Wireless Wall Thermostatic On/Off Remote Control
INSTALLATION AND OPERATING INSTRUCTIONS
This wireless wall thermostatic on/off remote control – system provides a safe, reliable, and user-friendly remote
control for millivolt valve gas appliances. The system can be operated in a thermostatically or manual mode.
Always check the appliance home owner's manual for additional information, or warnings regarding accessory
installation before connecting this remote control system.
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the
dealer from whom you purchased the kit. Do not attempt to install any part of the kit unless all parts are in good
condition. Please keep this booklet for future reference.
Transmitter
Battery Alkaline AA ( for Transmitter)
Receiver (Assembly) consists of:
Receiver Box with Adapter
Slide Button-Black (On/RS/Off)
L-Bracket (Floor Mount)
Battery Alkaline AA (for Receiver)
Wall Cover Plate-Black
Wall Cover Plate-White
Slide Button-White (On/RS/Off)
Screws (for Wall Cover Plate)
Plug-In Wiring Assembly – 18" Inches
Velcro (Loop and Hook)
Wall Anchor Screws
Wall Anchor
Screws (for fireplace system control covers)
Installation Instructions
•
Contemporary Ergonomic Style Transmitter with Large LCD Display
•
Backlit LCD Display
•
Battery Powered Transmitter
•
Compact 30" wire length of plug in Adapter
•
Pre-Programmed for Quick Installation
•
Low battery Indication
•
Child Proof Lock-out
•
128 Security Codes
•
Quick Disconnect Wiring Assembly
•
On/Off, Thermostatic, Timer, and 5-2 Day Thermostatic Programming Flexibility
•
Reset Button
50D0077 Rev 1
WWTD
CONTENTS OF KIT
Description
FEATURES/SPECIFICATIONS
Page 1 of 10
Qty
1
2
1
4
1
1
1
2
1
1
2
2
2
1
Ambient Technologies
A Division Of MHS
