Designs for Vision NanoCam 4K Quick Start

Part A: Initial Setup

You're NanoCam 4K/Go comes with the following: Footpedal, Footpedal USB Receiver, USB Cable, USB
Extension Cable, Blue Cap Hex Driver
- The DBR software is loaded onto the Designs for Vision Chrome Cap USB Stick supplied with
your camera.
- If you already have the DBR software, you must make sure you have version 1.1.3 loaded.
-

Part B: Setting up the Footpedal

The footpedal is controlled using a wireless Bluetooth module. You must plug in the module to the
nearest USB port.
To operate the foot pedal, insert Bluetooth Receiver into the USB port on your device, as shown below:
You can test to make sure the footpedal is working properly before use. The footpedal is pre-set to work
with the DBR software. Plug in your camera to the USB port or adapter depending on your setup. The
footpedal will not work without the camera plugged in.
- Pressing the left side of the pedal will allow you to record video. Press once to start and then
again to stop the video.
- Pressing the right side of the pedal will take still pictures. You can take pictures while recording
as well.
Record/Stop
NanoCam 4K/NanoCam Quick Start
(Note, if your device has a USB C port
you must use a USB C to USB A
adapter, also you may require a USB
hub if your device only has one USB
port
Take Picture
