- Page 2 A passive outdoor loudspeaker system is one of the best audio entertainment investments you can make for both residential and commercial installations. Investing the time and labor to install a wired speaker system will provide the safest and most dependable sound solution that can be easily upgraded and customized over time. Before connecting the speakers, please take the time to design and review the overall system, making sure the speakers are well- situated to provide an even coverage with adequate sound level.
- Page 4 Four 8Ω speakers 2-channel installation Simple 8Ω installation mono or bridged mode stereo mode series wiring(16Ω/channel) parallel wiring(4Ω/channel)
- Page 6 Eight 8Ω speakers 2-channel installation Subwoofer installation subwoofer Blue satellite speakers Optional satellite wiring Standard wiring (4Ω/channel) (8Ω/channel) series-parallel wiring(8Ω/channel)
- Page 7 To operate in 70v mode. you must utilize a 70v amplifier. Simply set the dial to any of the wattage setting and connect Alternately, silicon can be applied to the opening of standard wire nut to provide water protection. The B series is the speaker to a 70v amplifier that has power output at least 20% greater than the summation of all speaker wattage designed to be water-resistant, not waterproof.
