CONTENTS SAFETY INFORMATION………………………………………………………………………………………………………………… 1 IMPORTANT SAFETY INSTRUCTIONS………………………………………………………………………………………………. 2 REMOTE CONTROLLER……………………………………………………………………………………………………………….. 3 LOUDSPEAKER POSITIONING……………………………………………………………………………………………………….. 4 FRONT PANEL INFORMATION………………………………………………………………………………………………………… 5 REMOTE CONTROL INFORMATION…………………………………………………………………………………………………. 6 REAR PANEL INFORMATION………………………………………………………………………………………………………….. 7 CONNECTIONS - LOUDSPEAKER CONNECTIONS……………………………………………………………………………………………………. 8 - AUDIO CONNECTIONS………………………………………………………………………………………………………………... 9 - DIGITAL CONNECTIONS……………………………………………………………………………………………………………… 9 - FRONT INPUT CONNECTIONS………………………………………………………………………………………………………. 10 - AERIAL CONNECTIONS………………………………………………………………………………………………………………... -
Page 3: Safety Information
SAFETY INFORMATION CLASS 1 LASER PRODUCT ACCESSORIES 1. RCA cord (yellow color). 2. Remote control. 3. Battery AA x 2 for Remote control 4. Instruction Manual Caution: To reduce the risk of electric shock, do not remove Cover (or back) No user-serviceable parts inside. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Caution: Read This Before Operating Your Unit. READ AND FOLLOW INSTRUCTIONS: All the safety and operation instructions should be read before the product is operated. Follow all operation instructions within this manual. RETAIN INSTRUCTIONS: The safety and operation instructions should be retained for future reference. HEED WARNINGS: Comply with all warnings on the product and in the operation instructions. -
Page 5: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION 13. SERVICING: Do not attempt to service this product yourself as removing cover may expose you to dangerous voltages or other hazards. Refer all servicing to qualified service personnel. 14. LIGHTNING: For added protection for this product during a thunderstorm, or when it is left unattended and unused for long period of time, unplug it from the wall outlet and disconnect the antenna or cable system. -
Page 6: Remote Controller
REMOTE CONTROLLER By using the provided remote control unit, the receiver can be controlled from your listening position. To use the remote control unit, point it at the REMOTE SENSOR window of the receiver. Notes: - Even if the remote control unit is operated within the effective range, remote control operation may be impossible if there are any obstacles between the unit and the remote control. -
Page 7: Front Panel Information
FRONT PANEL INFORMATION 13 14 15 1. POWER ON/OFF Push this button to turn the unit into standby mode, push it again to turn off the unit. 2. Stereo Direct Press this button ,the unit will change to stereo direct output mode, all the signal through this unit will not be amplify. 3. -
Page 8: Remote Control Information
REMOTE CONTROL INFORMATION 1. Mute Press this button to mute the sound, push again to cancel the mute function. 2. Standy Push this button to turn the unit into standby mode, push it again to turn off the unit. 3. Digital in Press this button to active the PCM digital in inpu 4. -
Page 9: Rear Panel Information
REAR PANEL INFORMATION 1. Antenna: Connection terminal for AM& FM 2. Mains switch Use to interrupt the mains voltage 3. RS232 port 4. Analog audio In/Out - TAPE OUT: Connect to the line input terminals on the TAPE DECK - AUX IN: Connect to the line output of an external player. -TAPE IN: Connect to the line output terminals on the TAPE DECK. -
Page 10: Connections
CONNECTION LOUDSPEAKER CONNECTIONS Caution: To avoid damaging the speakers with a sudden high-level signal, be sure to switch the power off before connecting the speakers. Check the impedance of your speakers. Connect speaker with an impedance of 8 ohms or more. The amplifier’s red speaker terminals are the + (positive) terminals and the black terminals are the –... -
Page 11: Audio Connections
CONNECTION AUDIO CONNECTIONS Note: Do not plug in the mains power lead or turn on the unit before all connections have been made. Connect to source equipment using phono cables (stereo 2RCA-2RCA). DIGITAL CONNECTIONS Two types of digital audio connections can be made to this unit, optical and coaxial. -
Page 12: Front Input Connections
CONNECTION FRONT INPUT CONNECTIONS The front panel iPod input is for temporary connections to the iPod player. -
Page 13: Aerial Connections
CONNECTIONS AERIAL CONNECTIONS FM aerial Connect an aerial to the FM 75 ohm socket (a simple wire aerial is supplied for temporary use). Extend the lead and move the aerial around until you get the best reception. For continued use, we strongly recommended using a 75 ohm outdoor FM aerial. AM loop aerial Connect each end of the single length antenna to the antenna terminals. -
Page 14: Basic Operation
BASIC OPERATION 1. Press the Main Power ON/OFF Switch on the rear panel to ON. 2. Press the Power On button on the front panel to switch on the unit. 3. Select the desired source by pushing the corresponding button - DVD/CD - AUX/STEREO LINE IN - iPod... - Page 15 BASIC OPERATION Radio Operations Automatic Tuning Press the Main Power On/Off switch on the rear panel first, then press the Power On/Off button on the front panel to turn this unit on. Press the Tuner button on the front panel or on the remote control, then press the Band button on the remote to select FM or AM.
-
Page 16: Radio Data System (Optional)
RADIO DATA SYSTEM (Optional) RADIO DATA SYSTEM (RDS) RDS is a method for the transmission of additional information from local Radio Stations. It can only operated in FM mode. For example, name of the station broadcasting, name of the program or the type of program will be shown on the multi-function display. -
Page 17: Troubleshooting
TROUBLESHOOTING To determine any problem with your receiver, always check the most obvious possible causes first. If any problem still remains after your having checked the items below, consult your nearest dealer. Problem Amplifier When listening to the music in stereo. Left/right speakers reversed. -
Page 18: Specifications
SPECIFICATIONS Max Power Output: A Speaker : B Speaker: A+B Speaker Total Harmonic Distortion: Inter-modulation distortion: requency Response: Signal/Noise ratio: Signal/Noise ratio: Channel Separation: Audio Analogue input Senstivity/Impedance: Tuning Range: THD: Signal/Noise ratio Antenna inputs: General: Mains voltage: Dimensions: Option USB multimedia player for audio *Design and specifications are subject to change without notice.
