- Page 1 LAGAN...
- Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
- Page 3 GB ENGLISH LANGUAGE COUNTRY...
-
Page 4: Table Of Contents
Gas connection Product description Energy efficiency Daily use Environmental concerns Hints and tips IKEA guarantee Care and cleaning Troubleshooting Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage. - Page 5 ENGLISH WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. If the appliance has a child safety device, it should be • activated.
-
Page 6: Safety Instructions
ENGLISH Disconnect the appliance from the electrical supply before • maintenance. Do not use a steam cleaner to clean the appliance. • If the supply cord is damaged, it must be replaced by the • manufacturer, the Authorised Service Centre or similarly qualified persons in order to avoid a hazard. - Page 7 ENGLISH Electrical Connection fuses removed from the holder), earth leakage trips and contactors. Warning! Risk of fire and electric • The electrical installation must have an shock. isolation device which lets you disconnect the appliance from the mains at all poles. •...
- Page 8 ENGLISH • Used oil, that can contain food remnants, Caution! The use of a gas cooking can cause fire at a lower temperature appliance results in the than oil used for the first time. production of heat, moisture and • Do not put flammable products or items products of combustion in the that are wet with flammable products in, room in which it is installed.
-
Page 9: Installation
ENGLISH • Clean the appliance regularly to prevent • Use original spare parts only. the deterioration of the surface material. Disposal • Deactivate the appliance and let it cool down before you clean it. Warning! Risk of injury or • Disconnect the appliance from the suffocation. - Page 10 ENGLISH The hob should not be installed in a bed You must observe the minimum sitting room with a volume of less than 20 distances to other appliances and m³. If it is installed in a room of volume less furniture cabinets or other units than 5 m³...
-
Page 11: Product Description
ENGLISH For further information on the installation refer to the Assembly Instruction. Product description Cooking surface layout Auxiliary burner Semi Rapid burner Rapid burner Semi Rapid burner Removable pan supports Semi Rapid burner control knob Semi Rapid burner control knob Rapid burner control knob Auxiliary burner control knob Burner control knob... -
Page 12: Hints And Tips
ENGLISH To ignite the burner: If there is no electricity, you can ignite the burner without an 1. Push the control knob and turn it electrical device. In this case, anticlockwise to the maximum position approach the burner with flame, marked with push the relevant knob and turn it 2. -
Page 13: Care And Cleaning
ENGLISH Diameters of cookware Minimum di‐ Maximum di‐ Keep the cookware centered on Burner ameter of ameter of pots the pan supports. pots and pans and pans Back left Use pots and pans with bottom (Semi-rap‐ fitting the size of burner used. Minimum di‐... -
Page 14: Troubleshooting
IKEA store call centre. You can find a full is not free of charge, even during list of IKEA appointed contacts at the end of the warranty period. - Page 15 PI-000000-0 21552 000.000.00 0476 MOD: Made In Italy G2X CXX mbar = XXkW G3X CXX mbar = XXXg/h © Inter IKEA Systems B.V. 2021 Max Power = 6W TYPE H0000-0/0 PNC. 000000000 00 00000000000000000 S.N.: 00000000 220-240 V 50-60 Hz...
-
Page 16: Electrical Connection
ENGLISH bag inserted inside the hob packaging. This will need in future our assistance. Thank you will allow us to assist you better, by for your help! identifying precisely your hob, in case you Electrical connection Electrical Requirements Warning! Refer to Safety chapters. -
Page 17: Gas Connection
ENGLISH Green and yellow - Earth Replacement of the connection cable Blue - Neutral Warning! To replace the Brown - Live connection cable, the technician must have a specific equipment. 1. Connect the green and yellow (earth) wire to the terminal in the plug which is In this case, only cable type H03V2V2-F T90 marked with the letter 'E' or the earth must be used. - Page 18 ENGLISH Warning! When you finish the If the feeding gas pressure is installation, check the sealing and different or variable from the pipe fixing. To check the required one, you must install an installation, use soapy water. Do appropriate pressure adjuster, not use the flame.
-
Page 19: Energy Efficiency
Service Provider. 6. Repeat this procedure for all burners. 7. Reassemble the gasket and the knobs. Energy efficiency Product information according to UK Ecodesign Regulation Model identification LAGAN 605.220.92, LAGAN 805.231.99 Type of hob Built-in hob Number of gas burners... -
Page 20: Environmental Concerns
IKEA kitchen furniture or for clarification on functions of For quicker service, always refer to the IKEA the IKEA appliances, please contact your article name and number (8-digit code) nearest IKEA Customer Support Centre, the found on the rating plate of your appliance. - Page 21 Magyarország 06-1-252-1773 Belföldi díjszabás Hétköznap 8.00 és 17.00 óra között 050-7111267 ma-vr: 8.00 - 21.00 Nederland Geen extra kosten. (0900-BEL IKEA) zat: 9.00 - 21.00 Luxembourg +31 507111267 Alleen lokaal tarief. zon / pub. vakantie: 10.00 - 18.00 (internationaal) Norge l i t Österreich...
