Ortech ODDMF-ST Quick Start Manual

Smart Controller
MODEL ODDMF-ST
CAUTION
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
Electrical products can cause death or injury, or damage to property.
If in any doubt about the installation or use of this product, consult a competent technician.
SCREEN ICONS AND BUTTONS
Fan speed icon
Controller lock icon
Temperature
setting
Room temperature setting
Alarm
Setting
WALL INSTALLATION
1) Disconnect the fan mounting bracket from the back
wall of the smart controller. Using the holes in the
mounting bracket as a stencil, mark 2 dots on the wall
and pre-drill two holes for the included screws.
2) Use screws to attach the mounting bracket to the wall
with the two round mounting knobs pointing out and
away from the wall.
info@ortechindustries.com
www.ortechindustries.com
WARNING
WARNING — THE INSTALLATION MUST BE CARRIED OUT BY A QUALIFIED TECHNICIAN.
1. For use with EC motor fans
2. Please read the instructions before use
Power Mod Up Down
button button button button
Connect up to 4 fans
This smart speed controller can
manage up to 4 EC fans
simultaneously.
13376 Comber Way
Surrey BC V3W 5V9
Auto mode icon
Alarm icon
Manual mode icon
Temperature icon
375 Admiral Blvd
Mississauga ,
ON L5T 2N1
Instruction Manual
Auto Mode
In auto mode, this smart controller can
maintain your desired temperature level
by automatically adjusting the speed of all
connected fans.
Manual Mode
In manual mode, this smart controller can
maintain a constant speed on all
connected fans.
Thermal Probe
Each smart controller comes equipped
with a thermal probe, which allows the
controller to register temperature
changes in the surrounding environment.
3) Slide the controller
3) onto the round
3) mounting knobs
3) to secure it in place.
1-888-543-6473
1-888-541-6474
