ChlorKing CHLOR-2.0 User Manual

Saline chlorination system chlorine generator

Advertisement

2010-2077
2019-10-10
For swimming pools, a range of 1.0 - 3.0 ppm of free available chlorine
For spas, a range of 3.0 - 5.0 ppm of free available chlorine must be maintained.
READ THE LABEL AND OPERATING MANUAL BEFORE USING
REGISTRATION NO. 29541 PEST CONTROL PRODUCT ACT
WARNING: Operating the ChlorKing Saline Chlorination System, Model CHLOR-2.0,
without water flow through the cell can cause a buildup of flammable gases
NOTE TO USER: This pest control product is to be used only in accordance with the
directions on the label. It is an offence under the Pest Control Products Act, to use
this product in a way that is inconsistent with the directions on the label.
ChlorKing Saline Chlorination System, Model CHLOR-2.0
CHLORINE GENERATOR
CONTROLS BACTERIA AND ALGAE
Swimming Pool (and Spa) Waters
COMMERCIAL
A maximum of 113,600 L of water can be treated with
ChlorKing Saline Chlorination System, Model CHLOR-2.0
Maximum output of hypochlorous acid equivalent to 0.896 kg
of free available chlorine per day
must be maintained.
KEEP OUT OF REACH OF CHILDREN
which can result in FIRE OR EXPLOSION.
WARNING: Do not use this device with bromide products.
CHLORKING INC,
2935 NORTHEAST PARKWAY
ATLANTA, GEORGIA, U.S.A, 30360.1-800-536-8180
in

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHLOR-2.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for ChlorKing CHLOR-2.0

  • Page 1 READ THE LABEL AND OPERATING MANUAL BEFORE USING REGISTRATION NO. 29541 PEST CONTROL PRODUCT ACT WARNING: Operating the ChlorKing Saline Chlorination System, Model CHLOR-2.0, without water flow through the cell can cause a buildup of flammable gases which can result in FIRE OR EXPLOSION.
  • Page 2 USER’S GUIDE MODEL MINI-2.0...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION… ................... 4 WARRANTY INFORMATION… ..............5 SAFETY INFORMATION… ..............6-7 PREPARING YOUR WATER BEFORE INSTALLATION… ....8-9 SALT CHART FOR CORRECT MAINTENANCE… ........ 10 TOOLS AND PARTS REQUIRED FOR INSTALLATION… ....11 INSTALLING YOUR SYSTEM – PLUMBING… ........12-13 ELECTRICAL…...
  • Page 4 READ THE LABEL AND OPERATING MANUAL BEFORE USING REGISTRATION NO. 29541 PEST CONTROL PRODUCT ACT WARNING: Operating the ChlorKing Saline Chlorination System, Model MINI-2.0, without water flow through the cell can cause a buildup of flammable gases which can result in FIRE OR EXPLOSION.
  • Page 5: Introduction

    Titanium Electrode Replacement Electrode for the ChlorKing Saline Chlorination System, Model MINI-2.0 REGISTRATION NO. 29541 PEST CONTROL PRODUCTS ACT This electrode must only be used on this model of chlorine generating device. READ THE LABEL AND REFER TO OWNER'S MANUAL OF THE ChlorKing Saline Chlorination System, Model MINI-2.0, BEFORE USING.
  • Page 6: Warranty Information

    WARRANTY INFORMATION ChlorKing® system carries a limited 3 year warranty 1. 3 year warranty on assembly of electrical components and cell housing. 2. 1 year on all electrical items. 3. 2 years or 15,000 hours, which ever occurs first, pro-rated hourly, on titanium electrodes.
  • Page 7: Safety Information

