Summary of Contents for LION M-FIRE
- Page 1 M-FIRE MOBILE FIRE TRAINING SET ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||| USER’S MANUAL ORIGINAL USER’S MANUAL Version 1.21 29/08/19...
-
Page 2: Table Of Contents
Troubleshooting Warranty Specifications Gas Technical Specifications Electrical Specifications Control Unit/Console Burner Unit Attributes Important notifications Advice on usage options of M-Fire attachments “Manual operation” “Automatic” with grating “Automatic” with attachment plate Instructions for using the attachment M-Fire “Deep Fat Fryer”... -
Page 3: System Description
The power supply can be shut off by switching the ‘Off-Hand-Auto’ button on the control unit to ‘Off’. The power supply automatically shuts off if the M-Fire is not being used for 5 minutes. In case of low voltage, the M-Fire shuts off (to avoid internal damage, when using a battery) The gas supply can be shut off by closing the valve on top of the gas bottle. -
Page 4: How To Use The M-Fire
M-Fire base unit. Open the gas valve and check for any leaks. The M-Fire is now ready for use. We do not recommend using the M-Fire in a confined space, but, if you do, the following requirements must be met: •... -
Page 5: Transport
A: Increasing Fire: The M-Fire will start with the low pointed flame. After 20 seconds the tray will ignite. After another 10 seconds the tray and high pointed flame join. If the tray is not ignited after 10 seconds, the ignition stops and the Fail LED starts flashing slowly. -
Page 6: Manitenance
An over-temperature will recover itself. When other failures occur please contact LION. If the power supply is lower than 11 volts, the M-Fire shuts down (to avoid internal damage, when using a battery). When the power supply is restored, the M-Fire can be turned on. -
Page 7: Specifications
30 kg Dimensions (w x d x h): 61 x 80/92 x 21 cm (including grating and wheels) 3.5 Attributes Included: M-Fire Basic Burner Unit Fire Grid Prop Connecting plate Power adapter Solid Reducing valve (Shell connection) 0 -1.5 bar... - Page 8 M-Fire Underframe M-Fire Dustbin M-Fire Electric motor M-Fire Stove top M-Fire Electric Cabinet M-Fire Flat screen M-Fire Deep Fat Fryer, including connection cable Battery Power Pack Battery Connecting Kit Cigarette Lighter Plug and Cable Automotive Plug Connecting Kit Dustbin Electric Motor...
-
Page 9: Important Notifications
The supplied adaptor for 12 V-DC power supply type “FT-Solid” is watertight. Regularly check that the enclosure is not damaged! • The control box is not watertight, although, it can take a few incidental drops. • The control box on the M-Fire is splashproof. It must not be submerged. -
Page 10: Advice On Usage Options Of M-Fire Attachments
5.2 “Automatic” with grating A: Increasing fire: The M-Fire begins with the low pointed flame. After 20 seconds, the tray starts up too, followed by the high pointed flame after another 10 seconds. The maximum total duration of this scenario is 60 seconds. - Page 11 M-Fire User’s Manual Version 1.21 | 29/08/19 Page 10 Flatscreen Deep fat fryer * When using the “cooker” with pan, pay extra attention when using the settings “Increasing fire” or “Intermittent”, as the accompanying high pointed flame can give people a fright. The safety of the trainees is of course paramount.
-
Page 12: Instructions For Using The Attachment
6.1 M-Fire “Deep Fat Fryer” The “Deep Fat Fryer” attachment is an option for the M-Fire and is intended to demonstrate the effect of trying to extinguish a chip-pan fire with water. This accessory can be supplied with its own remote control (power supply + control cable) or with a connection cable designed for use with an M -Fire control console. - Page 13 Version 1.21 | 29/08/19 Page 12 LION Protects B.V. Industrieweg 5 5111 ND Baarle-Nassau the Netherlands T: +31 (0)13 507 6800 F: +31 (0)13 507 6808 E: infoEMEA@lionprotects.com WWW.LIONPROTECTS.COM ||||||||||||||||||||||||||||||||||||||||||||||||| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||| |||||||||||||||||||||||||||||||||||||||||||||||||||||| © LION Group, Inc. All rights reserved. Version 1.21 voorbehouden. 29/08/19...
