- Page 1 Assembly Instructions (W x D x H) 1.60m x 0.80m x 2.10m Product Name: Sunset Arch PLEASE KEEP THIS INSTRUCTION Zest4Leisure 01352 752555 option 1 – sales@zest4leisure.co.uk...
- Page 2 Sunset Arch Assembly Instructions Requires 2 person assembly. All screw holes to be pre-drilled. Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit, Tape Measure. Sunset Arch Pack List Item Description Quantity Rail Rafter Post/Trellis Assembly...
- Page 3 Repeat procedure for remaining Post/Trellis Assembly. Ensuring Post/Trellis Assembly C is perpendicular to Rails A, position Bracings D as shown in Figs.3a & 3b and fix using 4no 50mm Screws – 2no per bracing. Repeat procedure for remaining bracings. Sunset Arch is now complete.
