Part V

Parameter List

This section explains the parameters that actually can be transferred by the Instrument.
19

Using the Parameter List

• Parameter field
Shows the parameter name.
• ID field
Shows the parameter ID as a hexadecimal number.
• R/W field
Shows "R" to indicate that an IPR (Individual Parameter Request) read operation (Read) is
possible or "W" to indicate that an IPS (Individual Parameter Send) write operation is possible.
• Block field
Shows the bit field allocation of the block number. The bit field position is shown as a decimal
format number.
• Size field
Shows the parameter bit width as a decimal format value.
• Array field
Shows the parameter array size as a hexadecimal value.
• Min-Def-Max field
Shows the minimum value, default value, and maximum value for parameter acquisition as a
hexadecimal value.
• Description field
Explains the meaning of parameter values. Unless otherwise specified, setting values are all indi-
cated in decimal format.
20

System Parameters

These parameters make it possible for an external device to check the status of the Instrument and for
an external device to command some operation of the Instrument.
20.1

System Information Parameter

This parameter is a container for system information.
Parameter ID
Model Name 0000
General Register 000D R/W
R/W Block Size Array Min-Def-Max Description
R 00000000 7 08
↑
8 01
00-20-7F Ascii Character
XW-P1..."XW-P1"
XW-G1..."XW-G1"
00-00-FF General-purpose register for communication test
63
