ITALTINTO MANUAL DISPENSER i50
This manual forms an integral part of the machine and it shall always be kept available to operators working on the same machinery;
the manual shall always accompany the machine, also when this is sold to another user.
Operators must read this manual and carefully follow the indications contained herein, as the manufacturer
will not be liable for damages caused to people and/or objects or suffered to the machinery, should the
conditions reported below not be respected.
The Client shall respect the trade secret, therefore the following documentation and annexes cannot be altered neither modified,
reproduced nor transferred to third parties, without the manufacturer's authorization
User's manual
"Translation from original instructions in Italian language"
Italtinto Europe S.r.l.
Sede Legale: V.le Andrea Doria, 7 – 20124 Milano
Unità operativa: Via Zibido, 3 -20080 Zibido S. Giacomo (MI) ITALIA
Tel. +39 02.9000.5234 - Fax +39 02.9000.5242
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ITALTINTO i50
Summary of Contents for ITALTINTO i50
- Page 1 ITALTINTO MANUAL DISPENSER i50 User’s manual “Translation from original instructions in Italian language” This manual forms an integral part of the machine and it shall always be kept available to operators working on the same machinery; the manual shall always accompany the machine, also when this is sold to another user.
-
Page 2: Table Of Contents
Purge the air in the pumps by dispensing 5-6 times at least one Ounce (Y) of colorant ......14 Pump purge ..............................14 Colorant Agitation ............................16 Dispense ................................ 16 Maintenance ............................... 17 Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 3: Warranty And Supply Conditions
The manufacturer will not be liable for materials being processed, neither for damages that the latter can cause to the staff or environment. The Manufacturer WILL NOT be liable for the disposal of the products intended for the operation, maintenance of the machine or production. Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 4: The Manual And Receivers
The staff who interacts with the machine shall always use the personal protection equipment foreseen by the laws applicable in the destination country, and any other safety equipment provided by the employer, such as: masks, gloves, safety shoes, etc… Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 5: Symbols And Sign
Prohibition to remove the machine’s safety features. Do not operate or carry out maintenance services on the machine with removed or open guards. Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... - Page 6 Maintenance operations must be performed by specialized service staff marking plate generic warning Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020...
-
Page 7: Field Of Use
-use machine parts or systems, connecting them to other equipment. N.B. The machine IS NOT equipped to be installed in an explosion-proof environment. The Manufacturer declines any liability for any damage caused by improper or imprudent operations Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 8: Characteristics
③ Pump housing, mandrel and other components are all made with stainless steel. ④ Colorant canisters are fabricated with high quality engineering plastics, resisting to corrosion and anti- solvent, translucent canister cap provides visual monitoring for colorant level. Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... - Page 9 – 2/48 micro-adjustment scale with red end cap 1=1 ml micro-adjustment scale with red end cap 1=1/48 divided in 10 x 0,1ml divided in 8 1/384 Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020...
-
Page 10: Accident Prevention
The work station must be properly lit to ensure the safety of all work and maintenance operations. The Manufacturer WILL NOT be liable for the disposal of the products intended for the operation, maintenance of the machine or production: colorants, solvents, exhausted lubricants, batteries, etc… Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... - Page 11 The staff must wear the clothing and personal protection equipment provided by the employer: masks, gloves, safety shoes, etc…The staff must not wear clothing items with long sleeves, laces or belts that may jeopardize their safety. Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020...
-
Page 12: Lifting And Transport
INSTALL a differential magneto-thermal switch upstream the general switch 08 supplied by the Manufacturer of suitable power (30 mA) check the grounding connection Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 13: Assembly
(Figure 8), disconnect power (power indicator turns off), rotate the rotary tray by hand in a steady, smooth motion. The rotary tray dowel pins should be now detached with the locating pin holes enabling the rotation of the rotary tray. Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 14: Rotary Tray Rotation Process
Push down the black bottom to unlock the scale with one hand, lower the scales gently with the other hand (attention: scales are precision components, please do not lower scales free handed as it would be damaged by the impulsive force from free falling!) Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... - Page 15 Jack up Hold piston hand down grip Fig. 13 Fig. 14 Release the Push valve hand down the grip piston jack to the Counter clockwise Fig. 15 Fig. 16 Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020...
-
Page 16: Colorant Agitation
Raise the piston to zero on the black scale, rotate the valve fully and push the piston all the way to dispense the colorant into the container. Release the valve to close the nozzle. Dispenses up to 10/48 must be performed using the red precision scale Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... -
Page 17: Maintenance
1. The mark label on the scales, canisters, other plastics and digital display on all dispensers can be cleaned with dry cloth, never clean the machine with acetone or other solvent base cleaners. Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020... - Page 18 (Figure 22) nozzle rubber band (Figure 23) replacing nozzle (Figure 24) nozzle washer (Figure 25) unscrew on the cover (Figure 26) lubricate around the eccentric wheel Italtinto dispenser i50 - user’s manual ENG Rev.0 01/2020...
