Pro-Line Boats PRO-2 Manual

1:10 2wd short course buggy kit
Hide thumbs Also See for PRO-2:

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Line Boats PRO-2

Summary of Contents for Pro-Line Boats PRO-2

  • Page 2: Tools Required

    From your friends at Pro-Line This assembly manual contains instructions for Pro-Line is continually improving our products; building your new PRO-2 Buggy. Please take your consequently, actual parts included in the PRO-2 time building the kit according to the instructions Buggy kit may appear slightly different than the and become familiar with the steps.
  • Page 3 HARDWARE USED Front Bumper Assembly (ACTUAL SIZE) M2.5 × 6 × 2 M2.5 × 6 SHCS × 2 M3 × 8 SHCS HARDWARE USED Front Shock Tower to Bulkhead (ACTUAL SIZE) × 2 M3 × 14 BHCS (BAG B) HARDWARE USED Front Bumper to Bulkhead (ACTUAL SIZE) ×...
  • Page 4 HARDWARE USED Shock Mounting Hardware (ACTUAL SIZE) OUTSIDE HOLE × 2 M3 X 30 SHCS × 2 M3 Washer × 2 Ball Ends × 2 M3 Locknut HARDWARE USED Front Bumper to Shock Tower (ACTUAL SIZE) × 2 M3 × 8 BHCS ×...
  • Page 5 HARDWARE USED Front Camber Link Pivot Balls (ACTUAL SIZE) DRIVER’S SIDE LINK × 2 Small Inner Pivot Balls × 2 Large Inner Pivot Balls KEEP THESE MARKS ON DRIVER’S SIDE PASSENGER’S SIDE LINK “DRIVER’S SIDE” AND “PASSENGER’S SIDE” REFER TO U.S. STANDARDS HARDWARE USED Front Camber Links to Shock Tower (ACTUAL SIZE)
  • Page 6 HARDWARE USED Front Hub Assembly (ACTUAL SIZE) × 4 5 × 11 Bearing × 2 King Pin AXLE Axle × 2 REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED Front Wheel Hex Assembly (ACTUAL SIZE) × 2 Cross Pin (Bag G) SHIMS BETWEEN BEARING AND PIN.
  • Page 7 HARDWARE USED Steering Links to Rod Ends & Pivot Balls (ACTUAL SIZE) 70mm (ACTUAL SIZE) × 4 Short Rod Ends 87.5mm (ACTUAL SIZE) × 2 × 4 Large Pivot Balls USE INCLUDED TURNBUCKLE WRENCH, REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED Steering Link to Steering Knuckle (ACTUAL SIZE)
  • Page 8 HARDWARE USED Assemble Front End to Chassis (ACTUAL SIZE) × 3 M4 × 10 FHCS HARDWARE USED Front Bumper Brace to Front Bulkhead (ACTUAL SIZE) × 2 M4 × 14 BHCS HARDWARE USED Rear Shock Mounting Hardware (ACTUAL SIZE) × 2 M3 ×...
  • Page 9 HARDWARE USED Rear Camber Links to Rod Ends & Pivot Balls (ACTUAL SIZE) 50mm (ACTUAL SIZE) 82mm (ACTUAL SIZE) × 4 Long Rod Ends × 2 × 2 Small Inner Pivot Balls DRIVER’S SIDE LINK × 2 Large Inner Pivot Balls KEEP THESE MARKS ON DRIVER’S SIDE PASSENGER’S SIDE LINK USE INCLUDED TURNBUCKLE WRENCH...
  • Page 10 HARDWARE USED Rear Body Mount to Shock Tower (ACTUAL SIZE) Install setscrew leaving × 4 ½ of the threads exposed M2.5 × 12 SHCS × 1 Black O-Ring × 1 M4 × 12 Setscrew × 1 Secure-Loc Cap HARDWARE USED Outdrives to Transmission (ACTUAL SIZE) ×...
  • Page 11 HARDWARE USED Rear Arms & Hub Carriers Assembly (ACTUAL SIZE) × 4 5 × 11 Bearing × 2 Rear Outer Hinge Pin (Bag F) × 2 Rear Inner Hinge Pin (Bag F) × 4 M3 Locknut LOWER HOLE (Bag F) REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED Rear Wheels Hex &...
  • Page 12 HARDWARE USED Rear Bumper to Chassis (ACTUAL SIZE) × 1 M3 X 30 SHCS × 1 M3 X 54 SHCS × 2 M3 Locknut HARDWARE USED Rear Bumper Brace to Transmission (ACTUAL SIZE) × 1 M3 × 20 SHCS × 1 M3 ×...
  • Page 13 Shock Setup (Fluids Bag) 1. Remove Springs 2. Fill with oil 3. Bleed 4. Tighten 5. Replace Springs × 4 Visit prolineracing.com/pro-2/build for shock assembly videos and spring rate charts. HARDWARE USED Install Rear Shocks (ACTUAL SIZE) × 2 M3 × 16 BHCS...
  • Page 14 HARDWARE USED Front Arms & Hinge Pin Brace to Bulkhead (ACTUAL SIZE) Steering Rod 2” (ACTUAL SIZE) × 2 Short Rod Ends × 1 Large Pivot Balls HARDWARE USED HARDWARE USED Install Servo (ACTUAL SIZE) (ACTUAL SIZE) × 2 Remove (4) screws in Servo Mount M3 ×...
  • Page 15 HARDWARE USED Motor Installation (ACTUAL SIZE) × 2 M3 × 8 SHCS × 2 HD Motor Washer Remove Gear Cover Install Motor Set Gear Mesh (Pinion sold separately) Reinstall Gear Cover HARDWARE USED (ACTUAL SIZE) Install Pre-Mounted Blockade Tires (PL #1183-25) See our full line of Pre-mounted SC Tires by scanning this QR code.
  • Page 16 HARDWARE USED Roof & Nose Brace to Cage (ACTUAL SIZE) × 4 M2.5 × 12 SHCS HARDWARE USED Rear Cage Assembly (ACTUAL SIZE) × 6 M2.5 × 8 BHCS HARDWARE USED Rear Cage Assembly Cont’d (ACTUAL SIZE) × 2 M2.5 × 12 SHCS...
  • Page 17 Paint & Trim your PRO-2 SC Buggy Body. Visit prolineracing.com/how-to-tips for body painting tips. SCAN HARDWARE USED Attach Side Panels (ACTUAL SIZE) × 6 M2.5 × 14 BHCS HARDWARE USED Mount Helmet (ACTUAL SIZE) × 1 M3 × 12 SHCS...
  • Page 18 Painted interior to Cage - Rear (ACTUAL SIZE) × 2 M2.5 × 6 BHCS HARDWARE USED (ACTUAL SIZE) Trim & mount painted PRO-2 Buggy Body HARDWARE USED Nerf Bars to Cage (ACTUAL SIZE) × 6 M2.5 × 12 SHCS REPEAT THIS STEP FOR OPPOSITE SIDE...

