INSTALLATION AND OPERATING INSTRUCTIONS
This hi/lo remote control system provides a safe, reliable, and user-friendly remote control to power up to a 6 VDC
servo motor or solenoid gas valve system (Maxitrol Gas Valve). Always check the appliance home owner's manual
for additional information, or warnings regarding accessory installation before connecting this remote control
system.
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately contact the
dealer from whom you purchased the kit. Do not attempt to install any part of the kit unless all parts are in good
condition. Please keep this booklet for future reference.
Transmitter
Battery Alkaline AAA ( for Transmitter)
Receiver (Assembly) consists of:
Receiver Box
f i r e - p a r t s . c o m
Push Button-Black (ON/HI, OFF/LO)
L-Bracket (Floor Mount)
Battery Alkaline AA (for Receiver)
Wall Cover Plate-Black
Wall Cover Plate-White
Push Button-White (ON/HI, OFF/LO)
Screws (for Wall Cover Plate)
Plug-In Wiring Assembly – 18" Inches
Velcro (Loop and Hook)
Installation Instructions
Screws (for fireplace system control covers)
•
Contemporary Ergonomic Style Transmitter with Large LCD Display
•
Backlit LCD Display
•
Battery Powered Transmitter and Receiver
•
Easy Access Front Battery Door
•
Pre-Programmed for Quick Installation
•
Low battery Indication
•
Child Proof Lock-out
•
Over 4 million security codes
•
Thermal Shutdown and Out of Range Shutdown On Transmitter
•
Quick Disconnect Wiring Assembly
•
Reset Button
50D0033 Rev 1 June 2002
RCMHL
HI/LO Remote Control
CONTENTS OF KIT
Description
FEATURES/SPECIFICATIONS
Page 1 of 7
Qty
1
3
1
4
1
1
1
2
1
1
1
2
Ambient Technologies
A Division Of
Monessen Hearth Systems
Advertisement
Related Manuals for Ambient Technologies RCMHL
Summary of Contents for Ambient Technologies RCMHL
- Page 1 RCMHL HI/LO Remote Control INSTALLATION AND OPERATING INSTRUCTIONS This hi/lo remote control system provides a safe, reliable, and user-friendly remote control to power up to a 6 VDC servo motor or solenoid gas valve system (Maxitrol Gas Valve). Always check the appliance home owner’s manual for additional information, or warnings regarding accessory installation before connecting this remote control system.
- Page 2 Read all instructions completely before attempting installation. Follow instructions carefully during installation. Any modification of components will void the warranty and may cause a fire hazard. 50D0033 Rev 1 June 2002 Page 2 of 7 Ambient Technologies A Division Of Monessen Hearth Systems...
-
Page 3: Installations
Make sure that the wires do not contact the appliances any place other than at the terminals. Exposure to temperatures higher than 105C (250ºF) may cause the receiver to malfunction or fire hazard. 50D0033 Rev 1 June 2002 Page 3 of 7 Ambient Technologies A Division Of Monessen Hearth Systems... - Page 4 2. Using a paper clip, press the button and the system will reset and go into clock setting mode. Follow the instructions on how to set the time in the next section. 50D0033 Rev 1 June 2002 Page 4 of 7 Ambient Technologies A Division Of Monessen Hearth Systems...
- Page 5 Transmitter: General: The RCMHL is a manual remote control with flame height control. The transmitter will operate the remote receiver from 1foot to a maximum of 30 feet. The distance is reduced when batteries are low or when the receiver is inside a metal enclosure.
- Page 6 4. Press and hold the OFF/LO button on the transmitter to turn it off. The flame height should reduce until extinguishs the unit completely (the pilot light will remain on). 50D0033 Rev 1 June 2002 Page 6 of 7 Ambient Technologies A Division Of Monessen Hearth Systems...
-
Page 7: Troubleshooting
Ambient Technologies warrants each new Ambient Technologies remote control against any defects that are due to faulty material or workmanship to the original owner, for a period of five years after the original date of purchase.
