverse time limit overload tripping; Bit1 grounding tripping; Bit2 underload tripping Bit3 disconnection; Bit4 underpressure release; Bit5 overpressure release; Bit6 blocking and tripping; Bit7 blocking tripping; Bit8 current imbalance Trip Breakdown fault tripping; 0x6D word indication 1 Bit9 PTC temperature tripping;...
  • Page 55 Bit11 start timeout alarm; Bit12 power alarm; Bit13 underpower alarm; Bit14 phase sequence alarm; Bit15 short circuit alarm. (0- No alarm, 1- Alarm) Bit0 fixed time limit overload alarm; Bit1 voltage imbalance alarm; 0x71 Alarm fault indication 2 Bit2 overflow protection word alarm;...
  • Page 56 0x87 Temperature trip delay 0.1~600 word Temperature return 0x88 0Off,100~30000 word resistance Under voltage alarm 0x89 50~90% word threshold Under voltage trip 0x8A 50~90% word threshold 0x8B Under voltage trip delay 0.1~600 word Over voltage alarm 0x8C 110~150% word threshold Over voltage trip 0x8D 110~150%...
  • Page 57 bits First channel 0-38400,1-19200,2-9600,3- 0xAA communication baud word 4800,4-2400,5-1200 rate First channel 0xAB 1-247 word communication address 0xAC reserve word First channel 0-No check，1-2stop bit， 0xAD communication parity word 3-Odd，4-Even bits 0-38400,1-19200,2-9600,3- First channel 0xAE communication baud 4800,4-2400,5-1200， word rate 6-Profibus First channel 0xAF...
  • Page 58 output,9-the output state stopped,10-the starting state output,11-the output operation state,12-the communication control output,13-the output device self-checking,14-the device output power,15-nowhere electric process output chain,16-electric reset signal output,17-protected mode have nowhere electricity output 1,18-protected mode electricity output 2,19-logic diagram output 1,20-logic diagram output 2, 21-logic diagram output 3, 22-30 corresponding DI1-9 control the DO output...
  • Page 59 4-parking,5-starting jumped contactor,6-circuit breakers,7-fault Alarm output,8-tripping fault output,9-the output state stopped,10-the starting state output,11-the output operation state,12-the communication control output,13-the output device self-checking,14-the device output power,15-nowhere electric process output chain,16-electric reset signal output,17-protected mode have nowhere electricity output 1,18-protected mode electricity output 2,19-logic diagram output 1,20-logic diagram output 2, 21-logic...
  • Page 60 DI8 programmable 0xD4 ditto word setting DI9 programmable 0xD5 ditto word setting 0xD6-0 214-399 reserve word x18F Table 15 Read Address Address Parameter write Value range Type attr. A Phase effective value 07D0 word current percentage B Phase effective value 07D1 word current percentage...
  • Page 61 Ubc Fundamental line 07E1 0～1999.9V word voltage Uca Fundamental line 07E2 0～1999.9V voltage 07E3 leakage current 30-3000mA Phase effective 07E4 word current Phase effective 0-65535/current scaling 07E5 word current factor is the actual value Phase effective 07E6 word current 07E7 Uab RMS line voltage 0～1999.9V word...
  • Page 62 byte word high 32 bit signed number, 07FE byte High byte before, low byte word fundamental wave Total after reactive power Unit：var 07FF byte word high 32 bit unsigned number, 0800 byte High byte before, low byte word fundamental wave Total after apparent power Unit：VA...
  • Page 63 high 32 bit signed number, 080C byte High byte before, low byte Fundamental wave A word after phase reactive Unit：var 080D byte word high 32 bit signed number, 080E byte High byte before, low byte word Fundamental wave B after phase reactive Unit：var 080F...
  • Page 64 reactive power after word Unit：VA 081B byte word high 32 bit signed number, 081C byte High byte before, low byte Total fundamental word after wave apparent power Unit：VA 081D byte word high 32 bit unsigned number, 081E byte High byte before, low byte word Fundamental wave total after...
