ITALTINTO COLOR DISPENSER i302 – i352
This manual forms an integral part of the machine and it shall always be kept available to operators working on the same
machinery; the manual shall always accompany the machine, also when this is sold to another user..
Operators must read this manual and carefully follow the indications contained herein, as the manufacturer
will not be liable for damages caused to people and/or objects or suffered to the machinery, should the
conditions reported below not be respected.
The Client shall respect the trade secret, therefore the following documentation and annexes cannot be altered neither modified,
reproduced nor transferred to third parties, without the manufacturer's authorization
Dispenser machine
User's manual
Serial N. ITE000..........
"Translation from original instructions in Italian language"
Italtinto Europe S.r.l.
Sede Legale: V.le Andrea Doria, 7 – 20124 Milano
Unità operativa: Via Zibido, 3 -20080 Zibido S. Giacomo (MI) ITALIA
Tel. +39 02.9000.5234 - Fax +39 02.9000.5242
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ITALTINTO i302
Summary of Contents for ITALTINTO i302
- Page 1 ITALTINTO COLOR DISPENSER i302 – i352 Dispenser machine User’s manual Serial N. ITE000..“Translation from original instructions in Italian language” This manual forms an integral part of the machine and it shall always be kept available to operators working on the same machinery;...
-
Page 2: Table Of Contents
Stop Drop maintenance ........................... 24 Fuses replacement............................25 Troubleshooting .............................. 26 Spare parts request form ..........................28 Table A ................................29 Table B ................................30 Table C ................................31 Electrical scheme ............................. 32 Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 3: Warranty And Supply Conditions
The manufacturer will not be liable for materials being processed, neither for damages that the latter can cause to the staff or environment. The Manufacturer WILL NOT be liable for the disposal of the products intended for the operation, maintenance of the machine or production. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 4: The Manual And Receivers
The staff who interacts with the machine shall always use the personal protection equipment foreseen by the laws applicable in the destination country, and any other safety equipment provided by the employer, such as: masks, gloves, safety shoes, etc… Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 5: Standard Reference
• UNI EN 349: 2008 Safety of the machinery – Minimum gaps to avoid crushing of parts of the human body. • IEC EN 60204-1: 2006 Safety of the machinery - Electrical equipment of machines. Part 1: General requirements. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 6: Symbols And Sign
Prohibition to remove the machine’s safety features. Do not operate or carry out maintenance services on the machine with removed or open guards. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 7 Generic warning Warning for installer 1500W/ 6,5A (220-240V) 400W 3,5A(100-120V) Max power multi socket Marking plate Danger Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 8: Field Of Use
-use machine parts or systems, connecting them to other equipment. N.B. The machine IS NOT equipped to be installed in an explosion-proof environment. The Manufacturer declines any liability for any damage caused by improper or imprudent operations Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 9: Characteristics
Allowed ambient temperature………………………………………………………............5 ÷ 40 ° C Maximum relative humidity allowed without condensation………………………….……………………………………..…. 30 ÷ 90 % Pollution degree……………………………………………..………....................2 Installation ……………………………………………………………….……..................II Altitude ………………..........................2000 m (max) Indoor use only PC connection…………………………………………….....................RS 232 / USB Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 10 The tags must be cleaned on a regular basis and always kept well visible, meaning NOT HIDDEN with foreign objects and parts (cloths, boxes, equipment, etc.). The technical data included in this manual does not replace the information indicated on the tags on-board the machine. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 11: Machine Description
13 to mix the colorant inside canister 01. The step-controlled motor lifts and lowers stems 17 simultaneously, all secured to a single upper disc, through a recycling ball worm screw 16. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 12 The blade moves like a 'fish tail' mixing the colorant avoiding air bubbles and foam. Each canister is equipped with a motor to drive the blade, the mixing time and intervals are managed by software. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
- Page 13 Pwer supply for PC and monitor is provided by a multi socket 1500W/ 6,5A (220-240V) 400W /3,5A 100-120V (not available for cMET US). In front of machine is available a useful USB port to connect devices without opening panels. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 14: Accident Prevention
