1. Product description
This product is intended for HDMI to IP video streaming for home users. The device allows users to watch
Set-Top Box (STB) or other HDMI video equipment video streams on their smartphone, tablet, Android smart TV
or personal computer. The device allows video recording to the USB or local network drive for watching the
records later. It is also possible to access the device from outside your local network (e.g. using the smartphone
and mobile data connection) and watch live video streams and records remotely.
"TerraTV" Android App is designed specifically for this product for video playback. Third-party video players
are supported as well.
MHI512P is packed with an external power supply.
The device is intended for indoor usage only.
2. Safety instructions
The streamer is powered from the external power supply +12 V. This voltage is not dangerous to life.
Any repairs must be done by skilled personnel.
Do not plug the power supply of the streamer into the mains until all the cables have been connected
correctly.
The streamer shall not be exposed to dripping or splashing water.
Avoid placing streamer next to central heating components, near highly combustible materials and in areas of
high humidity.
If the streamer has been kept in cold conditions for a long time, keep it in a warm room no less than 2 hours
before use.
Do not place the streamer on unstable surfaces, where the unit may fall and resulting in possible damage.
Do not insert any objects into the ventilation openings.
The ventilation should not be impeded by covering the streamer with items, such as newspapers, cloths,
curtains.
This product complies with the relevant clauses of the European Directive 2002/96/EC. The unit must
be recycled or discarded according to applicable local and national regulations.
Equipment intended for indoor usage only.
This product is in accordance to following norms of EU: EMC norm EN50083-2, safety norm
EN IEC62368-1 and RoHS norm EN50581.
This product is in accordance with Custom Union Technical Regulations: "Electromagnetic
compatibility of technical equipment" CU TR 020/2011, "On safety of low-voltage equipment" CU TR
004/2011
This product is in accordance with safety standard AS/NZS 60065 and EMC standards of Australia.
Vers. 1.01
HDMI to IP streamer MHI512
Scan to download TerraTV App
from Google Play
EN
Advertisement
Related Manuals for Terra MHI512
Summary of Contents for Terra MHI512
- Page 1 HDMI to IP streamer MHI512 1. Product description This product is intended for HDMI to IP video streaming for home users. The device allows users to watch Set-Top Box (STB) or other HDMI video equipment video streams on their smartphone, tablet, Android smart TV or personal computer.
- Page 2 3. External view Rear view Front view Figure 1. External view of the streamer. 1 – DC IN – DC powering entry for 3.5/1.3 mm DC jack; 2 – Reset – device reset and restore defaults button (see description in section 6); 3 –...
- Page 3 Internet Explorer is not supported. 4.2 Requirements for video records storage • SSD or USB memory stick is recommended. HDD usage is not recommended; • If the USB drive consumes more than 2.5 W (500 mA) of power, it must be powered through an external power source;...
- Page 4 Figure 2. Language, country, region selection. Language selection affects the language of the control interface. Different browsers may have different languages used simultaneously. The language setting is saved in the WEB browser as a cookie. 5. Menu description On the top of every WEB configuration window there are 3 main icons. See detailed icons description below: System diagnostics information.
- Page 5 Figure 4. Input the media settings menu section. “HDMI Signal” - shows if HDMI video signal source is connected to the device or not. “Video resolution” – connected video signal source parameters such as video resolution and frame rate. 5.2.2 Output media settings Figure 5.
- Page 6 Figure 7. The playlist is available from the local network. Figure 7 shows the playlist URL for third-party players. This playlist file is accessible from the local network only. Click on the icon to copy the playlist URL and then open a video player and paste this URL. Figure 8.
- Page 7 Figure 10. Recording schedule. “One-time recording” - means a single recording at the exact time and specified duration. The start time can be selected up to 6 days in advance. Such schedule entry is shown in Figure 10 on the “Friday movie” record. If the “One-time recording”...
- Page 8 “External port“ is a port number used to access the device remotely or receive video streams. “Streaming port” is a port number used for video streaming. The external streaming port value should be equal to the local streaming port value. Otherwise “Terra TV” app or third-party video players may not work correctly.
- Page 9 When you click the “Update”, the device will try to enable / disable the selected ports on the network router. The status indicator icons will show the progress of the operation. Hovering over the status icon will display more status information. 5.5.3 HTTPS The user interface of the device can be accessed via the secure HTTPS protocol.
- Page 10 The “Download” button creates a logs.json file that can be used for troubleshooting and receiving help from Support. Messages will be exported in the English language regardless of the WEB interface language used. Figure 16. Logs messages 5.6.2 Change password The user who wants to change the password just select the “Change password”...
- Page 11 Figure 19. Entering a new user. “Admin” user has no restrictions. “User” is almost the same as “Admin”, but user management is disabled. “Guest” has read-only access which means no device settings can be changed. A user with administrator access rights can edit another user’s password or change the role. Click “Edit” and change the parameters.
- Page 12 If valid firmware files have been selected, the firmware version number will be displayed as shown in Figure 22. Click the “Upload” button to upload the file to your device. A confirmation message will appear on the screen asking you to reboot the device. Do not disconnect the power supply from the device during programming. The login window will appear on the screen as soon as the firmware update is completed.
- Page 13 Figure 25. Date and time settings. ”Local Time” shows the time of the device that it currently has, estimating possible DST offset. If the time in this field is not correct, make sure you select the correct country (see section 5.6.10). Date and Time Source has two options: NTP Server and Manual Input.
- Page 14 DLNA, HTTP, SRT Control port IEE802.3 10/100 Base T Current consumption without external load 12 ± 1 V 350 mA (MHI512) Current consumption with max. external 12 ± 1 V 800 mA (MHI512) load Supply voltage limit values, power 100-240 V~ 50/60 Hz 11 W max.
