2019-2076
2019-10-10
For swimming pools, a range of 1.0 - 3.0 ppm of free available chlorine
For spas, a range of 3.0 - 5.0 ppm of free available chlorine must be maintained.
READ THE LABEL AND OPERATING MANUAL BEFORE USING
WARNING: Operating the ChlorKing Saline Chlorination System, Model CHLOR-5.0,
without water flow through the cell can cause a buildup of flammable gases
WARNING: Do not use this device with bromide products.
NOTICE TO USER: This pest control product is to be used only in accordance with the
directions on the label. It is an offence under the Pest Control Products Act, to use
this product in a way that is inconsistent with the directions on the label.
ChlorKing Saline Chlorination System, Model CHLOR-5.0
CHLORINE GENERATOR
CONTROLS BACTERIA AND ALGAE
Swimming Pool (and Spa) Waters
A maximum of 283,900 L of water can be treated with
ChlorKing Saline Chlorination System, Model CHLOR-5.0
Maximum output of hypochlorous acid equivalent to 2.268 kg
of free available chlorine per day
KEEP OUT OF REACH OF CHILDREN
REGISTRATION NO. 29088 PEST CONTROL PRODUCTS ACT
which can result in FIRE OR EXPLOSION.
CHLORKING INC,
2935 NORTHEAST PARKWAY
ATLANTA, GEORGIA, U.S.A, 30360. 1-800-536-
8180
in
COMMERCIAL
must be maintained.
Advertisement
Table of Contents
Related Manuals for ChlorKing CHLOR-5.0
Summary of Contents for ChlorKing CHLOR-5.0
- Page 1 READ THE LABEL AND OPERATING MANUAL BEFORE USING REGISTRATION NO. 29088 PEST CONTROL PRODUCTS ACT WARNING: Operating the ChlorKing Saline Chlorination System, Model CHLOR-5.0, without water flow through the cell can cause a buildup of flammable gases which can result in FIRE OR EXPLOSION.
- Page 2 2019-2076 2019-10- Titanium Electrode Replacement Electrode for the ChlorKing Saline Chlorination System, Model CHLOR-5.0 REGISTRATION NO. 29088 PEST CONTROL PRODUCTS ACT This electrode must only be used on this model of chlorine generating device. READ THE LABEL AND REFER TO OWNER'S MANUAL OF THE ChlorKIng Saline Chlorination System, Model CHLOR-5.0, BEFORE USING.
- Page 3 2019-2076 2019-10- USER’S GUIDE MODEL CHLOR-5.0...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION… ................... 4 WARRANTY INFORMATION… ..............5 SAFETY INFORMATION… ..............6-7 PREPARING YOUR WATER BEFORE INSTALLATION… ....8-9 SALT CHART FOR CORRECT MAINTENANCE… ........ 10 TOOLS AND PARTS REQUIRED FOR INSTALLATION… ....11 INSTALLING YOUR SYSTEM – PLUMBING… ........12-13 ELECTRICAL…... - Page 5 READ THE LABEL AND OPERATING MANUAL BEFORE USING REGISTRATION NO. 29088 PEST CONTROL PRODUCTS ACT WARNING: Operating the ChlorKing Saline Chlorination System, Model CHLOR-5.0, without water flow through the cell can cause a buildup of flammable gases which can result in FIRE OR EXPLOSION.
-
Page 6: Introduction
Titanium Electrode Replacement Electrode for the ChlorKing Saline Chlorination System, Model CHLOR-5.0 REGISTRATION NO. 29088 PEST CONTROL PRODUCTS ACT This electrode must only be used on this model of chlorine generating device. READ THE LABEL AND REFER TO OWNER'S MANUAL OF THE ChlorKIng Saline Chlorination System, Model CHLOR-5.0, BEFORE USING. -
Page 7: Warranty Information
WARRANTY INFORMATION ChlorKing® system carries a limited 3 year warranty 1. 3 year warranty on assembly of electrical components and cell housing. 2. 1 year on all electrical items. 3. 2 years or 15,000 hours, which ever occurs first, pro-rated hourly, on titanium electrodes. -
Page 8: Safety Information
SAFETY INFORMATION PLEASE READ THE FOLLOWING SAFETY INFORMATION CAREFULLY! WARNING! • Only a certified technician may install and service your ChlorKing® system. • Modifying your ChlorKing® system in anyway may cause bodily injury and will void your warranty. • Warning: To reduce the risk of injury, do not allow children to operate this device. - Page 9 • When replacing the cell, only use replacement cells having a label that clearly states that it is a replacement cell for the chlorine generating device ChlorKing Saline Chlorination System, Model CHLOR-5.0, REGISTRATION NUMBER 29088, PEST CONTROL PRODUCTS ACT. • Follow all aspects of the local and National Electrical Code(s) when installing ChlorKing model CHLOR-5.0.