  • Page 65 byte word high 082A byte 32 bit unsigned number, Full wave B phase High byte before, low byte word reactive after 082B Unit：var byte word high 082C 32 bit unsigned number, byte word Full wave C phase High byte before, low byte reactive after Unit：var...
  • Page 66 High byte:00-99,low 083C Year,month word byte:0-12 High byte:0-31, low 083D Day,hour word byte:0-23 High byte:0-59, low 083E Minute,second word byte:0-59 083F 507-549 reserve -0843 Motor running time by 08FC 0-65535 h word Total motor stopping 08FD 0-65535 h word times 08FE Total running times 0-65535 h...
  • Page 67 Bit13 underpower tripping; Bit14 phase sequence tripping; Bit15 short circuit tripping. (0- No tripping, (1) Bit0 fixed time limit overload tripping; Bit1 voltage unbalanced Trip Breakdown fault 0907 tripping; word indication 2 Bit2 overflow protection tripping; Bit3 starting times tripping. Bit0 anti-time overload alarm;...
  • Page 68 Maximum starting 090B 0-65535 word current by now Maximum Historical 090C 0-65535 word starting current Maximum current in 090D 0-65535 word operation by now Maximum Historical 090E 0-65535 word operation current Latest Fault Record 2100 、 2150 、 2200 、 2250 、 090F Communication word...
  • Page 69 Clear motor operation 0926 Write data 0xa5b5 word information 0927 Event record clear Write data 0xa5b5 word 1.6、 6.3、 25.0、 100.0、 250.0、 092E Current 800.0、1.0、5.0 word Current proportional 092F 1、10、100 factor 1-Stop、2-Start 1、3- Start 0930 Operational control bits 2、4-Emergency stop、 word 5-resei 0931...
  • Page 70 0946 Full value 2 times rated current word 0947 094B-09 623-645 reserve word 095A LCD version word 095B LCD NO. word 095C Main body version word 095D Main body NO. word Bit0 reverse time limit overload tripping; Bit1 grounding tripping; Bit2 underload tripping Bit3 disconnection;...
  • Page 71 Bit6 blocking alarm; Bit7 blocking alarm; Bit8 current imbalance alarm; Bit9 PTC temperature alarm; Bit10 external fault alarm; Bit11 start timeout alarm; Bit12 power alarm; Bit13 underpower alarm; Bit14 phase sequence alarm; Bit15 short circuit alarm. (0- No alarm, 1- Alarm) Bit0 fixed time...
  • Page 72 screen time （100～1000）mA 0972 Leakage alarm threshold word （100～1000）mA 0973 Leakage trip threshold word 0975 Leakage trip delay 0.1～600.0s Bit0:Action choice （ 0-Circuit breaker 0976 Leakage action choice 1-contactor ） Leakage fault starting 0977 0-25.0 screen time Under power alarm 0978 10～99% threshold...
  • Page 73 resistance 100-30000 09AC External fault trip delay 0.1～600.0s word Start timeout trip 09AE 100%～200% word threshold 09AF Start time 0.1～600.0s Over power alarm 09B0 100～700% threshold Over power trip 09B1 100～700% word threshold 09B3 Over power trip delay 0.1～600.0s Under power alarm 09B6 0～100% threshold...
  • Page 74 threshold 09E5-0 722-799 Reserve High speed trip 0A28 allowed/forbidden 1 High speed trip 0A29 allowed/forbidden 2 High speed alarm 0A2A allowed/forbidden 1 High speed alarm 0A2B allowed/forbidden 2 0A2C High speed rated current 0A2D High speed rated power 0A2E 0A2F High speed trip level 0A30 High speed tE trip level...
  • Page 75 High speed current 0A50 unbalance trip threshold High speed current 0A52 unbalance trip delay High speed start timeout 0A55 threshold High speed start timeout 0A56 time High speed over power 0A57 alarm threshold High speed over power 0A58 trip threshold High speed over power 0A5A trip delay...
