LiftUPS-1k5-3LED-BC60
LiftUPS-1k5-6LED-BC60
LiftUPS-1k5-LCD-BC60
LiftUPS-1k0-3LED-BC60
LiftUPS-1k0-6LED-BC60
LiftUPS-1k0-LCD-BC60
1.07.2020
www.ips-ups.eu
LiftUPS-manual-EN-R1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LiftUPS-1k5-3LED-BC60 and is the answer not in the manual?

Questions and answers

Summary of Contents for IPS LiftUPS-1k5-3LED-BC60

  • Page 1 LiftUPS-1k5-3LED-BC60 LiftUPS-1k5-6LED-BC60 LiftUPS-1k5-LCD-BC60 LiftUPS-1k0-3LED-BC60 LiftUPS-1k0-6LED-BC60 LiftUPS-1k0-LCD-BC60 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 2: Safety And General Information

    Avoid a short circuit on positive and negative polarities of battery, otherwise it can lead to electric shocks or a fire. Cut off the electricity supply immediately when the UPS operates abnormally, and contact your dealer. ~ 1 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 3: Specifications

    Charging current Equalizing charge Single battery 14.2 Vdc (default), voltage 13.6 ~ 15.0 Vdc (selectable) Floating charge voltage Single battery 13.6 Vdc Single battery 10.8 Vdc (default), Low voltage alarm 9.6 ~ 13.0 Vdc (selectable) ~ 2 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 4 100 m) IP rating IP20 Cooling Forced-air cooling Noise < 45 dB Dimensions (mm) 205x146x70 Weight (kg) 1.50 1.50 1.52 Packaged weight (kg) 1.66 1.66 1.68 Note: "Selectable" can be customized according to customer requirements. ~ 3 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 5: Product Overview

    ④ Load indicator lights (green) ⑤ Power ON / OFF button 3.2 Panel Features (3 LED Indicators) ① Output indicator light (green) ② Charging indicator light (yellow) ③ Alarm indicator light (red) ④ Power ON / OFF button ~ 4 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 6 ③ Input live wire interface ④ Input neutral wire interface ⑤ Input earth wire Interface ⑥ Output neutral wire interface ⑦ Output live wire interface ⑧ Battery positive (+) interface ⑨ Battery negative (-) interface ~ 5 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 7: Installation

    Attach the UPS to the mounting bracket based on the fixed distance between holes. Mounting 1 Mounting 2 Fixed distance between holes 40 mm 220 mm 180 mm 2. Connect devices according to the UPS connection diagram. ~ 6 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 8: Operation

    48% > load ≥ 4% light is lit Load Two load indicator No load 96% > load ≥ 48% indicator lights are lit indicator light lights (green) Three load indicator load ≥ 96% lights are lit ~ 7 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 9: Troubleshooting

    1001. View the last two numbers of the output voltage displayed on the LCD panel to check the fault code. For example, the following picture shows that the fault code is 28. ~ 8 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
  • Page 10 Check if the battery is damaged and Battery overvoltage 1101 65 ~ 69 the battery voltage is normal or not. If the problem persists after rebooting, Relay fault 1110 70 ~ 74 please contact your supplier. ~ 9 ~ 1.07.2020 www.ips-ups.eu LiftUPS-manual-EN-R1...
