- Page 1 Proscend 4100 VDSL2 IP DSLAM Installation Manual Version 0.01...
-
Page 2: Table Of Contents
Housekeeping and Alarm Contact Output Interface ............. 13 Provisioning a Management IP port ..............15 Configuration Import/Export .................. 19 Firmware Update ....................21 — Operating and Maintaining the Proscend 4100 ..........23 Maintenance requirement ..................23 2.1.1 Tools and Equipment Requirements ................23 2.1.2... -
Page 3: Installation Of The Proscend 4100
1.1.1 Tools and Test Equipment Requirements To install and maintain the Proscend 4100, you should have the tools and test equipment listed in the following: Required Installation Tools and Materials... -
Page 4: Hardware Installation
Hardware Installation The hardware installation for the Proscend 4100 is simple and without complex hardware setting. However, it should be installed following out the standard installation procedures. During installation, basic safety precaution should always be taken, especially, be sure to wear an antistatic wrist strap to prevent static electricity from damaging the system and injury to the operator. -
Page 5: Installation Overview
DSLAM is obtained via DHCP. Users can also set the IP address manually by using the CLI commands or Web Configuration Tool (refer to section 1.3). It’s possible to access the DSLAM with telnet on port 23. Proscend 4100 VDSL2 IP DSLAM User Manual V0.01... -
Page 6: Mounting The Proscend 4100
Warning — Hazardous voltages may exist on the chassis. Always practice good safety habits when wiring a live circuit or performing maintenance. Proscend 4100 VDSL2 IP DSLAM User Manual V0.01... - Page 7 For 23’’ Rack For 19’’ Rack Mounting Bracket Position for Standard Mount of Proscend 4100 Proscend 4100 VDSL2 IP DSLAM User Manual V0.01...
-
Page 8: Power And Ground Connections
AC Power Connection If your Proscend 4100 uses AC power, connect the AC power cord to the AC supply socket on the front panel of the IP DSLAM, and plug the cord into the external power source. The voltage must be 100 to 240 VAC (±10% tolerance). - Page 9 -48VDC power supplier of telecom equipment. This is to guarantee our products against interferences by other equipment while they are working. Ground Connections This section provides the grounding rule for the Proscend 4100. All remote system sites must be properly grounded for optimum system performance. In Central Office: There should be a CO GND that is adequately grounded.
-
Page 10: Connecting The Vdsl2/Adslx And Pots Interfaces
1.2.5 Connecting the VDSL2/ADSLx and POTS interfaces The Proscend 4100 supports 24 ports VDSL2/ADSLx subscribers per box. Depending on your box, there maybe two RJ21 50-pin female connectors on the front panel of the system. One for VDSL2/ADSLx line and the other for POTS interface. - Page 11 For POTS port 1~24: PIN No Port PIN No PIN No Port PIN No Pin Assignment of POTS Interface Proscend 4100 VDSL2 IP DSLAM User Manual V0.01...
-
Page 12: Connecting The Gbe1/Gbe2 Trunk Interface
RX LC-type receptacle on the front panel. Warning — Never look directly at the transmitting ports of optical interface that might be emitting laser, in order to prevent damage to the eye from the laser radiation. Proscend 4100 VDSL2 IP DSLAM User Manual V0.01... -
Page 13: Ethernet Port (Mgmt)
1.2.7 Ethernet Port (MGMT) The Proscend 4100 provides one RJ45 Jack (MGMT) on the front panel for Ethernet interface connection. The detailed pin assignment is shown in the following figure and table. Other pins Bob Smith TX + TX -... -
Page 14: Console Port (Cid)
1.2.8 Console Port (CID) The Console interface (CID) on the front panel is the main control interface of the Proscend 4100. The RJ45 connector pin assignment is illustrated below: Console Port RJ-45 pin assignment To connect the host PC to the console port, a RJ45 (male) connector-to-RS232 DB9 (female) connector cable is required. - Page 15 Operation diagram of Housekeeping Inputs and Alarm Contact Output Note — The maximum current and voltage for ALMOUT / ALMCOM is restricted to 0.5 A 30 VDC or 0.15 A 125 VAC (resistive load). Proscend 4100 VDSL2 IP DSLAM User Manual V0.01...
-
Page 16: Provisioning A Management Ip Port
This section describes how to use CLI commands or Web GUI to provision an IP port for the Proscend 4100. Referring to the previous section, use a console cable to connect a host PC and the Proscend 4100 through its console port (COM). Then on PC run the terminal program with the setting shown below: In the PC terminal screen, type in the login user name and password to login the system. - Page 17 /*Save new setting to memory*/ After setting the in-band/out-band IP of the Proscend 4100, remember to connect its Ethernet port MGMT to the Ethernet LAN. Then in the previous PC terminal screen, type the following command to verify if the Ethernet connection between the management station and the DSLAM is working.
- Page 18 = 1.0/1.1/1.6 ms localhost:% Now you can access the Proscend 4100 via Telnet on port 23 (for using CLI) or Web GUI by entering its IP address in your browser’s URL/address field. Besides CLI, you can also change the in-band/out-band management IP of the Proscend 4100 in the Web GUI: a.
- Page 19 DB then click on Submit button (you can specify the DB filename to save or let system determine). This will save inband configuration and runtime configuration as the active restoration database for next power-on restoration. You shall wait for memory write success message. Proscend 4100 VDSL2 IP DSLAM User Manual V0.01...
-
Page 20: Configuration Import/Export
Configuration Import/Export The configuration database of Proscend 4100 contains two kinds of database - inband database and general database. Inband database contains configuration for the inband channel and is shared by two boot images (no matter which boot point you choose, the inband configuration keeps the same).
