SEMROC MARS LANDER Manual

Model rocket kit

Advertisement

Quick Links

1. Materials. I will use only lightweight, non-metal parts for the nose,
body, and fins of my rocket.
2. Motors. I will use only certified, commercially-made model rocket
motors, and will not tamper with these motors or use them for any
purposes except those recommended by the manufacturer.
3. Ignition System. I will launch my rockets with an electrical launch
system and electrical motor igniters. My launch system will have a
safety interlock in series with the launch switch, and will use a launch
switch that returns to the "off" position when released.
4. Misfires. If my rocket does not launch when I press the button of
my electrical launch system, I will remove the launcher's safety inter-
lock or disconnect its battery, and will wait 60 seconds after the last
launch attempt before allowing anyone to approach the rocket.
5. Launch Safety. I will use a countdown before launch, and will
ensure that everyone is paying attention and is a safe distance of at
least 15 feet away when I launch rockets with D motors or smaller,
and 30 feet when I launch larger rockets. If I am uncertain about the
safety or stability of an untested rocket, I will check the stability be-
fore flight and will fly it only after warning spectators and clearing
them away to a safe distance.
6. Launcher. I will launch my rocket from a launch rod, tower, or rail
that is pointed to within 30 degrees of the vertical to ensure that the
rocket flies nearly straight up, and I will use a blast deflector to pre-
vent the motor's exhaust from hitting the ground. To prevent acciden-
tal eye injury, I will place launchers so that the end of the launch rod
is above eye level or will cap the end of the rod when it is not in use.
7. Size. My model rocket will not weigh more than 1,500 grams (53
ounces) at liftoff and will not contain more than 125 grams (4.4
ounces) of propellant or 320 N-sec (71.9 pound-seconds) of total
impulse. If my model rocket weighs more than one pound (453
grams) at liftoff or has more than four ounces (113 grams) of propel-
lant, I will check and comply with Federal Aviation Administration
regulations before flying.
8. Flight Safety. I will not launch my rocket at targets, into clouds, or
near airplanes, and will not put any flammable or explosive payload
in my rocket.
9. Launch Site. I will launch my rocket outdoors, in an open area at
least as large as shown in the accompanying table, and in safe
weather conditions with wind speeds no greater than 20 miles per
hour. I will ensure that there is no dry grass close to the launch pad,
and that the launch site does not present risk of grass fires.
10. Recovery System. I will use a recovery system such as a
streamer or parachute in my rocket so that it returns safely and un-
damaged and can be flown again, and I will use only flame-resistant
or fireproof recovery system wadding in my rocket.
11. Recovery Safety. I will not attempt to recover my rocket from
power lines, tall trees, or other dangerous places.
LAUNCH SITE DIMENSIONS
Installed Total Impulse
Equivalent Motor Type
(N-sec)
0.00 — 1.25
1.26 — 2.50
2.51 — 5.00
5.01 — 10.00
10.01 — 20.00
20.01 — 40.00
40.01 — 80.00
80.01 — 160.00
160.01 — 320.00
Minimum Site Dimensions
(ft.)
1/4A
50
A
100
B
200
C
400
D
500
E
1000
F
1000
G
1000
2 Gs
1500
FUTURISTIC PLANETARY
Designed by
Wayne Kellner
Made in the U.S.A by Semroc Astronautics Corporation - Knightdale, N.C. 27545
MARS LANDER™
Kit No. KV-54
Specifications
Body Diameter
3.74" (5.9cm)
Length
12.6" (31.9cm)
Fin Span
13.2" (33.5cm)
Net Weight
4.1 oz. (116.2g)
Parachute Recovery
MANNED VEHICLE
GREAT DEMO BIRD
FUN TO BUILD
AND FLY
WORKING SHOCK
ABSORBING GEAR
BALSA NOSE CONE
LASER-CUT
BODY PARTS
Skill Level 4
Master Modeler
Engine Approx. Altitude
B4-2
110'
B6-2
115'
C6-3
360'

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MARS LANDER and is the answer not in the manual?

