FH-3000
Combo Flat/Cube Heat Transfer Machine
OWNER'S MANUAL
FH-3000
Cube Attachment
FH-3000
FH-3000
Shown with Flat Attachment
Shown with Cube Attachment
For Customer Service, Call 1-800-835-0606
or Visit www.hixcorp.com
CONTENTS
Receiving & Installation ............................................................................................................2-3
Operation ..................................................................................................................................... 4
Setting Temperature & Time ........................................................................................................ 5
Preference Settings ..................................................................................................................... 6
Machine Presets .......................................................................................................................7-8
Cycle Count ................................................................................................................................. 9
Temperature & Time Modes ...................................................................................................... 10
Platen Pressure ......................................................................................................................... 11
Transfer Application ................................................................................................................... 12
Repairs/Adjustments ............................................................................................................13-14
Maintenance .............................................................................................................................. 14
Troubleshooting ......................................................................................................................... 15
Warranty .................................................................................................................................... 16
BEFORE warranty repair you MUST get Prior Authorization:
70620 RV E_120820
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hix FH-3000
Summary of Contents for Hix FH-3000
-
Page 1: Table Of Contents
FH-3000 Combo Flat/Cube Heat Transfer Machine OWNER’S MANUAL FH-3000 Cube Attachment FH-3000 FH-3000 Shown with Flat Attachment Shown with Cube Attachment For Customer Service, Call 1-800-835-0606 or Visit www.hixcorp.com CONTENTS Receiving & Installation ......................2-3 Operation ............................. 4 Setting Temperature & Time ......................5 Preference Settings ........................ -
Page 2: Receiving & Installation
RECEIVING & INSTALLATION SHIPPING OR RETURNS NOTE: Save all of your shipping/packing materials. ******DO NOT RISK COSTLY SHIPPING DAMAGE!****** ******SHIP ONLY IN ORIGINAL BOX.****** 1. Fasten machine to plywood shipping base with bolts provided. 2. Tie or tape handle securely to base. 3. - Page 3 RECEIVING & INSTALLATION CHANGING PLATEN ATTACHEMENTS 1. To switch the different attachments, just lift the attachment off, replace with other attachment. Adjust screw to change height. 2. Load paper cube tight against the back and non moving side. Tighten adjustment knob. Adjustment Rod...
-
Page 4: Operation
OPERATION 1. Turn on the machine by pushing the on/off switch. Startup/Splash screen is displayed as the controller boots up. NOTE: The current program number and the software revision of the control- ler are displayed at startup. (The default settings are program number P 7 for °F, P 8 for °C and software revision RV 1.0) Startup/Splash Screen After boot up, the home screen is displayed showing the current heat platen... -
Page 5: Setting Temperature & Time
SETTING TEMPERATURE & TIME ADJUST TEMPERATURE: TEMPERATURE ADJUSTMENT SCREEN UP ARROW TEMPERATURE READOUT/SETTING DOWN ARROW 1. Touch the temperature readout on the display. “UP” ▲ and “DOWN” ▼ arrows will appear on the right side of the display and the temperature value will start flashing and to indicate it is in set mode. -
Page 6: Preference Settings
PREFERENCE SETTINGS SETTINGS: 1. Press the “?” on the upper right corner of the display on the Home Menu Screen to access the settings menu. 2. Press the settings sub menu title to be adjusted. SETTINGS MENU SCREEN ADJUST SHUTDOWN TIMEOUT SETTING SET QUANTITY OF PRESETS DISPLAYED... -
Page 7: Machine Presets
MACHINE PRESETS PRESET QUANTITY Temperature presets can be stored in the memory for different trans- fer settings. By default two presets are displayed. This setting can be adjusted to display four presets. PRESET QUANTITY DISPLAYED PREFERENCE SCREEN TWO PRESETS DISPLAYED FOUR PRESETS TOGGLE BETWEEN DISPLAYED... - Page 8 MACHINE PRESETS STORING PRESETS: NOTE: The factory default settings for all presets is set to 200°F and 10 seconds. HOME MENU SCREEN PRESET LOCATIONS TEMPERATURE SETTING TIME SETTING 1. Set the desired temperature and/or cycle time using the temperature and time adjustment instructions in this document. 2.
-
Page 9: Cycle Count
CYCLE COUNT CYCLE COUNT The cycle count feature counts the number of cycles that the machine has undergone. A cycle is counted every time the countdown timer is activated by closing the press. NOTE: The cycle count will maintain the total count even if the power has been turned off. -
Page 10: Temperature & Time Modes
TEMPERATURE & TIME MODES TEMPERATURE MODE Temperature Mode controls which temperature scale is displayed on the controller home screen. F = Fahrenheit C = Celsius TEMPERATURE MODE PREFERENCE SCREEN UP ARROW TEMPERATURE SCALE PREFERENCE DOWN ARROW SAVE SETTINGS RETURN TO PREVIOUS SCREEN TO CHANGE THE SCALE: 1. -
Page 11: Platen Pressure
PLATEN PRESSURE 1. There is a pressure control knob located on the front stem, holding the lower platen. Set so that the heat head will lock down firmly, with your substrate in place. 2. Pressure is reduced by turning knob (with machine open) counter- clockwise and increased by turning it clockwise. -
Page 12: Transfer Application
TRANSFER APPLICATION When you fail to make a successful transfer you can wonder, “Is it the machine’s fault, or the transfer, wrong settings or what”? FIRST, THE BASICS: 1. Be sure to set the heat transfer machine to the transfer manufacturer’s recommended Temperature, Time and Pressure settings. -
Page 13: Repairs/Adjustments
REPAIRS/ADJUSTMENTS RELAY BYPASS WARNING: Before making repairs, be sure ON/OFF switch is OFF and machine is unplugged! ATTENTION: Eteindre la machine avant de faire des réparations. 1. Remove the back cover of the machine. WARNING: To prevent posible electrical shock, unplug the machine before removing cover to service. -
Page 14: Maintenance
REPAIRS/ADJUSTMENTS MICRO SWITCH ADJUSTMENT If countdown timer will not activate. WARNING: Before making repairs, turn temperature control knob to “OFF” and unplug machine! 1. Remove rear cover. 2. Using a screwdriver and a small wrench loosen micro switch mounting screws 3. -
Page 15: Troubleshooting
TROUBLESHOOTING *Customer Service Tech Sheets are available for this step. Visit www.hixcorp.com to print or call 620-231-8568 and we will send you one. Parts ordering is available on-line. Machine overheats Little or no heat Does heat light remain on constantly when overheating? Is power light on? Is heat light on? -
Page 16: Warranty
In the event of a defect, HIX, at its option, will repair, replace or substitute the defective item at no cost during this warranty period subject to the limitations of insurance and shipping costs stated below (excludes labor).
