  • Page 1 INSTRUCTION MANUAL INSTRUCTION MANUAL...
  • Page 2 Thank you for purchasing Pro-Line’s PRO-Fusion SC 4×4! For Over developed from the ground up for extreme performance, durability, 35 years, Pro-Line has designed and manufactured the best RC versatility, and most importantly, fun! Thank you for choosing the products in the world. This 1:10 scale 4×4 SC truck has been PRO-Fusion SC 4×4 and joining Team Pro-Line in making history! This assembly manual contains instructions for building your Pro-Line is continually improving our products;...
  • Page 3 HARDWARE USED Differential Assembly - Build Differential Assembly - Build 3× (ACTUAL SIZE) INSTALL DRIVE PIN × 3 × 3 18 × 12 × 4 Bearings 18 × 12 × 4 Bearings × 6 × 6 Large Diff Shim Large Diff Shim ×...
  • Page 4 HARDWARE USED Center Diff Mount, Battery Foam & Chassis Braces Center Diff Mount, Battery Foam & Chassis Braces (ACTUAL SIZE) × 5 × 5 M4 × 12 FHCS M4 × 12 FHCS × 3 × 3 M3 × 10 FHCS M3 ×...
  • Page 5 HARDWARE USED Front Diff Case Assembly Front Diff Case Assembly (ACTUAL SIZE) × 4 × 4 M3 × 14 FHCS M3 × 14 FHCS HARDWARE USED Front Arms & Hinge Pins Front Arms & Hinge Pins (ACTUAL SIZE) LOWER: × 4 ×...
  • Page 6 HARDWARE USED Front Axle & Hub Assembly Front Axle & Hub Assembly (ACTUAL SIZE) × 2 × 2 Drive Pin Drive Pin × 2 × 2 Drive Pin Cup Drive Pin Cup × 2 × 2 M3 Set Screw M3 Set Screw ×...
  • Page 7 HARDWARE USED Steering Rack Steering Rack (ACTUAL SIZE) Groove inside × 4 × 4 PRO TIP 11 × 5 × 4 Bearing 11 × 5 × 4 Bearing Use included 17mm wheel nut wrench to tighten servo saver collar. × 2 ×...
  • Page 8 HARDWARE USED Install Top Plate Install Top Plate (ACTUAL SIZE) (not included) × 6 × 6 M3 × 10 SHCS M3 × 10 SHCS HARDWARE USED Steering Turnbuckle Assembly - Build Steering Turnbuckle Assembly - Build 2× (ACTUAL SIZE) (actual size) Step 1 ×...
  • Page 9 HARDWARE USED Rear Diff Case Assembly & Rear Arms Rear Diff Case Assembly & Rear Arms (ACTUAL SIZE) NOTE ORIENTATION M3 × 20 FHCS × 2 × 2 18 × 12 × 4 Bearings 18 × 12 × 4 Bearings ×...
  • Page 10 HARDWARE USED Rear Hubs to Arms & Rear Shock Tower Rear Hubs to Arms & Rear Shock Tower (ACTUAL SIZE) × 4 × 4 M3 × 16 SHCS M3 × 16 SHCS × 6 × 6 M3 Locknut M3 Locknut ×...
  • Page 11 HARDWARE USED Rear Sway Bar Assembly Rear Sway Bar Assembly (ACTUAL SIZE) × 4 × 4 M3 × 3 Set Screw M3 × 3 Set Screw FOR REAR SWAY BAR Use 2.7mm bar (thinner of 2 bars) IMPORTANT 38.5mm Ensure the end of the sway (actual size) bar is fl...
  • Page 12 HARDWARE USED Rear Bumper & Skid Plate Assembly Rear Bumper & Skid Plate Assembly (ACTUAL SIZE) M3 × 8 SHCS M3 × 12 SHCS × 4 × 4 M3 × 8 SHCS M3 × 8 SHCS M3 × 8 SHCS ×...
  • Page 13 HARDWARE USED Front Sway Bar to Arms Front Sway Bar to Arms (ACTUAL SIZE) × 2 × 2 Sway Bar Ball Stud Sway Bar Ball Stud × 2 × 2 Short Sway Bar Link Short Sway Bar Link Build Build HARDWARE USED Front Bumper Assembly Front Bumper Assembly...
  • Page 14 HARDWARE USED Shock Assembly - Build Shock Assembly - Build Front & Front & Rear Rear 2× 2× (ACTUAL SIZE) × 4 × 4 PRO TIP Lower Shock Pivot Ball Lower Shock Pivot Ball To avoid damaging the shock shaft when threading the bottom shock eyelet on, use shock pliers OR use...
  • Page 15 HARDWARE USED Body Mount Assembly Body Mount Assembly (ACTUAL SIZE) IMPORTANT FRONT Install Set Screw × 4 × 4 leaving ½ of the M4 × 16 Set screw M4 × 16 Set screw threads exposed. × 4 × 4 6.5 × 1.5 O-Ring 6.5 ×...
  • Page 16 HARDWARE USED Center Battery Strap Brace to Chassis Center Battery Strap Brace to Chassis (ACTUAL SIZE) × 3 × 3 M3 Locknut M3 Locknut × 3 × 3 M3 × 10 FHCS M3 × 10 FHCS HARDWARE USED Battery Stops Battery Stops (ACTUAL SIZE) PRO TIP...
  • Page 17 HARDWARE USED Install Servo Install Servo (ACTUAL SIZE) IMPORTANT Feed servo wire through channel in center × 4 × 4 diff case. Secure the wire to keep it from getting damaged by spur gear. M3 × 10 SHCS M3 × 10 SHCS ×...
  • Page 18 HARDWARE USED Install Motor & Pinion Gear Install Motor & Pinion Gear (ACTUAL SIZE) × 1 × 1 M4 × 4 Set screw M4 × 4 Set screw × 4 × 4 M3 × 10 FHCS M3 × 10 FHCS Setting Gear Mesh IMPORTANT PRO-Fusion SC 4×4 includes eccentric gear mesh inserts...
  • Page 19 Select Body & Tires Now the fun really begins! The PRO-Fusion SC 4×4 is able to use IMPORTANT many different body and tire combinations. Make your truck into a True-Scale Short Course truck, an ultimate bashing machine, a Whichever body or tire style you choose, please note that the slammed street truck —...

