- Page 1 TS33-ON SERIES Instalation manual for three-three phase true-online UPS For models: TS33-ON-10k0 TS33-ON-15k0 TS33-ON-20k0 TS33-ON-30k0 www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
-
Page 2: Table Of Contents
5.1 Power-up mode / Shutdown mode 5.2 Standby mode 5.3 Bypass mode 5.4 Mains power mode (Frequency conversion mode) 5.5 Battery mode / battery self test mode 5.6 ECO mode 5.7 Fault mode 5.8 Maintenance bypass 5.9 Test mode Troubleshooting www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 3: Safety Information
It is not suitable to connect some electric equipments such as hair drier and heating appliance. Note：Symbol instructions Symbol Significations Symbol Significations Caution Protective earth Danger! High Disable/mute Voltage! audible alarm Turn on Bypass Turn off Battery inspection Standby or Repeat Shutdown Battery www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 4: Product Overview
RS232 / USB / EPO (standard) ; RS485 / AS400 / SNMP Communications (optional) OTHERS Operating 0 ~ 40℃ temperature Relative humidity < 95% (non-condensing) ≤ 60 dB (1m) ≤ 65 dB (1m) Noise level IP rating IP20 www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 5: Front Panel Features
360Vac. 2.2 Front panel features Front panel of standard Front panel of long Front panel of 10kVA standard model UPS (3 floors batteries) time model UPS model UPS (1 floor batteries) www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... - Page 6 UPS standard model UPS long time model UPS (3 floors batteries) (1 floor batteries) Rear panel of 15k / 20k / Rear panel of 15k/ 20k/ 30k long time model UPS 30k standard model UPS www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 7 ⑬ Intelligent slot 1 (SNMP / AS400 / ⑤ Main input breaker RS485 optional) ⑭Intelligent slot 2 (SNMP / AS400 / ⑥ Bypass input breaker RS485 optional) ⑦ Maintenance switch ⑮ Parallel port (optional) ⑧ Fan ⑯ Inbuilt battery breaker www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
-
Page 8: Installation
Place the UPS close to the mains input power distribution so as to cut off mains input switch and power supply in emergency situation. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... - Page 9 Not to connect UPS to any loads first, close the battery breaker and provide mains power to the UPS (close the UPS input breaker), UPS will charge the battery group. To Battery input terminal of UPS Positive Negative battery breaker 16/18/20 Battery Battery Battery Battery 10-30k long time model UPS battery connection www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
-
Page 10: Parallel System Installation
For three or more parallel UPS units, the quantity of parallel cables needed equals to the UPS quantities. It just needs to connect each UPS in sequence with the parallel cables by parallel cards. Parallel cable connection for two UPS Parallel cable connection for three or more UPS www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... - Page 11 Connect all parallel UPS input cables to the input patchboard. Mains input Public input terminal block Public output terminal block Load Load Load Load - - - block Parallel UPS connection Two parallel UPS connection Load www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 12 In the condition of each single UPS running, set the output voltage (OPU) of each UPS, and ensure that each OPU is same. Verify if the parallel cables of all UPS are connected firmly, perform startup and finish parallel installation. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
-
Page 13: Operation Instructions
In menu setting interface: Press more than half a second and less than 2 seconds to confirm the setting option. Press and hold more than 2 seconds to exit the menu setting interface. 4.1.2 LED indicators www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... - Page 14 There are following contents in the area of display page After starting up in 20 seconds, this display area mainly indicates the UPS power rating. This display area mainly indicates the UPS operation mode in 20 seconds after starting up, such as STdby www.ips-ups.eu 28.05.2018 info@ips-ups.eu...
- Page 15 UPS working status to the indicator Buzzer sound Description Long beep Fault mode Low battery in battery mode 1 s per beep Output and bypass overload 2 minper beep The inverter is not open 4 s per beep All other alarms www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
-
Page 16: Ups Settings
Although the UPS settings can be configured in any mode, it is suggested that it should be better to make the setting operation in standby mode. Contact with suppliers or after sales staff if need other configuration (frequency conversion mode, ECO mode ON, parameter adjustment, special menu settings ect.) www.ips-ups.eu 28.05.2018 info@ips-ups.eu... - Page 17 2 seconds to exit the setting interface and return to the home screen. Note: Configure the output voltage setting of parallel UPS units in standby or bypass mode. The settings of single UPS unit can be configured in any mode. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 18 2 seconds to exit the setting interface and return to the home screen. Note: The low voltage alarm point of each battery is (Eod + 1V) (Battery low voltage shutdown point + 1V)×Numbers of battery. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 19 2 seconds to exit the setting interface and return to the home screen. Note: The physical address setting can be only configured in case of single UPS operating, it can not be done in parallel UPS units www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 20 2 seconds to exit the setting interface and return to the home screen. Note: The single UPS unit will emit an alarm indicating PAL SET F after PAL Enable. And it is forbidden to start the UPS. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 21 UPS output information. Power up again after power off, the UPS enter normal mode. Note: The menu setting interface will not have CHK option until failure, there is no CHK option when the UPS is normal. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 22 Note: Expert mode is OFF by default. After setting it to be ON, EP will be restored to be OFF if power up again, but the setting contents of three options (CLR W, PCS and EPO) will be saved in real time. www.ips-ups.eu 28.05.2018 info@ips-ups.eu...
