PST - 7700 Series
User's Manual
Rev. Original
FCC Notes:
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions manual, may cause interference to radio communications. It has been tested
and found to comply with limits for a Class A digital device pursuant to subpart J of
Part 15 of FCC Rules, which are designed to provide reasonable protection against
interference when operated in a commercial environment. Operation of this equipment
in a residential area is likely to cause interference in which case the user at his own
expense will be required to take whatever measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Inc. expressly disclaims any
warranties, expressed, implied or statutory, including without limitation implied
warranties of merchantability or fitness for particular purpose, good title and against
infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com
or
http://www.posiflex.com.tw
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Inc. 2005
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 13770900010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PST - 7700 and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX PST - 7700

  • Page 1 PST - 7700 Series User’s Manual Rev. Original FCC Notes: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested...
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: l Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. l This product contains inside a Lithium battery and maybe also a sealed type Lead acid battery if the UPS battery option is ordered.
  • Page 3: Brief Introduction

    BRIEF INTRODUCTION THE USER’S MANUAL The purpose of this manual is to guide the user in the initial installation and general use of the Posiflex PST7700 series of POS terminals. It does not explain any application software that may be supplied with it. We intend to provide our customers with all technology advantages available by evolving the product design to incorporate appropriate changes and improvements.
  • Page 4 THE STANDARD FEATURES CPU: C3 1.0 GHz; HDD: 20 GB or above; RAM: 128 MB Ethernet Networking: The standard network port works with both 10 Base T and 100 Base T. Programmable Keyboard: In either 112 key matrix or 136 key QWERTY layout with 8 KB memory.
  • Page 5: System Box Contents

    1). PP-2000 series: Friction type paper feed, 2 stations 9 pin dot matrix impact printer. 2). PP-5600 series: Friction type paper feed, 9 pin dot matrix impact printer 3). PP-5700 series: Sprocket type paper feed, 9 pin dot matrix impact printer 4).
  • Page 6 Cashier Display Carton When the order is PST7700 or PST7730, the purchased 9” VGA mono CRT monitor will be shipped in a separate box from the main system unit. When the order is PST7705 or PST7735, the package for the 12.1” color TFT LCD is inserted in a side within the system box.
  • Page 7: Crt Monitor

    INSTALLAT ION GUIDES Please do not connect the power cord or turn on the main unit until you have fully read the installation guides and followed the instructions!!! TECHNICAL ENHANCEMENTS Applicable technical enhancements in PST7700 series include RTC battery replacement, COM port power supply settings, VGA port power supply settings, DRAM upgrades, CD-ROM drive upgrade and adding a half length PCI adapter card.
  • Page 8 The next step is to pass the monitor cable through a square hole at the back edge of main unit. Open the back door by sliding two back door latches at the bottom of back door toward the center. The back door is easily removable.
  • Page 9: Customer Display

    platform of the main unit till it clicks. Screw the pivot back to secure the base of the cashier display on the display platform of the main unit as in drawing below. Remove the cable cover on the display platform (same way as the instructions for CRT model) and connect the VGA connector of the 12.1”...
  • Page 10 without the transparent key caps (these are in the accessories box). Also supplied with the keyboard are 4 die cut self-adhesive A4 label sheets that may be printed by most conventional means with whatever legends are required by the application. Each type of key top (with transparent key cap) listed in the table at end of BRIEF INTRODUCTION can be separately purchased in certain quantities and applied for variety in keyboard layout presentation.
  • Page 11 preferred for a permanent device like a bar code scanner in POS business. To access the internal connection you must remove the keyboard. To do this first unlock the front door lock and then remove the two mounting screws from the underneath of the chassis located just behind the front edge of the terminal.
  • Page 12: Cash Drawer

    The PST7700 installed with power management kit option is able to control most of the common cash drawers available on the market. However, it is recommended that the Posiflex CR-3100 or CR-3200 or CR-4000 or CR- 4100 or CR-4210 be used since the terminal has been designed to compliment these cash drawers both mechanically and electrically.
  • Page 13 USING THE PST SYSTEM BEFORE POWER ON It is very important that you check the following operational points: Ventilation This terminal must NOT be operated in an environment with restricted ventilation. There must be at least 25 mm air clearance around any top or side ventilation holes with a free flow of air around the unit at ALL times for the installation.
  • Page 14: Led Indicators

    room also provides very good protection as long as the ambient temperature remains below 30 C and the ventilation of the PST system is free. However, should any accident happen and the sulfuric acid from the battery spills on skin or clothing, wash immediately with water.
  • Page 15: Power On/Off Control

    AC power is available when the system is powered off. (b) With a UPS battery fitted together with the power management kit: The standby LED lights steadily to indicate the presence of AC power at system powered off. The system cannot be turned on if the AC power fails.
  • Page 16 choose for “PM Wake Up Events” in “Power Management Setup” and make the “Ring Power Up Control” enabled for Modem Ring Up or select the “Power Up by Alarm” for Alarm Clock Wake Up. Save the configuration and exit the CMOS setup program. The Preset Power On Control will then be ready.
  • Page 17 LCD MONITOR (for PST7705/PST7735) Mechanical Adjustments The 12.1” LCD color display is integrated on display platform to give the operator the clearest view. The display may be lifted from the horizontal to the upright position and rotated through a total of 90° (left 45 max., right 45 max.).
  • Page 18 There are 4 keys supplied with each keyboard and the lock is so designed that each key may turn the 6 position key switch to correspondent position range. The keys are named: PRG, REG, Z, GT. The available positions for each key type are listed in the table below: ü= accessible ü...
  • Page 19: Front Door

    of the slot, or sliding the card upward from the lower side of the slot till it reaches the top end as long as the card is a standard one. A non-standard card recorded without complete degaussing prior to recovery may accept only one direction in card reading.
  • Page 20 One of the major design features of the PST terminals is the ability to accommodate a very large range of printers. The terminal provides a printer platform where the printer can be mounted (use the Velcro strips in the accessories kit for fixation aid), and also provides a regulated 24 volts DC power line to power the printer.