  • Page 76 4-Three choice one ； 5- Two choice one ； 6-all control 0- Comm ； 1- In place ； 2- Three choice one Panel ； 3-Stop ； 4-Remote 0AC2 word permission output1 the default is 0 0- Comm ； 1- In place ； 2- Three choice one Panel ；...
  • Page 77 device self-checking, 14-the device output power, 15-nowhere electric process output chain, 16-electric reset signal output, 17-protected mode have nowhere electricity output 1, 18-protected mode electricity output 2,19- logic diagram output 1 output logic diagram,20- logic diagram output 2, 21- logic diagram output 3, 22-30 corresponding DI1-19 control the DO output...
  • Page 78 0B09 DO5 progamable word DO5 action 0B0A word setting(time) 0B0B DO5 trip setting1 word As same as DO1 （ 951-956 ） DO5 trip setting2 0B0C word DO5 alarm setting1 0B0D word DO5 alarm setting2 0B0E word 0B15-0 981-986 Reserve Bit0-Bit8 correspond DI1-9 ，...
  • Page 79 setting 997-100 0B38-0 Reserve 0-close;1-A;2-A*B;3-A+B; 4-A*B*C;5-(A+B)*C;6-(A *B)+C;7-A+B+C;8-A*B*C *D;9-(A+B)*C*D;10-(A*B +C)*D;11-(A+B+C)*D;12- A*B*C+D;13-(A+B)*C+D; 14-A*B+C+D;15-A+B+C+ D;16-A*B*C*D*E;17-(A+ B)*C*D*E;18-(A*B+C)*D 0B3E 1003 Logic diagram1 *E;19-(A+B+C)*D*E;20-( word A*B*C+D)*E;21-((A+B)* C+D)*E;22-(A*B+C+D)*E ;23-(A+B+C+D)*E;24-A* B*C*D+E;25-(A+B)*C*D +E;26-(A*B+C)*D+E;27-( A+B+C)*D+E;28-A*B*C+ D+E;29-(A+B)*C+D+E;30 -A*B+C+D+E;31-A+B+C+ Low-byte:0-Close;1-9 correspond to DI1-19;17-21 correspond to DO1 - DO6;27-Starting 1;28-Starting 2;29-Starting 3;30-Stop,31-Emergency shutdown;32-Stop state;33-Starting 1004 0B3F...
  • Page 80 Input B relay 1010 0B45 0.0-60.0s word Input C relay 1011 0B46 0.0-60.0s word Input D relay 1012 0B47 0.0-60.0s word Input E relay 1013 0B48 0.0-60.0s word 1014 0B49 Logic diagram 2 word 1015 0B4A Input A word Input B 1016 0B4B word...
  • Page 81 1100 0BB8 DI NO. 1-9 correspond to DI1-9 1101 0BB9 DI status 0-open 1-closed Action 1time-year High byt:year,low 1102 0BBA month byte:month Action 1time-day hour High byt:day,low byte:hour 1103 0BBB Action 1time-minute High byt:minute,low 1104 0BBC second byte:second 1105-11 0BBD-0 Reserve 1108-11 0BC0-0...
  • Page 82 1308-13 0C88-0 1316-13 0C90-0 1324-13 0C98-0 1332-13 0CA0-0 ditto ditto 1340-13 0CA8-0 1348-13 0CB0-0 1356-13 0CB8-0 1364-14 0CC0-0 reserve 0-External stop 1-Comm 2-In place 3-Panel 1500 0D48 Stop position 4-Remote 5-Emergency stop 6-Voltage loss stop Action 1time-year High byt:year,low 1501 0D49 month byte:month...
  • Page 83 0-All three phase lost power 1700 0E10 Cause of voltage shock 1-A phase 2-B phase 3-C phase 0E11 1701 Minimum voltage Unit :1% 1702 0E12 Time of voltage shock Unit :0.1S Action after voltage 1-keep 2-restart 1 3-restart 0E13 1703 shock Action 1time-year High byt:year,low...
