parts list
ItEM
QtY
rEFErENCE
required Circuit Components
1
0
C1, C2, C3, C4 (OPT)
2
2
C5, C6
3
1
D1
4
1
D2
5
19
E1-E13, E16-E21
6
2
E14, E15
7
8
JP1-JP8
8
1
J1
9
1
Q1
10
1
Q2
11
1
Q3
12
3
R1, R2, R3
13
0
R4, R5 (OPT)
14
2
R6, R7
15
2
R8, R9 Bal to #1765A
16
2
TP1, TP2
17
1
U1
18
1
U2
19
8
XJP1-XJP8
Part DESCrIPtIoN
Capacitor, 0603
Capacitor, 0.1µF , 25V, X7R, 10%, 0603
LED, Red, J-Type, SMD, Tape/Reel, 1208
LED, Green, J-Type, SMD, Tape/Reel, 1208
Turret, Testpoint, 0.065
Turret, Testpoint, 0.095
Header, 3-Pin, 0.079, Single Row
Connector, Header 14POS 2mm Vert Gold
Transistor, PNP , –40V, –200MA, SOT23-3
Transistor, NPN, 40V, 350MW, SMD, SOT23-3
MOSFET, N-Channel, 60V, 115mA, SOT23-3
Resistor, Chip 4.99k, 0.06W, 1%, 0603
Resistor, 0603
Resistor, Chip, 330Ω, 0.06W, 5%, 0603
Resistor, Chip, 1k, 0.06W, 5%, 0603
Testpoint, Test pad
IC, Temperature, Voltage, Current Monitor MSOP(16)-MS
IC, EEPROM, 2kbit, 400kHz, TSSOP-8
Shunt, .079" Center
DEMO MANUAL DC1785B
MaNUFaCtUrEr/Part NUMBEr
OPT
TDK, C1608X7R1E104K (Bal to #1787A)
Panasonic, LN1251CTR
Panasonic, LN1351CTR
Mill-Max, 2308-2-00-80-00-00-07-0
Mill-Max, 2501-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Molex, 87831-1420
Diodes/Zetex, FMMT3906TA
Diodes Inc., MMBT3904-7-F
Diodes/Zetex, 2N7002TA
Yageo, RC0603FR-074K99L
OPT
Yageo, RC0603JR-07330RL
Yageo, RC0603JR-071KL
Component Corp., TP-107-02-1
Linear Technology, LTC2991CMS#PBF
Microchip, 24LC025-I/ST
Samtec, 2SN-BK-G