  • Page 19: Electronics Placement

    Remove Truck Nerf Bars REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED Install Buggy Body Holders (ACTUAL SIZE) × 4 M2.5 × 6 BHCS Electronics Placement ELECTRONICS (Not Included) ANTENNA TUBE RECEIVER (Not Included) FOAM STRIPS...

  • Page 20: Optional Steps

    OPTIONAL STEPS HARDWARE USED Light Mounts – Requires #6085-00 (Sold Separately) (ACTUAL SIZE) × 2 M2.5 × 10 BHCS M3 x 6 Wood screws (included with lights) × 2 REPEAT THIS STEP FOR OPPOSITE SIDE HARDWARE USED Light Mounts – Requires #6085-00 (Sold Separately) (ACTUAL SIZE) ×...

  • Page 21: Optional Parts

    6308-01 Pro-Spec Shocks (Rear) 6085-00 Light Bar Kit 6092-13 Optional 78T Spur Gear 6308-31 Pre-Assembled (Rear) 6092-17 MIP Super Ball Diff Kit Go To ProLineRacing.com for the latest Tires, 6092-17 MIP Super Ball Diff Kit Wheels, & Accessories for your PRO-2 SC Buggy!
  • Page 22 Stock PRO-2 Buggy Setup TRACK: EVENT: DRIVER: DATE: SC BUGGY SETUP SHEET QUAL: FINISH: FRONT PROTRAC SUSPENSION FRONT SHOCKS INSIDE (A) PISTON: Stock OIL WEIGHT: 35 wt (B) PRIMARY SPRING: Yellow (C) SECONDARY SPRING: Green DROOP SPACER: CAMBER: ° COMPRESSION SPACER: °...
  • Page 23 TRACK: EVENT: DRIVER: DATE: SC BUGGY SETUP SHEET QUAL: FINISH: FRONT PROTRAC SUSPENSION FRONT SHOCKS INSIDE (A) PISTON: OIL WEIGHT: (B) PRIMARY SPRING: (C) SECONDARY SPRING: DROOP SPACER: CAMBER: ° COMPRESSION SPACER: ° TOE: (D) SPRING ADJUSTMENT: RIDE HEIGHT: STOCK SHOCKS REAR SHOCKS (A) PISTON: REAR PROTRAC SUSPENSION...
