Wireless Wall On/Off/Timer Remote Control
INSTALLATION AND OPERATING INSTRUCTIONS
This wireless wall on/off/timer remote control – system provides a safe, reliable, and user-friendly remote control
for millivolt valve gas appliances. The system can be operated in a timer or manual mode. Always check the
appliance home owner's manual for additional information, or warnings regarding accessory installation before
connecting this remote control system.
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the
dealer from whom you purchased the kit. Do not attempt to install any part of the kit unless all parts are in good
condition. Please keep this booklet for future reference.
Transmitter
Battery Alkaline AAA ( for Transmitter)
Receiver (Assembly) consists of:
Receiver Box with Adapter
Slide Button-Black (On/RS/Off)
L-Bracket (Floor Mount)
Battery Alkaline AA (for Receiver)
Wall Cover Plate-Black
Wall Cover Plate-White
Slide Button-White (On/RS/Off)
Screws (for Wall Cover Plate)
Plug-In Wiring Assembly – 18" Inches
Velcro (Loop and Hook)
Wall Anchor Screws
Wall Anchor
Screws (for fireplace system control covers)
Installation Instructions
•
Contemporary Ergonomic Wall Mount Transmitter with LCD Display
•
Battery Powered Transmitter
•
Compact 18" wire length of plug in Adapter
•
Pre-Programmed for Quick Installation
•
Low battery Indication
•
Child Proof Lock-out
•
16 Security Codes
•
Quick Disconnect Wiring Assembly
•
On/Off and Timer (30, 60, 90) or (60, 120, 180) minutes Flexibility
•
Reset Button
50D0089 Rev 2
WMTD
CONTENTS OF KIT
Description
FEATURES/SPECIFICATIONS
WARNING
Page 1 of 10
Qty
1
2
1
4
1
1
1
2
1
1
2
2
2
1
Ambient Technologies
A Division Of MHS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ambient Technologies WMTD
Summary of Contents for Ambient Technologies WMTD
- Page 1 WMTD Wireless Wall On/Off/Timer Remote Control INSTALLATION AND OPERATING INSTRUCTIONS This wireless wall on/off/timer remote control – system provides a safe, reliable, and user-friendly remote control for millivolt valve gas appliances. The system can be operated in a timer or manual mode. Always check the appliance home owner’s manual for additional information, or warnings regarding accessory installation before...
-
Page 2: Installations
Low battery power in the transmitter or receiver can affect the operation of the remote control in the AUTO mode. In some cases the unit may not cycle off when the target temperature is reached. INSTALLATIONS 50D0089 Rev 2 Page 2 of 10 Ambient Technologies A Division Of MHS... - Page 3 Make sure that the wires do not contact the appliances any place other than at the terminals. Exposure to temperatures higher than 105C (250ºF) may cause the receiver to malfunction or fire hazard. 50D0089 Rev 2 Page 3 of 10 Ambient Technologies A Division Of MHS...
- Page 4 Close the side door until it snaps into the housing. The batteries should be replaced at least once every 6 months or when low battery icon come out on the LCD display. Transmitter: - Batteries Installation 50D0089 Rev 2 Page 4 of 10 Ambient Technologies A Division Of MHS...
- Page 5 Do not use two (2) or more remote control systems in the same area with the same dip switch settings, as they will communicate with each other. This may cause the appliances to malfunction. OPERATIONS: 50D0089 Rev 2 Page 5 of 10 Ambient Technologies A Division Of MHS...
- Page 6 Wireless Wall Transmitter: General: The WMTD Remote Control has two (2 ) operating modes: Manual and Timer. The transmitter will operate the remote receiver from 1 foot to a maximum of 30 feet. The distance is reduced when batteries are low or when the receiver is inside a metal enclosure.
- Page 7 The transmitter will not work mode until child-proof mode is deactivated by pressing the _ and _ buttons simultaneously for 3 seconds again to exit child-proof mode. 50D0089 Rev 2 Page 7 of 10 Ambient Technologies A Division Of MHS...
-
Page 8: Troubleshooting
Press the _ button on the transmitter to turn the system to OFF. The flame should extinguish (the pilot light will remain on). TROUBLESHOOTING Symptom Causes Action 50D0089 Rev 2 Page 8 of 10 Ambient Technologies A Division Of MHS... -
Page 9: Warranty
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARRANTY 50D0089 Rev 2 Page 9 of 10 Ambient Technologies A Division Of MHS... - Page 10 Answers to any questions regarding our limited warranty may be obtained by writing our corporate offices. Ambient Technologies warrants each new Ambient Technologies remote control against any defects that are due to faulty material or workmanship to the original owner, for a period of five years after the original date of purchase.