Questions and answers

Summary of Contents for SEMROC MARS LANDER

  • Page 1 LAUNCH SITE DIMENSIONS Installed Total Impulse Equivalent Motor Type Minimum Site Dimensions Made in the U.S.A by Semroc Astronautics Corporation - Knightdale, N.C. 27545 (N-sec) (ft.) 0.00 — 1.25 1/4A MARS LANDER™...
  • Page 2: Limitation Of Liability

    In July 1958, G. Harry Stine of Model Missiles, Inc. in Denver, Colorado approached Vern Estes about Your purchase and use of any Semroc products is making model rocket engines for them. On January construed as your agreement to and acceptance of 15, 1959, Vern’s automated model rocket engine...
  • Page 3: Before You Start

    B6-2, B4-2, and C6-3 engines only. Only fly your complex model rockets, the Mars Lander was de- Mars Lander™ in little or no wind. The Mars Lan- signed to challenge even more experienced model- der™ is marginally stable due to its short, squat ers.
  • Page 4: Parts Identification

    These instructions are presented in a logical  60. Prepare any remaining balsa surfaces for order to help you put your Mars Lander™ together a smooth professional looking finish. Fill the wood quickly and efficiently. Check off each step as you grain with diluted Fill n’...
  • Page 5: Recovery System

    Apply glue along the second long- est edge of the balsa gear housing as shown in the the Mars Lander™. Tie it securely to the black elas- illustration and glue it in place. Make sure the out- tic shock cord.
  • Page 6  6.  55. Punch out the 4 balsa gear struts and round Apply a coat of glue on the back side of one of the edges as shown. Loop two rubber bands the rear descent stage body wrap and press it in around the notch in each strut stretching them to between two of the gear housings and even with the top of the strut.
  • Page 7  52. Next run a line of glue around the edge of the ascent bulkhead and around the forward end of the parachute tube. Slide on the command module making sure the launch lug is through the notch and glue into place. When the glue is dry cut away the top of the launch lug at an angle so that it is flush with the shroud.
  • Page 8: Module Assembly

    MODULE ASSEMBLY  49. Slide the landing gear assembly into the descent stage tube. Make sure the bulkhead is aligned properly so that the landing gears move freely. Do Not Glue! Slide the ascent module on the parachute tube and fit the internal ring inside the descent stage.
  • Page 9  47.  14. Remove the landing gear assembly from Once the glue has set on the pads apply a the descent stage. Carefully cut 4 notches 1/4” long small amount of glue to a small landing pad disk (7) in the internal ring along the marks.
  • Page 10: Break Time

     17. While the glue is drying, insert one plastic bearing in each of the rubber hinges. Use your fin- gers to slowly work the bearing to the center of each rubber hinge tube. When all the glue is dry, slide one of the flexible hinge tubes onto the strut brace.
  • Page 11: Engine Mount

    ENGINE MOUNT  40. Apply glue to the inside edge of the large end of the ascent module shroud. Center the nar- row bulkhead notch over the notched brace and glue bulkhead in first with the ring facing out. Push ...
  • Page 12  22.  38. Now mark the tube 1” from the rear as On a flat surface lay a piece of wax paper shown in the illustration below . Cut a notch on the down. Position the small end of the ascent module inside of the engine tube centering ring 1/32”...
  • Page 13: Main Assembly

    MAIN ASSEMBLY  35. Glue the shroud together by applying glue to the shroud tab and align the two sides to- gether. Hold in place until it sets up and then leave  24. Punch out the balsa and paper (1) gear to dry.
  • Page 14  26. Next apply a line of glue along the two longest edges of the gear housing as shown in the illustration. Glue it to the body tube so that the front of the housing is exactly 1/8” from the forward end of the descent tube.
  • Page 15 NOTE  29. Cut out the marking guide for the para- When the landing gears are put onto the engine chute tube and wrap it around the tube. Mark the tube they should look like the drawing below. tube at each arrow point. Remove the guide and draw a line down the whole body tube with a straight edge.
  • Page 16: Parts List

    EXPLODED VIEW Parts List A 1 Body Tube ......BT-100CE B 1 Body Tube ........ BT-60FG C 1 Body Tube ........ BT-20DJ D 2 Ring Tubes ....... RT-99D E 1 Balsa Nose Cone ...... BNC-60AL F 1 Laser Cut Fins ......FV-54 G 4 Launch Lugs ......