  • Page 84 1924-19 0EF0-0 1930-19 0EF6-0 1936-19 0EFC-0 1942-19 0F02-0F 1948-20 0F08-0F reserve Record the number of 2020 0F50 Power on index power on Power on time-year High byt:year,low 0F51 2021 month byte:month Power on time-day hour High byt:day,low byte:hour 2022 0F52 Power on time-minute High byt:minute,low 2023...
  • Page 85 2068-20 0F80-0F 2072-20 0F84-0F 2076-20 0F88-0F 2080-20 0F8C-0 2084-20 0F90-0F reserve 2090-20 0F96-0F ditto 2100 0FA0 Trip status 1 0FA1 2101 Trip status 2 2102 0FA2 Alarm status 1 2103 0FA3 Alarm status 2 Action 1time-year High byte:year,low 2104 0FA4 byte:month month Action 1time-day hour...
  • Page 86 120 5120-52 1450-14 reserve Correspond address of 5300 14B4 custom address 1 Correspond address of 5419 157B custom address 120 9 9 9 9 Typical Typical applications Typical Typical applications applications applications 9.1 ARD2F Electrical Motor Protection Mode Wiring...
  • Page 87 When the stop button is pressed, the KM suction coil loses power, so that the main contact of the KM is released and the motor stops working. 9.2 ARD2F Electrical motor protector direct starting wiring diagram Direct starting: motor starting and stopping is controlled by protector, Press the Start 1 button on the display unit, Display unit control), DO1 relay (default start 1 function) closed, Close the KM's main contacts, The motor began to work.
  • Page 88 DO1 relay disconnected,KM coil power loss, motor stop work. 9.3 ARD2F Electrical motor protector forward/reverse wiring diagram Forward and reverse starting: motor starting and stopping are controlled by protector, Press the Start 1 button on the display unit, Display unit control), DO1 relay (default start 1 function) closed, Close the KM1's main contacts, Motor starting;...
  • Page 89 9.4 ARD2F Electrical Protector Y-△ Starting (Three Relay Mode) Wiring Diagram Y-△ start (three relay mode): motor start, stop is controlled by protector, Press the "Start 1" button on the display unit, Display unit control), DO1 relay (default start 1 function), DO3 relay (default start 3 function) closed,close the KM1、KM3's main contacts, Motor Y starting, After the switch...
  • Page 90 9.5 ARD2F Electrical Motor Protector Double Speed Mode Connection Double speed starting: motor starting and stopping are controlled by protector, Press the "Start 1" button on the display unit, Display unit control), DO1 relay (default start 1 function) closed, Close the KM1's main contacts, Motor starting at low speed; Press the start 2 button, DO1 relay (default start 1 function) disconnected, DO2 relay (default start 2 function) closed, Close the KM2、...
  • Page 91 is defined as" communication control ", output 2 is defined as "panel control ". The DI6 is defined as (control permission 1). When DI6( control permission 1) is disconnected, the control mode corresponding to the control permission output 1 takes effect, and the control mode corresponding to the output 2 takes effect when the DI6( control permission 1) is connected.
  • Page 92 Examples of of of of ordering ordering ordering ordering Example: specific model: ARD2F-100/QJMCSU-90L Technical requirements: motor power 37 KW, 4-20 mA analog output ,alarm output, voltage loss restart Communication protocol : RS485 protocol, MODBUS RTU protocol Auxiliary power: AC 220V Display mode :90L Note: main body and transformer connection length 1 m;...
  • Page 93 Address: NO.253,Yulv Road Jiading District, Shanghai,China Tel.: 0086-21-69158338 0086-21-69156052 0086-21-59156392 0086-21-69156971 Fax: 0086-21-69158303 Web-site:www.acrel-electric.com E-mail: ACREL008@vip.163.com Postcode:201801 Manufacturer: Jiangsu Acrel Electrical Manufacturing Co., Ltd, Address: NO.5,Dongmeng Road, Dongmeng Industrial Park, Nanzha Street, Jiangyin City,Jiangsu Province,China Tel./Fax:0086-510-86179970 Web-site: www.jsacrel.com Postcode: 214405...

This manual is also suitable for:
