1. Materials. I will use only lightweight, non-metal parts for the nose,
body, and fins of my rocket.
2. Motors. I will use only certified, commercially-made model rocket
motors, and will not tamper with these motors or use them for any
purposes except those recommended by the manufacturer.
3. Ignition System. I will launch my rockets with an electrical launch
system and electrical motor igniters. My launch system will have a
safety interlock in series with the launch switch, and will use a launch
switch that returns to the "off" position when released.
4. Misfires. If my rocket does not launch when I press the button of
my electrical launch system, I will remove the launcher's safety inter-
lock or disconnect its battery, and will wait 60 seconds after the last
launch attempt before allowing anyone to approach the rocket.
5. Launch Safety. I will use a countdown before launch, and will
ensure that everyone is paying attention and is a safe distance of at
least 15 feet away when I launch rockets with D motors or smaller,
and 30 feet when I launch larger rockets. If I am uncertain about the
safety or stability of an untested rocket, I will check the stability be-
fore flight and will fly it only after warning spectators and clearing
them away to a safe distance.
6. Launcher. I will launch my rocket from a launch rod, tower, or rail
that is pointed to within 30 degrees of the vertical to ensure that the
rocket flies nearly straight up, and I will use a blast deflector to pre-
vent the motor's exhaust from hitting the ground. To prevent acciden-
tal eye injury, I will place launchers so that the end of the launch rod
is above eye level or will cap the end of the rod when it is not in use.
7. Size. My model rocket will not weigh more than 1,500 grams (53
ounces) at liftoff and will not contain more than 125 grams (4.4
ounces) of propellant or 320 N-sec (71.9 pound-seconds) of total
impulse. If my model rocket weighs more than one pound (453
grams) at liftoff or has more than four ounces (113 grams) of propel-
lant, I will check and comply with Federal Aviation Administration
regulations before flying.
8. Flight Safety. I will not launch my rocket at targets, into clouds, or
near airplanes, and will not put any flammable or explosive payload
in my rocket.
9. Launch Site. I will launch my rocket outdoors, in an open area at
least as large as shown in the accompanying table, and in safe
weather conditions with wind speeds no greater than 20 miles per
hour. I will ensure that there is no dry grass close to the launch pad,
and that the launch site does not present risk of grass fires.
10. Recovery System. I will use a recovery system such as a
streamer or parachute in my rocket so that it returns safely and un-
damaged and can be flown again, and I will use only flame-resistant
or fireproof recovery system wadding in my rocket.
11. Recovery Safety. I will not attempt to recover my rocket from
power lines, tall trees, or other dangerous places.
LAUNCH SITE DIMENSIONS
Installed Total Impulse
Equivalent Motor Type
(N-sec)
0.00 — 1.25
1.26 — 2.50
2.51 — 5.00
5.01 — 10.00
10.01 — 20.00
20.01 — 40.00
40.01 — 80.00
80.01 — 160.00
160.01 — 320.00
Minimum Site Dimensions
(ft.)
1/4A
50
A
100
B
200
C
400
D
500
E
1000
F
1000
G
1000
2 Gs
1500
24
NASA INSPIRED
EASY AND FUN
TO BUILD
EXCITING
FLIGHTS
BALSA
NOSE
CONES
Made in the U.S.A by Semroc Astronautics Corporation - Knightdale, N.C. 27545
Orbital Transport™
Kit No. KV-66
Specifications
Booster
Body Diameter 0.976" (2.5 cm)
Length
23.0" (58.4 cm) 8.6" (21.8 cm)
Fin Span
8.1" (20.6 cm)
Net Weight
1.8 oz. (51.1 g)
Glide/Parachute Recovery
TM
Designed by:
Wayne Kellner
Glider
Engines
0.736" (1.9 cm)
B6-4
C6-5
5.4" (13.7 cm)
0.5 oz. (14.2 g)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KV-66 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SEMROC KV-66

  • Page 1 11. Recovery Safety. I will not attempt to recover my rocket from power lines, tall trees, or other dangerous places. LAUNCH SITE DIMENSIONS Made in the U.S.A by Semroc Astronautics Corporation - Knightdale, N.C. 27545 Installed Total Impulse Equivalent Motor Type...
  • Page 2: Limitation Of Liability

    Estes Industries, Inc. roc products on these conditions. In July 1958, G. Harry Stine of Model Missiles, Your purchase and use of any Semroc products is Inc. in Denver, Colorado approached Vern Es- construed as your agreement to and acceptance of these terms.
  • Page 3: Before You Start

    $2.50. room left. The Semroc Retro-Repro™ Orbital Transport™  55. is very close to the original with some modern Fold the parachute and pack it and the changes.
  • Page 4: Parts Identification

    ASSEMBLY  51. After the paint has dried, decals should be applied. The decals supplied with the Orbital Trans- port™ are waterslide decals. Refer to the photo on  1. These instructions are presented in a logical the front and the diagram below for decal place- order to help you put your Orbital Transport™...
  • Page 5: Booster Assembly

    FINISHING  48. When the fillets have dried, prepare balsa for a smooth professional looking finish. Fill the wood grain with Fill’n’Finish, balsa fillercoat, or sanding sealer, When dry, sand with fine sandpa- per. Repeat until smooth. Don’t overdo it! Layers of unsanded filler can add much weight! ...
  • Page 6  45. Apply a thin bead of glue around the small end of the shroud and attach it to the center of the paper nose block on the end of the glider. When it is dry, run a heavier bead around the inside of the ring at the joint.
  • Page 7  41.  10. Attach the hold-down assembly to the Test the scramjet lower housing (5) for fit bottom of the glider even with the leading edge of against the scramjet engines and the housing parts. the wing and perpendicular to the body tube. It will Apply glue to the tops of the scramjet engines and project slightly over the nose cone.
  • Page 8: Engine Mount Assembly

    ENGINE MOUNT ASSEMBLY  37. Cut out the Glider Marking Guide from the pattern sheet. Wrap it around the glider body tube about 1/4” from one end. Hold it in place with  13. Using a hobby knife, punch a small 1/8” a small piece of tape.
  • Page 9  34.  17. Assemble chute using instructions When all the rings are in place and the printed on the canopy. Attach the chute to the knot is pulled up against the top ring, apply a fillet screw eye. of glue around all the joints, being careful to keep the outside surfaces of both rings free of glue.
  • Page 10  21.  31. Using a door facing, drawer, or piece of Apply glue to the root edge of one of the angle molding, draw a line from each mark. Lines J, rudders (13) and attach it to the line corresponding K, and L need to be 9”...
  • Page 11  28.  24. Apply glue to the root edge of one of the While the glue is setting on the wings, cut ventral fins (10) and attach it to Line J and even out the Booster Wing Alignment Template from the with the end of the main body tube.
  • Page 12: Exploded View

    EXPLODED VIEW Parts List A 1 Body Tube ......BT-50 B 1 Body Tube ......BT-20D C 1 Body Tube ......BT-20J D 4 Body Tubes ......BT-5T E 1 Balsa Nose Cone ....BNC-50Y F 1 Balsa Nose Cone ....BNC-20B G 2 Adapter Rings ....
