- Page 1 Foxtech GS-75U Dual-screen Ground Contrtol Station...
- Page 2 Ground station use and maintenance instructions The basic operation of a hardened notebook is similar to that of a normal notebook, but there are also differences caused by the unique structure and different features of the design. ● Power on Make sure the computer power connection is intact or the lithium battery is fully charged, press the power on button for 1-2s, if there is a password, please enter the user password and then enter the system.
-
Page 3: Specification
indicates that your computer has been powered on, please observe the LCD screen, if it has No response, please check the LCD connection cable, confirm whether the BIOS screen resolution of the external monitor is 1920 * 1080 bit. ● can't boot into the system. Please confirm in the BIOS if the hard disk information is denied, check whether the system is damaged, if there is damage, reinstall the system. - Page 4 Interface Dimension...
-
Page 6: Turn On The Computer
● Size of the reserved space at the bottom Computer operation instructions ● Turn on the computer 1. Press the top of the laptop with your thumb to open the laptop 2. Press and hold the computer's rear power-on button to turn on the computer... - Page 7 Power Switch ● Interface cover operating instructions The cover can be opened by pressing down the snap with the thumb and pivoting outward. ● Instructions for the use of the aviation plug interface Plug in the connection cable Note: When the cable is inserted into the interface, please align the red dot on the cable with the red dot on the interface 2.
- Page 8 ● Antenna interface operating instructions Insert the antenna into the WIFI interface, rotate and tighten the position of the antenna as shown in the figure Bend the antenna ● Antenna interface operating instructions Click on the Start menu at the bottom left corner of the desktop...
- Page 9 Select power options Select Shutdown to turn off the computer ● Extended Desktop Settings Right-click the desktop, click Display Settings to enter the monitor settings panel...
- Page 10 Click the Multi-monitor settings drop-down list and select "Extend Desktop 1 and 3" to enter the next setting screen...
- Page 11 Click on the logo to identify the monitor number (the number is displayed at the bottom right of the monitor)
- Page 12 Drag the monitor serial number square to arrange the monitors, and click Apply when the settings are completed.
- Page 13 Note: The following arrangement, the mouse can be moved up and down to move back and forth between the two monitors of 3 and 1 serial number (When the mouse cursor in the serial number 3 monitor, put the mouse down, the mouse cursor can be to the serial number 1 monitor to operate) ●...
- Page 14 Select tablet settings Click on Settings...
- Page 15 Tap to touch input Enter the settings screen and operate according to the text prompts. Tap the screen with one finger to identify it as a touch Press Enter to continue to the next step to complete your screen. If this is not a tablet screen, press Enter to go to configuration.
- Page 16 When the battery power reaches 20% the light turns red (at this time you can access the adapter for charging) When the battery power reaches 10% the light flashes slowly, the power reaches 5% the light flashes quickly (connect the adapter to change the light flashing status) ●Signal source adjustment instructions Press the PLUS button to select the signal source, and then press Enter to complete the selection...
- Page 18 Joystick/key communication protocol...
- Page 20 Joystick/Button Diagram...
