Summary of Contents for Sonic Frontiers MCA Series
Page 1
M C A S E R I E S A M P L I F I E R S O P E R A T I N G M A N U A L...
Page 2
We at Sonic Frontiers International hope you will derive many years of listening pleasure from your new Anthem MCA Amplifier. This Operating Manual contains important information regarding the operation and care of the MCA Series. Be sure to read this manual carefully and follow these instructions in order to keep your unit performing and s o u n d i n g its best.
Page 3
F I G U R E 1 MCA front panel. F I G U R E 2 MCA 5 rear panel. F I G U R E 3 MCA 3 rear panel. F I G U R E 4 MCA 2 rear panel.
Page 4
C O N T R O L F U N C T I O N S 2- COL OUR LED In MANUAL mode, the LED is lit “green” when the amplifier is “ON”, receiving power from the power supply. In TRIGGERor AUTOmode, the LED will be lit “red” until the amplifier receives a music signal (auto) or a trigger voltage (trigger), at which point it will turn “green”.
Page 5
(i.e. the amplifier is on and outputting a signal). PLACEMENT FOR PROPER VENTILATION The MCA Series require a minimum of 12” (30cm) above, of unobstructed air space. Make sure that the ventilation slots on the top and bottom remain unobstructed by any object.
Page 6
T E C H N I C A L S P E C I F I C A T I O N S MCA 2 INPUTS MCA 3 MCA 5 MCA 2 OUTPUTS MCA 3 MCA 5 Power On/Off, 3 Way On Mode (Auto-on, Manual-on, Trigger-on) SWITCHES (2) MCA 2 DIMENSIONS...
W A R R A N T Y ( U S A & C A N A D A ) LIMITED FIVE YEAR WARRANTY Sonic Frontiers International warrants to the purchaser that each component is free of manufacturing defects for a period of five (5) years from the date of purchase.
Page 8
D E S I G N E D A N D M A N U F A C T U R E D S O N I C F R O N T I E R S I N T E R N A T I O N A L 2 7 9 0 B R I G H T O N R O A D , O A K V I L L E , O N T A R I O , C A N A D A L 6 H 5 T 4 T E L : ( 9 0 5 ) 8 2 9 - 3 8 3 8...