    SAFETY INFORMATION PLEASE READ THE FOLLOWING SAFETY INFORMATION CAREFULLY! WARNING! • Only a certified technician may install and service your ChlorKing® system. • Modifying your ChlorKing® system in anyway may cause bodily injury and will void your warranty. • Warning: To reduce the risk of injury, do not allow children to operate this device.
  • Page 8 • When replacing the cell, only use replacement cells having a label that clearly states that it is a replacement cell for the chlorine generating device ChlorKing Saline Chlorination System, Model MINI-2.0, REGISTRATION NUMBER 29541, PEST CONTROL PRODUCTS ACT. • Follow all aspects of the local and National Electrical Code(s) when installing ChlorKing model MINI-2.0.
  • Page 9: Preparing Your Water Before Installation

    PREPARING YOUR WATER BEFORE INSTALLATION ChlorKing® saline chlorination systems operate by utilizing the sodium chloride that has been added to the pool water, to produce sodium hypochlorite (liquid chlorine), through the process of electrolysis. In order for your ChlorKing® system to operate correctly, sodium chloride (salt) must be added directly to the pool at least 24 hours before the installation of the equipment.
  • Page 10 Use standard test kits to check water chemistry, and use either a conductivity tester or salt test strip to check saline levels. (Note that most conductivity testers require frequent calibration to ensure accurate readings, failure to calibrate the equipment will result in inaccurate readings.) How to Calculate volume of a pool For a rectangular shaped pool...
  • Page 11: Salt Chart For Correct Maintenance

    The following is a chart to determine the amount of salt required to raise a pool or spa to 5000 ppm SALT CHART FOR CORRECT MAINTENANCE ppm Salt Levels Number of KG's of Salt to Be Added ppm Salt Pool and or spa Volume (litres) 1,000 100,000 200,000...
  • Page 12: Tools And Parts Required For Installation

    TOOLS AND PARTS REQUIRED FOR INSTALLATION Your ChlorKing® system will include an installation kit comprising of the following items: Description Strainer clear bowl with 20 mesh PVC ball valve Sch. 40 PVC male adaptor Sch. 40 PVC nipple SCH 80...
  • Page 13: Installing Your System - Plumbing

    PLUMBING YOUR SYSTEM Your ChlorKing® system can be plumbed using two different methods. Both will work fine, however, the following must be taken into account before making the decision of what method to use. 1. Your ChlorKing® system requires a minimum of 75 Lpm of flow through the cell to produce the rated amount of chlorine.
  • Page 14 PRESSURE-DROP PLUMBING METHOD [1] ChlorKing® power supply ChlorKing® cell NOTES: THE RECTIFIER COOLING LINES MUST BE CONNECTED FROM THE SUCTION SIDE OF THE PUMP AND AFTER THE FILTER. ALWAYS USE FILTERED WATER. IF THERE IS A CONTROLLER PRESENT, THE OUTLET LINE THAT FEEDS THE CONTROLLER PROBES COULD BE CONNECTED TO THE RECTIFIER.
  • Page 15: Electrical

    ELECTRICAL SPECIFICATIONS Each ChlorKing® model has very specific wiring requirements based on its line voltage and amperage draw. • Model MINI-2.0 operates at 110 – 120v. A power cord will be supplied out of the power box. Plug this into any standard 110 – 120v outlet. As above, the cord labeled ORP must be plugged into a controller, or a 120v outlet.
  • Page 16: Starting The System

    STARTING THE SYSTEM Once your ChlorKing® system has been successfully wired and plumbed, it is ready for use. • Make sure that the valves to and from the cell are in the open position. • Make sure that you have water flowing through the water-cooled heat sink in box 3.
  • Page 17: General Operation

    GENERAL OPERATION Your ChlorKing® system operates when power is activated by the main pumps, and from your ORP controller, and will continue to operate for as long as power is applied from those two sources. • The system has an output range of 5-100% of the rated chlorine production, and can be adjusted by turning the black knob of the side of box 1 in a clockwise or anti-clockwise motion.
  • Page 18: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Your ChlorKing® systems is designed to operate 24/7 at max power, and will give you years of trouble free use if you follow these basic maintenance and cleaning instructions. • Remember, this system produces sodium hypochlorite “liquid chlorine”...
  • Page 19 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