The work station must be properly lit to ensure the safety of all work and maintenance operations. The Manufacturer WILL NOT be liable for the disposal of the products intended for the operation, maintenance of the machine or production: colorants, solvents, exhausted lubricants, batteries, etc… Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 15 A proper cleaning of the work area may prevent accidents or unnecessary risks. Any colorant leak, even if small, may pose a hazard. Any foreign body not belonging to the machine (e.g. wrenches, bolts, screwdrivers, etc.) must always be kept away from the machine Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 16: Lifting And Transport
Manufacturer. Remove the side panels, unscrew butterfly bolts on the floor, push down the blocks and remove the machine from the pallet Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 17: Installation
The plug must be plugged into an outlet that is properly installed and grounded in accordance with all local codes and ordinances. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 18 USB cable, recommended not longer than 5 mt. Turn the machine on, install software PROSCAN or MATCHSCAN. After installation you should find a new COM port installed, it is the mainboard driver. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 19: Equipment
11 BUSY: the busy light 11 indicates that the machine is busy in operations and disabled to receive commands 12 PUSH PEDAL to unlock the can holder lifter Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 20: Start-Up
Groups are composed of 8 canister each, starting from N. 1 (e.g. canister 1-8 are of same group, 9- 16 are of same group) See software manual to configure group mixing intervals. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 21: Maintenance
Please remember that grease and lubricant residues may pose a hazard. The same applies for colorants and/or detergents used to operate or maintain the machine Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 22: Periodical Checks
Inspect the entire machine and perform a complete and accurate review after approx. five years of activity. For this purpose, contact the Manufacturer or one of his Service Agents. 10.000 h Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 23: Canister Replacement
10. To re assemble the canister, just place it on the support plate and push it in order to insert the nozzle into the manifold with care WARNING: Prevent any colorant leaks and clean if any leaks are present. Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 24: Stop Drop Maintenance
3. Once a year, clean and grease the rails To open and close the device, use the button in the SETUP page of the software, disconnect power pressing STOP emergency button Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 25: Fuses Replacement
Fuse (1) T4AL250V 220V IN Fuse (1) T6.3AL250V 110V IN Fuse (2) T10AL250V – 48÷60V Fuse (3) T10AL250V –24÷28V Fuse (4) T2AL250V – 12÷15 V pull the drawer to remove the fuse Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... -
Page 26: Troubleshooting
STOP emergency button is pressed Check the STOP button Lifter buttons are not enabled Lifter is not pushed properly Push the lifter completely Lifter Micro switch Check the integrity of the micro switch Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 27 Supports ..................Cast iron/steel/FE52 Bearings......................Steel Seals…………………........Rubber/ teflon/ Viton/Vulkolan/Kevlar Electric cables and sheaths.............. copper/Rubber Resistors…………………............ Copper/ Steel/ Ceramic Printed circuits……………………........Copper/ Tin/ Acids/ Resins Packaging………………………………..........Wood/ paper Working and maintenance materials…........Exhausted lubricants Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 28: Spare Parts Request Form
-Machine model -Serial no. -Document, page and component code -Description of the component -Required quantity -For electrical material, indicate the voltage (Volt) and frequency (Hz) Table N. Component description quantity Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 29 Table A 1 Pump group assembly 2 Step Motor 3 Joint 4 Micro switch 5 Endless screw + bearings assembly 6 Pumps moving disk 7 Nozzles manifold 8 Stop Drop assembly Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
- Page 30 11 Side panel 4 Canister 12 Emergency stop button 5 Nozzles manifold 13 Main switch 6 Stop Drop assembly 14 Ready Busy lights board 7 Photocells 15 Push pedal kit Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
- Page 31 Table C Mixing paddle assembly Piston pump Paddle rod guide assembly Solenoid Bush By-pass rod Nozzle Canister cap Mixing motor assembly 10 Connecting rod 11 Paddle 12 Bottom paddle Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
-
Page 32: Electrical Scheme
Electrical scheme standard mixing Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018... - Page 33 FT mixing Italtinto Dispenser i302 – i352 Release 2 – 06/ 2018...
