- Page 1 HARDWARE USED (ACTUAL SIZE) BUGGY BUGGY CONVERSION CONVERSION INSTRUCTION MANUAL INSTRUCTION MANUAL HARDWARE USED (ACTUAL SIZE) × 4 M2.5 × 6 BHCS REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED (ACTUAL SIZE) × 4 M2.5 × 12 SHCS...
- Page 2 HARDWARE USED (ACTUAL SIZE) Snap nose piece into place HARDWARE USED (ACTUAL SIZE) × 2 M2.5 × 8 BHCS HARDWARE USED (ACTUAL SIZE) × 4 M2.5 × 8 BHCS...
- Page 3 HARDWARE USED (ACTUAL SIZE) × 2 M2.5 × 12 SHCS HARDWARE USED (ACTUAL SIZE) × 6 M2.5 × 14 BHCS HARDWARE USED (ACTUAL SIZE) × 1 M3 × 12 SHCS Plastic washer from parts tree...
- Page 4 HARDWARE USED (ACTUAL SIZE) × 2 M2.5 × 6 BHCS HARDWARE USED (ACTUAL SIZE) × 2 M2.5 × 6 BHCS HARDWARE USED (ACTUAL SIZE) Trim and mount painted PRO-2 Buggy body...
- Page 5 HARDWARE USED (ACTUAL SIZE) × 3 M2.5 × 12 SHCS REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED (ACTUAL SIZE) PRO-2 CHASSIS × 4 M2.5 × 6 BHCS HARDWARE USED (ACTUAL SIZE) × 2 M3 × 12 SHCS...
- Page 6 HARDWARE USED (ACTUAL SIZE) Install setscrew leaving × 1 ½ of the threads exposed M4 × 12 Setscrew HARDWARE USED REAR SHOCK TOWER (ACTUAL SIZE) × 4 M2.5 × 12 SHCS HARDWARE USED (ACTUAL SIZE) Install setscrew leaving × 1 ½...
- Page 7 HARDWARE USED (ACTUAL SIZE) × 2 M3 × 14 BHCS FRONT BULKHEAD HARDWARE USED (ACTUAL SIZE) × 4 M4 × 12 FHCS FRONT OF PRO-2 HARDWARE USED (ACTUAL SIZE) × 2 M3 × 8 SHCS × 2 M4 × 14 BHCS...
- Page 8 HARDWARE USED (ACTUAL SIZE) × 2 M2.5 × 6 SHCS HARDWARE USED (ACTUAL SIZE) × 2 M3 × 8 BHCS × 2 M3 × 9 Washer HARDWARE USED (ACTUAL SIZE) × 1 M3 X 30 SHCS × 1 M3 X 54 SHCS ×...
- Page 9 HARDWARE USED (ACTUAL SIZE) × 1 M3 × 20 SHCS × 1 M3 × 16 SHCS HARDWARE USED (ACTUAL SIZE) M3 × 8 SHCS × 2 M3 × 10 SHCS × 2 M3 × 8 SHCS × 1 M3 × 10 SHCS OPTIONAL STEPS HARDWARE USED (ACTUAL SIZE)
- Page 10 HARDWARE USED (ACTUAL SIZE) × 2 M2.5 × 10 BHCS M3 x 6 Wood screws (included with lights) × 4 HARDWARE USED (ACTUAL SIZE) Wing Mount – Requires 1/10 Buggy Wing (Sold Separately) × 3 M2.5 × 12 SHCS HARDWARE USED (ACTUAL SIZE) ×...
