- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / Assembly instructions ShowerTablet Select 400 24340XX7 ShowerTablet Select 400 24360XX7...
- Page 2 中文 保养 (参见第页 6) 安全技巧 装配时为避免挤压和切割受伤，必须戴上手套。 • 单向阀必须在符合国家或当地的法律的情况下按照EN 806-5定期检查 ( 本产品只允许作为洗浴、卫生和洁身之用。 至少一年一次) 。 不得让儿童和肢体、精神和/或意识有障碍的成人在不受监管的情况下 • 为了保证恒温器的稳定运转，请务必定期从最热到最冷转动调温器。 使用淋浴系统。受酒精或毒品影响的人员不得使用淋浴系统。 大小 (参见第页 8) 该产品不得作扶柄使用。必须安装单独的扶柄。 冷热水管间过大的压力差必须予以平衡。 流量示意图 (参见第页 8) 安装提示 手持花洒 • 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或 浴缸出水口 表面损伤。 备用零件 (参见第页 9) • 管道和阀门必须根据通用标准进行安装、冲洗和检查。 • 请遵守当地国家现行的安装规定。 XX = 颜色代码 • 由有资格的专业人员进行产品安装时请注意：在所有加固区域中，加 00 = 镀铬 固表面是否平整 (无突出的接缝或瓷砖) ，墙体结构是否适合产品安装 67 = Matt Black 且未显露出任何缺点。 70 = Matt White • 本产品并非设计来与蒸气浴连接使用！...
-
Page 3: Installation Instructions
English Adjustment (see page 4) Safety Notes After the installation, the output temperature of the thermostat must be checked. A Gloves should be worn during installation to prevent crushing and cutting correction is necessary if the temperature measured at the output differs from the injuries. temperature set on the thermostat. The product may only be used for bathing, hygienic and body cleaning Maintenance (see page 6) purposes. Children as well as adults with physical, mental and/or sensoric impairments • The check valves must be checked regularly according to EN 806-5 in must not use this product without proper supervision. Persons under the accordance with national or regional regulations (at least once a year). influence of alcohol or drugs are prohibited from using this product. • To guarantee the smooth running of the thermostat, it is necessary from time to The product may not be used as a holding handle. A separate handle must be time to turn the thermostat from total hot to total cold. installed. Dimensions (see page 8) The hot and cold supplies must be of equal pressures. Flow diagram (see page 8) Installation Instructions • Prior to installation, inspect the product for transport damages. After it has been Hand shower installed, no transport or surface damage will be honoured. Bath Spout • The pipes and the fixture must be installed, flushed and tested as per the Spare parts (see page 9) applicable standards. - Page 4 SW 27 mm X + 38 mm SW 3 mm SW 3 mm (3 Nm)
- Page 5 SW 3 mm for example 42°C z. B. 42°C SW 3 mm (1 Nm)
- Page 6 SW 22 mm SW 3 mm SW 22 mm (4 Nm) 红色 /Red SW 3 mm (3 Nm)
- Page 7 > 40 °C...
- Page 8 ShowerTablet Select 400 ShowerTablet Select 400 24340XX7 24360XX7 21 - 26 21 - 26 150 ± 12 150 ± 12 G 1/2 G1/2 ShowerTablet Select 400 ShowerTablet Select 400 24340XX7 24360XX7 0,60 0,60 0,55 0,55 0,50 0,50 0,45 0,45 0,40...
- Page 9 ShowerTablet Select 400 24340XX7 95772000 95773000 96429000 98282007 98913000 98371000 92136000 (29x3) 94405XX0 98199000 (17x2) 94404000 95758000 94403XX0 98372000 98368000 (M6x16) (M28x1,5) 9293400X 98140000 92340000 98367XX0 (20x1) ShowerTablet Select 400 24360XX7 95772000 95773000 96429000 98282007 98371000 98913000 (29x3) 92136000 98199000...
-
Page 10: Warranty
English Cleaning Recommendation for Hansgrohe Products Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs and radiators consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and reclamations, it is necessary to consider certain criteria when cleaning. - Page 12 Hansgrohe · Auestraße 5 – 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