  • Page 20: Front Caster

    Tuning Tips FRONT CASTER This is the angle of the front hub from vertical when viewed from the side of the PRO-Fusion SC 4×4. It is adjusted by swapping or changing the combination of the 1mm and 2mm spacers on the front upper hinge pin.

  • Page 21: Center Differential

    CENTER DIFFERENTIAL SHOCK OIL & LOCATION Stock oil included in the center diff is 500,000 cSt. Stock shock oil for the PRO-Fusion SC 4×4 is 60wt. There are two shock mounting locations on the shock towers and two on the When using 1:8 motor systems with 4S Lipo power, you may fi...
  • Page 22 Option Parts Short Course Tires 17mm Hex Wheels TRENCHER X SC STREET FIGHTER SC BLOCKADE SC RAID F-11 Award-winning all- Perfect balance of The Blockade excels 17mm hexes are 2.8" tough and rugged terrain tire works on G-force enhancement in a wide variety of stronger and can look with 17mm Hex any surface.
  • Page 23 Part # Part Name Qty. in group 6062-06 50×4mm Steering Turnbuckle 4005-19 4005-36 4005-48 6070-02 Secure-Loc Cap Kit Front Upper Hinge Pin M3 × 14 SHCS Front Hub - Left 6082-02 60×4mm Rear Turnbuckle Lower Inner Hinge Pin Rear Body Mount Front Hub - Right 6092-06 Diff Internal Gear Replacement Kit 1...