-
Page 10: Preparing Your Water Before Installation
PREPARING YOUR WATER BEFORE INSTALLATION ChlorKing® saline chlorination systems operate by utilizing the sodium chloride that has been added to the pool water, to produce sodium hypochlorite (liquid chlorine), through the process of electrolysis. In order for your ChlorKing® system to operate correctly, sodium chloride (salt) must be added directly to the pool at least 24 hours before the installation of the equipment. - Page 11 Use standard test kits to check water chemistry, and use either a conductivity tester or salt test strip to check saline levels. (Note that most conductivity testers require frequent calibration to ensure accurate readings, failure to calibrate the equipment will result in inaccurate readings.) How to Calculate volume of a pool For a rectangular shaped pool...
-
Page 12: Salt Chart For Correct Maintenance
The following is a chart to determine the amount of salt required to raise a pool or spa to 5000 ppm SALT CHART FOR CORRECT MAINTENANCE ppm Salt Levels Number of KG of Salt to Be Added ppm Salt Pool and or spa Volume (litres) 1,000 100,000 200,000... -
Page 13: Tools And Parts Required For Installation
TOOLS AND PARTS REQUIRED FOR INSTALLATION Your ChlorKing® system will include an installation kit comprising of the following items: Description Strainer clear bowl with 20 mesh PVC ball valve Sch. 40 PVC male adaptor Sch. 40 PVC nipple SCH 80... -
Page 14: Installing Your System - Plumbing
PLUMBING YOUR SYSTEM Your ChlorKing® system can be plumbed using two different methods. Both will work fine, however, the following must be taken into account before making the decision of what method to use. 1. Your ChlorKing® system requires a minimum of 75 Lpm of flow through the cell to produce the rated amount of chlorine. - Page 15 PRESSURE-DROP PLUMBING METHOD [1] ChlorKing® power supply ChlorKing® cell NOTES: THE RECTIFIER COOLING LINES MUST BE CONNECTED FROM THE SUCTION SIDE OF THE PUMP AND AFTER THE FILTER. ALWAYS USE FILTERED WATER. IF THERE IS A CONTROLLER PRESENT, THE OUTLET LINE THAT FEEDS THE CONTROLLER PROBES COULD BE CONNECTED TO THE RECTIFIER.
-
Page 16: Electrical
• Model CHLOR-5.0 operates at 110 – 120v. A power cord will be supplied out of the power box. Plug this into any standard 110 – 120v outlet. As above, the cord labeled ORP must be plugged into a controller, or a 120v outlet. -
Page 17: Starting The System
STARTING THE SYSTEM Once your ChlorKing® system has been successfully wired and plumbed, it is ready for use. • Make sure that the valves to and from the cell are in the open position. • Make sure that you have water flowing through the water-cooled heat sink in box 3. -
Page 18: General Operation
1, you will notice the amperage needle of the gauge on box 3 increases or decreases. Higher amperage = higher chlorine production. Normal operating amps and volts for this model device are: Chlor-5.0 - 25 amps @ 15v • Water flow through the ChlorKing®... -
Page 19: Maintenance And Cleaning
MAINTENANCE AND CLEANING Your ChlorKing® system is designed to operate 24/7 at max power, and will give you years of trouble free use if you follow these basic maintenance and cleaning instructions. • Remember, this system produces sodium hypochlorite “liquid chlorine”... - Page 20 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