- Page 23 Press menu setting button more than 2 seconds to exit the setting interface, and get back to the main menu (or wait at most 30 seconds, it will automatically jump back to the main menu). www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 24 Note: After back-end software setting the model (TyPE), the number of batteries (PCS) will change accordingly, if set the model as S, PCS will automatically turn to be the default value 20, if set the model as H, PCS will automatically turn to be the default value 16. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 25 2 seconds to exit the setting interface, and get back to the main menu (or wait at most 30 seconds, it will automatically jump back to the main menu). Note: After setting OP OFF, the output power fails when emergency power shut off. www.ips-ups.eu 28.05.2018 info@ips-ups.eu...
-
Page 26: Parameters Inquiry
InterfacePage 1 (main interface): Display UPS phase A information, as shown below InterfacePage 2: Display UPS phase B information, as shown below InterfacePage 3: Display UPS phase C information, as shown below InterfacePage 4: Display UPS frequency information, temperature and software version, as shown below： www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 27: Event Log Query
200 pages (600 pieces) event logs records. Press and hold the inquiry button more than 2 seconds again to return to the home screen. Page Time Fault code Event logs query is for qualified personnel use only. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 28: Ups On / Off Operation
Mute silence. If press Self Test / Mute button more operation than 1 second again, the buzzer starts beeping, the buzzer disable icon is eliminated. In any modes, MUTE ON is configurable by LCD panel www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 29: Connect The Communication
The EPO port is on the rear panel of the UPS with green terminals. Its connection is as follows： In normal condition, pins ① and pins ② are closed； when perform Emergency Power Off, disconnect pins ① and pins ② . www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... - Page 30 Wait until the disply screen is extinguished completely and on standing for 10 mins, make sure there is no hazard of electrical shock inside the UPS, and you can do on-line maintenance for the UPS. After finishing on-line maintenance, close the input breaker first, then make the maintenance switch at “UPS” end, and www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
-
Page 31: Parallel Ups Operation
UPS and parallel system, then disconnect all parallel cables of the faulty UPS and parallel system, and then make maintenance operation for the faulty one. www.ips-ups.eu 28.05.2018 info@ips-ups.eu... -
Page 32: Operation Modes
In mains power mode / battery mode / frequency conversion mode, shut down the UPS when bypass is abnormal Shut down the single UPS unit when inverter of parallel UPS units is operating Exit fault mode and byass is abnormal 维修旁路 Maintenance bypass www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 33: Bypass Mode
After the inverter startup, automatically start the charger charging batteries. LED indicator in mains power mode is as shown in the figure below: the inverter LED indicator (green) is illuminated, meanwhile LCD display LinE characters. www.ips-ups.eu 28.05.2018 info@ips-ups.eu... -
Page 34: Battery Mode / Battery Self Test Mode
Battery mode / battery self test modeoperation process 5.6 ECO mode LED indicator in ECO mode is as shown in the figure below: the inverter.LED indicator (green) is illuminated and bypass LED indicator (yellow) is illuminated, meanwhile LCD display ECO characters. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 35: Fault Mode
Keep bypass supplying power to the load for other faults beyond above status. After the UPS enter fault mode, press mute button to mute the sound (auto cancel mute in one day), meanwhile contact your supplier or serviceman for troubleshooting. www.ips-ups.eu 28.05.2018 info@ips-ups.eu... -
Page 36: Maintenance Bypass
“BYPASS” by hand, otherwise it may cause damage to the UPS. Refer to 4.6.4 for details. 5.9 Test mode Test mode is specially used for test purpose, It is available to control UPS step-startup and drive test ect. by back- end software. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... -
Page 37: Troubleshooting
Output short-circuit loads. And then restart the information - AOP UPS. If the problem SHORT/BOP persists, contact the SHORT/COP supplier. SHORT/AB SHORT/BC www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0... - Page 38 The mains power is UPS input fuse is Replace with new fuse or normal but the UPS fails disconnected or check input manner or to access to mains input wiring is wrong contact the supplier power www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
- Page 39 TS33-ON SERIES Note: Contact the supplier if display screen shows other fault information. After troubleshooting, power-up need to enter menu setting interface to configure CHK OFF, refer to 4.2.8 for operation details. www.ips-ups.eu 28.05.2018 info@ips-ups.eu TS33-ON-manual_EN-R0...
