- Page 1 M-FIRE ‘UNITS’ ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||| USER’S MANUAL ORIGINAL USER’S MANUAL Version 1.2 14/01/20...
- Page 2 M-Fire Units User’s Manual Version 1.2 | 14/01/20 Page 1 Contents System description Use of the ‘M-Fire Unit’ Specifications Important remarks...
-
Page 3: System Description
System description General “M-Fire” is equipment designed to allow training and practice in extinguishing various types of small fires. A number of separate burner units are available in addition to the standard burner unit with various fire options and accompanying attachments, so that several practical situations can be simulated in a realistic manner. - Page 4 (mains voltage and low-voltage supply) will be interrupted. The burner unit of the “M-Fire” operates on a safe voltage of 12 Volts DC. The control console is equipped with a ball valve with which the gas supply can be interrupted. After completing the training, the tap on the gas bottle must be closed! If the burner unit is part of a training system, a main gas valve is provided.
-
Page 5: Use Of The 'M-Fire Unit
Alternatively: The area should be especially designed for fire simulations. • Operation The operation of M-Fire Unit can be carried out in 2 different ways. By means of the selector switch, “hand” or “auto” can be chosen. “Hand” (manual) The instructor determines the operation by holding down the start button. - Page 6 The gas cylinder should preferably be transported separately. The control console is equipped with handles and wheels to facilitate transport. If the “M-Fire Unit” is built into a vehicle, the general instructions for that vehicle must be followed. Maintenance The housing of the “M-Fire Unit”...
- Page 7 1 mm and the specification H07RN-F. Guarantee LION will replace any part of the “M-Fire Unit” in case the malfunctioning is a result of a material or • construction fault, within 12 months after the original purchase date.
-
Page 8: Specifications
Electrical The controls operate on 12V DC. This is supplied by the built-in power supply in the operation console / control box. With a standard M-Fire operation console, power is also supplied by the built-in battery. Power supply: 230V +/- 10% Fuse 230V: 0.5 A-T... -
Page 9: Important Remarks
CO2 is left in or near the burner unit. The presence of CO2 hinders ignition and flame detection. Close the gas valve on the gas cylinder after every use. The standard M-Fire control console must be disconnected from the burner unit before transport. The gas bottle should preferably be transported separately. - Page 10 Version 1.2 | 14/01/20 Page 9 LION Protects B.V. Industrieweg 5 5111 ND Baarle-Nassau the Netherlands T: +31 (0)13 507 6800 F: +31 (0)13 507 6808 E: infoEMEA@lionprotects.com WWW.LIONPROTECTS.COM |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||| © LION Group, Inc. All rights reserved. Version 1.2 14/01/20...
