contents 1. Before You Start Safety Refrigerant gas information Caring for the Environment 2. About Your Fridge-Freezer About the Fresh Food Compartment About the Freezer Compartment Fridge-Freezer Control Panel Freezing Fresh Food Warning Alarm During First Use 3. Food Storage Tips Tips on Storing Fresh Food Tips on Freezing Food 4.
1. Before You start Thank you for buying a Rangemaster appliance. We hope that it provides a stylish yet practical solution to your cooling needs. We hope that this handbook supplies you with all the information you require. If there is anything you are not sure of please contact us (see Warranty section for Consumer Services details).
R600a gas, we advise you to consult your own doctor. caring for the environment Disposing of your packaging Your new refrigerator was protected by suitable packaging while on its way to you. All of the materials used are environmentally friendly for disposal and can be recycled.
2. about Your Fridge-Freezer Light Glass shelves Bottle holder Glass shelf Crisper drawers Freezer drawers The fridge-freezer is shown in Fig.2-1 and has the following features: • Automatic fridge defrost • Adjustable thermostat • Egg rack • Bottle rack • 4 door shelves •...
Lift the front of the shelf and carefully pull it out of the grooves. 2. Defrost Water outlet The interior of the refrigerator is cooled by the cooling plate that is on the rear wall. Beneath this there is a channel and an outlet for the defrost water.
Freezer compartment The freezer compartment consists of four drawers (Fig.2-3). As with the refrigerator, certain areas of the freezer are better for storage of certain foods. Ice creams and water ices are best stored towards the rear of the appliance where it is coldest.
(Fig.2-6). Ideally the arrow should be set to the midway position (Fig.2-7). • The refrigerator can maintain a temperature of between 4-6 °C. • The freezer section can cool down to –18 °C and lower. IMPORTANT: The ambient temperature of the room, the...
IMPORTANT: DO NOT run the appliance with the thermostat on higher settings in normal use otherwise the defrost drain hole will freeze. Freezing Fresh Food To freeze the maximum quantity of fresh food specifi ed, turn the thermostat dial to its maximum position (Fig.2-8) a few hours before intending freezing.
Make sure that these foods are stored in suitable containers. • Foods stored in the refrigerator should be cleaned and dried before storing. • Before foods are put into the refrigerator, it is...
tips on Freezing Food • As with storing fresh foods, suitable packaging, correct temperature and food hygiene will enhance the quality of the food you are freezing. • Avoid putting hot foods into the freezer. First let them cool until they reach room temperature. •...
4. Installation Fig.4-1 38 min 1780 All dimensions in mm Positioning Your appliance IMPORTANT: We recommend that two people install this appliance. choosing the right location The appliance should be installed in a location where the ambient temperature corresponds with the climate classification as stated on the rating plate.
Take the upper hinge and remove the pin. Fit the pin to the new left-hand hinge: this is in the fi xing kit (Fig.4-9). Refi t the refrigerator door and install the new door hinge bracket (Fig.4-10). Refi t the upper support bracket.
38 min Fig.4-11 1780 min 200 cm² Make sure the ller shelves do not block the ow of air Min 200 cm² Fig.4-12 IMPORTANT: After you have completed reversing the door, check that the door opens and shuts correctly without fouling.
Page 15
Installing your fridge-freezer Fit the appliance towards the left-hand side of the housing unit, leaving a gap of approximately 5 mm. This fridge-freezer has front adjustable feet, which can be used to level the appliance. Using a suitable spanner, adjust the feet. Turn the spanner clockwise to raise the feet and counter- clockwise to lower the feet (Fig.4-13).
Neutral: to the terminal marked N, coloured Blue electrical supply connection Your refrigerator is intended as a permanent installation. Connect the appliance to the electrical supply (220–240 V ~ 50 Hz) with the plug and lead, which are fitted. Connections to the mains supply should be in accordance Live: to the with local regulations.
The drain hole (Fig.5-2) should be cleaned periodically with the drain hole cleaner. This will prevent water from collecting in the bottom of the refrigerator, instead of flowing down the defrost drainage channel and drain hole. IMPORTANT: Please note that the drain hole cleaner should not be left in position permanently.
Disconnect the appliance from the power supply before replacing the light bulb. There is an interior light in the top of the refrigerator section. Remove the bulb housing cover, by gently pulling the clip away from its slot (Fig.5-3). Then slide the cover off, removing the lugs on the cover from the bulb housing.
6. troubleshooting IMPORTANT: If your fridge-freezer does not appear be operating properly, please refer to the checklist below before contacting Consumer Services. My fridge-freezer does not appear to be working / there is no power to my appliance • Check that the plug is fully inserted into the power socket.
The product number/serial number is located inside the refrigerator on the top left-hand side. The 2 years free maintenance for the operation of the appliance started from the date of purchase of this product.
8. technical Data INSTALLER: Please leave these instructions with the user. DATA BADGE LOCATION: Front left-hand side of the freezer compartment. COUNTRY OF DESTINATION: GB/IE Dimensions All dimensions in mm. ratings Electrical – voltage/frequency Energy efficiency class on a scale of A (more efficient) to G (less efficient) Climate class (SN = 10-32 °C, N = 16-32 °C, ST = 18-38 °C, T = 18-43 °C) Freezer compartment star rating Temperature range (from >...
Page 24
• DocNo.000-0001 - Back cover Rangemaster Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 1926 457400 Fax: +44 (0) 1926 450526 E-mail: consumers@rangemaster.co.uk w w w. ran ge ma ste r.co.u k ArtNo.000-0003 CE logo...
