Hix Premier N-840 Owner's Manual

16”x20” / 15”x15” air automatic heat transfer machines 16”x20” / 15”x15” commercial air automatic heat transfer machines

Advertisement

N-840 / N-640
16"x20" / 15"x15" Air Automatic Heat Transfer Machines
C-800 / C-600
Air Automatic Heat Transfer Machines
OWNER'S MANUAL
For Customer Service, Call 1-800-835-0606
ext. 209, ext. 211, ext. 220, ext.221 or
CONTENTS
BEFORE warranty repair you MUST get Prior Authorization:
16"x20" / 15"x15" Commercial
Analog and Digital Versions
Visit www.hixcorp.com
(N-840
Shown)
D
1
2
3
3
4
5-7
8
9
9
10
11
12-13
14-15
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premier N-840 and is the answer not in the manual?

Questions and answers

Tina Megens
February 27, 2025

Met welke olie moet ik de compressor van de N-840 onderhouden

1 comments:
Mr. Anderson
February 27, 2025

Use 3-in-1 oil for lubrication every 6 months.

This answer is automatically generated

Summary of Contents for Hix Premier N-840

  • Page 1: Table Of Contents

    N-840 / N-640 16”x20” / 15”x15” Air Automatic Heat Transfer Machines C-800 / C-600 16”x20” / 15”x15” Commercial Air Automatic Heat Transfer Machines OWNER’S MANUAL Analog and Digital Versions (N-840 Shown) For Customer Service, Call 1-800-835-0606 ext. 209, ext. 211, ext. 220, ext.221 or Visit www.hixcorp.com CONTENTS Receiving &...
  • Page 2: Receiving & Installation

    Combination air filter/water traps are available at any major hardware store or may be purchased directly from HIX (part #71145). *C-800/600 includes a filter.
  • Page 3: Temperature & Time Instructions

    OPERATION DIGITAL TEMPERATURE & TIME INSTRUCTIONS 1. Turn on the machine by pushing the on/off switch. 2. To change or set the temperature, press the menu button on the digital control. The light next to “TEMP” will light. Press the up s, or down t, button to your desired setting.
  • Page 4: Transfer Application

    OPERATION TRANSFER APPLICATION The N-840/640 is ideal for T-shirt shops and retail applications. HIX recommends the C-800/600 for heavy service use such as commercial, continuous applications, or for high volume applications. The C-800/600 120 volt models have a slower heat recovery (i.e. 18-20 seconds @ 375°F). The C-800/600 in 220 volt is recommended for quicker cycle times (i.e.
  • Page 5: Troubleshooting

    TROUBLESHOOTING WARNING: Before making repairs, be sure on/off switch is off and machine is unplugged! *Customer Service Tech Sheets are available for this step. Visit www.hixcorp.com to print or call 620-231-8568 and we will send you one. Parts ordering is available on-line.
  • Page 6 TROUBLESHOOTING WARNING: Before making repairs, be sure on/off switch is off and machine is unplugged! *Customer Service Tech Sheets are available for this step. Visit www.hixcorp.com to print or call 620-231-8568 and we will send you one. Parts ordering is available on-line.
  • Page 7 TROUBLESHOOTING WARNING: Before making repairs, be sure on/off switch is off and machine is unplugged! *Customer Service Tech Sheets are available for this step. Visit www.hixcorp.com to print or call 620-231-8568 and we will send you one. Parts ordering is available on-line.
  • Page 8: Thermostat Bypass

    REPAIRS THERMOSTAT BYPASS (ANALOG ONLY) If your machine is not heating (temperature light does not come on). WARNING: Before making repairs, turn temperature con- trol knob to “OFF” and unplug machine! 1. Loosen recessed set screw in the thermostat knob and re- move knob by pulling knob upward.
  • Page 9: Fuse Replacement

    REPAIRS Fig. 2 FUSE REPLACEMENT WARNING: Before making repairs, be sure on/off switch is off and machine is unplugged! 1. Remove back cover of the machine and locate internal fuse holder on inside of the machine. 2. Remove blown fuse. Replace with the proper fuse. 120V (N-840, N-640, C-800, C-600) ..
  • Page 10: Maintenance Schedule

    MAINTENANCE WARNING: Unplug the machine from electrical and air supplies before performing these maintenance procedures! LUBRICATION Your press requires lubrication every 6 months. Using 3-in-1 oil (available from your hardware store), add one to two drops of oil at the joints of all moving parts. MECHANICAL Every 12 months (or 100,000 cycles - whichever comes first), verify the tightness of the two gas spring retaining bolts (N-840/640D...
  • Page 11: Shipping Or Returns

    SHIPPING OR RETURNS SHIPPING OR RETURNS NOTE: Save all of your shipping/packing materials. DO NOT RISK COSTLY SHIPPING DAMAGE! SHIP ONLY IN ORIGINAL BOX. 1. Fasten machine to plywood shipping base with bolts provided. 2. Tie or tape handle securely to base. 3.
  • Page 12: N-840/640 Parts Identification

    N-840/640 PARTS IDENTIFICATION Exploded View See also pg. 14/15 for C-800/600...
  • Page 13 PARTS IDENTIFICATION Reference Serial# Prefix inorder help to determine machine: 640 - N640 Analog 642 - C640 Digital 641 - N600 Analog 643 - C600 Digital Parts List: 840 - N840 Analog 842 - N840 Digital “A”= Analog only “D” = Digital only 841 - C800 Analog 843 - C800 Digital All other parts are common for all machines unless otherwise marked...
  • Page 14: C-800/600 Parts Identification

    C-800/600 PARTS IDENTIFICATION These drawings show the C-800/600 air spring component. For all other parts identification, refer to the N-840/640 diagram page 12/13. C-800/600 Air Spring Component...
  • Page 15 C-800/600 PARTS IDENTIFICATION C-800/600 Air Spring Component Exploded View / Parts List The drawing shows the C-800/600 air spring component. For all other parts identification, refer to the N-840/640 diagram.
  • Page 16: Warranty

    Shuttle for a period of 90 days from the date of purchase. DoughXpress and Thermatrol products are covered under separate warranty. In the event of a defect, HIX, at its option, will repair, replace or substitute the defective item at no cost during this period subject to the limitations of insurance and shipping costs stated below.

This manual is also suitable for:

Premier n-640Premier c-800Premier c-600
