SEMROC MX Orbital Transport KMX-01 Instructions

EXPLODED VIEW
A
C
D
5
F
13
11
12
G
G
L
O
G
6
2 1
4
7
14
3
9
L
10
8
H
K
I
I
PARTS LIST
A 1 Balsa Nose Cone ................................ BNC-3SC
B 1 Body Tube .......................................... BT-3-6.75
C 1 Balsa Nose Cone......................BNC-2G
D 1 Body Tube............................BT-2-2.5
E 1 Laser-cut Fin Set ............................... FMX-01
F 1 Glider Hook Set (2pcs).................FMX-01B
G 1 Glider Hook Cover Set..................LSKMX-01
H 2 Centering Rings .................................. RA-2-3
I 4 Launch Lugs..........................LL-2AM
J 1 Wood Dowel 1/12"x2.5" ....................... WD-13
K 1 Motor Tube ........................................ BT-2-1.25
L 2 Thrust Block ...................................... TB-2
M 1 Kevlar Cord ........................................ SCK-24
N 1 Streamer Pack ................................... SP-118
O 1 Launch Lug ........................................ LL-MX-1
P 1 Decal (Not Shown) .............................. DKMX-05
Q 1 Weight Clay (Not Shown)...............WC-1
R 1 Fin Alignment Tools (5 Pcs)............TKMX-01
(Not Shown)
Copyright © 2018 Semroc
www.semroc.com
