ORIGINAL CUMARU ROPE PORCH SWING
I N ST R U C T I O N S
ASSEMBLY
STEP 1. Use (2) 1.75" hex bolts and (2) washers to attach left
and right arm to loose cross bar.
RIGHT ARM
RIGHT ARM
WASHER
WASHER
1.75"
1.75"
LOOSE CROSS BAR
HEX BOLT
HEX BOLT
HARDWARE PACK
Hardware Pack Weight: 12.6 oz.
(2) CHAIN SETS
(2) TREE HOOKS
CHAIR PARTS
• LEFT ARM
• RIGHT ARM
• LOOSE CROSS BAR
• ROPE SEAT
LEFT ARM
LEFT ARM
SUGGESTED TOOLS
• MALLET
WASHER
WASHER
• 7/16" WRENCH
1.75"
1.75"
• 1/2" WRENCH
HEX BOLT
HEX BOLT
(2) WASHERS
(Not pictured. Eye bolts,
nuts and washers included
on chain set.)
(2) 1.75" HEX BOLTS
Advertisement
Related Manuals for Nags Head Hammocks CUMARU
Summary of Contents for Nags Head Hammocks CUMARU
- Page 1 ORIGINAL CUMARU ROPE PORCH SWING HARDWARE PACK I N ST R U C T I O N S Hardware Pack Weight: 12.6 oz. (2) 1.75” HEX BOLTS (2) WASHERS (2) CHAIN SETS (Not pictured. Eye bolts, nuts and washers included on chain set.)
- Page 2 If you are not satisfied with an item, return it unused in its original packaging for a complete refund or exchange. You can return it to any of our stores or to our warehouse, Nags Head hammocks, 305 Industrial Blvd., Greenville, NC 27834.
