2019-2078
2019-10-10
PRIMARY DEVICE LABEL
Chlorking Saline Chlorination System, Model NEXGEN
A maximum of 1,420,000 L of water can be treated with
Chlorking Saline Chlorination System, Model NEXGEN
Maximum output of hypochlorous acid equivalent to 11.34 kg of free available chlorine
For swimming pools, a range of 1.0 – 3.0 ppm of free available chlorine must be
For spas, a range of 3.0 – 5.0 ppm of free available chlorine must be maintained.
READ THE LABEL AND OPERATING MANUAL BEFORE USING
REGISTRATION NO. _33004
Warning: Operating the Chlorking Saline Chlorination system, Model NEXGEN, without
water flow through the cell can cause a buildup of flammable gases which can result in
WARNING: Do not use this device with bromide products.
NOTE TO USER: This pest control product is to be used only in accordance with the
directions on the label. It is an offence under the Pest Control Products Act, to use this
product in a way that is inconsistent with the directions on the label.
ATLANTA, GEORGIA, U.S.A, 30360. 1-800-536-8180
CHLORINE GENERATOR
CONTROLS BACTERIA AND ALGAE
in
Swimming Pool (and Spa) Waters
COMMERCIAL
per day
maintained.
KEEP OUT OF REACH OF CHILDREN
FIRE OR EXPLOSION
CHLORKING INC.
2935 NORTHEAST PARKWAY
PEST CONTROL PRODUCT ACT
Advertisement
Table of Contents
Related Manuals for ChlorKing NEXGEN
Summary of Contents for ChlorKing NEXGEN
- Page 1 READ THE LABEL AND OPERATING MANUAL BEFORE USING REGISTRATION NO. _33004 PEST CONTROL PRODUCT ACT Warning: Operating the Chlorking Saline Chlorination system, Model NEXGEN, without water flow through the cell can cause a buildup of flammable gases which can result in FIRE OR EXPLOSION WARNING: Do not use this device with bromide products.
- Page 2 REGISTRATION NO. _33004 PEST CONTROL PRODUCTS ACT This electrode must only be used on this model of chlorine generating device. READ THE LABEL AND REFER TO OWNERS MANUAL OF THE Chlorking saline Chlorination System, Model NEXGEN BEFORE USING. CHLORKING INC.
- Page 3 OWNER MANUAL USER’S GUIDE MODEL NEXGEN...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION… ................... 4 WARRANTY INFORMATION ..............5 SAFETY INFORMATION… ..............6-7 PREPARING YOUR WATER BEFORE INSTALLATION… ....8-9 SALT CHART FOR CORRECT MAINTENANCE ........10 TOOLS AND PARTS REQUIRED FOR INSTALLATION ....... 11 PLUMBING YOUR SYSTEM ..............12 ELECTRICAL SPECIFICATION…... -
Page 5: Introduction
INTRODUCTION ChlorKing 2935 NORTHEAST PARKWAY ATLANTA, GEORGIA, U.S.A, 30360. 1-800-536-8180 Patent # US 6821398B2 EPA Est. # 082229-GA-001 NSF-50 / UL-1081 listed Congratulations on purchasing your new ChlorKing Saline Chlorination System, we trust that this system will offer you the ultimate in swimming environments, and give you years of trouble free operation. -
Page 6: Warranty Information
WARRANTY INFORMATION ChlorKing® system carries a limited 3 year warranty 1. 3 year warranty on assembly of electrical components and cell housing. 2. 1 year on all electrical items. 3. 2 years or 15,000 hours, which ever occurs first, pro-rated hourly, on titanium electrodes. -
Page 7: Safety Information
SAFETY INFORMATION PLEASE READ THE FOLLOWING SAFETY INFORMATION CAREFULLY! WARNING! • Only a certified technician may install and service your ChlorKing® system. • Modifying your ChlorKing® system in anyway may cause bodily injury and will void your warranty. • Warning: To reduce the risk of injury, do not allow children to operate this device. - Page 8 • When replacing the cell, only use replacement cells having a label that clearly states that it is a replacement cell for the chlorine generating device ChlorKing Saline Chlorination System, Model NEXGEN, REGISTRATION NUMBER , PEST CONTROL PRODUCTS ACT. • Follow all aspects of the local and National Electrical Code(s) when installing ChlorKing model NEXGEN.
-
Page 9: Preparing Your Water Before Installation
PREPARING YOUR WATER BEFORE INSTALLATION ChlorKing® saline chlorination systems operate by utilizing the sodium chloride that has been added to the pool water, to produce sodium hypochlorite (liquid chlorine), through the process of electrolysis. In order for your ChlorKing® system to operate correctly, sodium chloride (salt) can be added directly to the pool at least 24 hours before the installation of the equipment. - Page 10 Use standard test kits to check water chemistry, and use either a conductivity tester or salt test strip to check saline levels. (Note that most conductivity testers require frequent calibration to ensure accurate readings, failure to calibrate the equipment will result in inaccurate readings.) How to Calculate volume of a pool For a rectangular shaped pool...
-
Page 11: Salt Chart For Correct Maintenance
2017-2433 2018-FEB-12 The following is a chart to determine the amount of salt required to raise a pool or spa to 5000 ppm SALT CHART FOR CORRECT MAINTENANCE ppm Salt Levels Number of KG's of Salt to Be Added ppm Salt Pool and or spa Volume (litres) 1,000 100,000... -
Page 12: Tools And Parts Required For Installation
2017-2433 2018-FEB-12 TOOLS AND PARTS REQUIRED FOR INSTALLATION Your ChlorKing® system will include an installation kit comprising of the following items: Description Strainer clear bowl with 20 mesh PVC ball valve Sch. 40 PVC male adaptor Sch. 40 PVC nipple SCH 80... -
Page 13: Plumbing Your System
PLUMBING YOUR SYSTEM 1. Your ChlorKing® system requires a minimum of 300 Lpm of flow through the venturi to produce the rated amount of chlorine. 2. If you elect to use the bypass plumbing method, you will need to purchase a butterfly valve based on the size of the pipe you are using. -
Page 14: Electrical Specification
• Model NEXGEN operates at 208 – 240v requiring advanced wiring, which should only be done by a qualified electrician. 208 – 240v power needs to be run from your main breaker panel to a safety switch, then into the ChlorKing®... -
Page 15: General Operation
7.5 litres / min = 11.34 kg per day Normal operating amps and volts for this model device are: NEXGEN - 100amps @ 23v • Water flow through the ChlorKing®... -
Page 16: Maintenance And Cleaning
** Remember, your ChlorKing® system is a chlorine generator, and will only operate as well as you maintain it. Careful attention must always be paid to proper chemical balancing, and regular service. MAINTENANCE AND CLEANING Your ChlorKing® systems is designed to operate 24/7 at max power, and will give you years of trouble free use if you follow these basic maintenance and cleaning instructions.
