DVB to IP streamer sti441C
1. Product description
DVB-T/T2/C to IP streamer (in the text - module) designed to broadcast in multicast on an IP network the services (TV
or Radio programs) issued from FTA or encrypted digital reception. The IP streams can be viewed using an IPTV set-top
box or a software video player. The streamer can descramble encrypted services by two conditional access (CA) modules.
Module is intended for indoor use only.
2. Characteristics
Input: 4 DVB multi-program transport streams (MPTS).
Output: up to 256 simultaneous, IP-encapsulated services (TV or Radio programs), with individual multicast addresses
and 4 MPTS streams.
• Information filtering of DVB tables.
• UDP & RTP transmission protocols.
• Web interface for configuration and setting.
• SAP & SDP protocols that facilitate automatic service selection on the user's STB and provide information to external
servers.
• PID filtering.
• PSI/SI parsing.
• Transparent ECM & EMM messaging.
• PAT, PMT and SDT table regeneration.
• Routing or blocking for CAT, EIT, TDT tables.
• Configurable QoS marking.
• Configurable Time To Live.
• TS file streaming from USB flash.
3. Safety instructions
Installation of the module must be done according to IEC60728-11 and national safety standards.
Any repairs must be made by skilled personnel.
Do not expose this module to moisture or splashing water and make sure no objects filled with liquids, such as vases,
are placed near or on the unit.
Avoid placing the module next to heat sources such as central heating components or in areas of high humidity.
Keep the converter away from naked flames.
If the module has been kept in cold conditions for a long time, bringing it into a warm environment may cause
condensation, so allow it to warm up for no less than 2 hours before plugging into the mains.
Ventilation should not be impeded by covering the module, such as newspapers, table-cloths, curtains etc.
Mount the module in a vertical position only. If installing in a 19" rack system additional forced air cooling fans may be
required (see table
"Technical
Always allow 10 cm of free space from the top, front and bottom of the unit to enable any heat to be dissipated.
This product complies with the relevant clauses of the European Directive 2002/96/EC. The unit must be recycled
or discarded according to applicable local and national regulations.
Equipment intended for indoor usage only.
This product is in accordance to the following norms of EU: EMC norm EN50083-2, safety norm EN IEC62368-1, RoHS norm EN50581.
This product is in accordance with Custom Union Technical Regulations: "Electromagnetic compatibility of technical
equipment" CU TR 020/2011, "On safety of low-voltage equipment" CU TR 004/2011.
This product is in accordance with safety standard AS/NZS 60065 and EMC standards of Australia.
Vers. 1.01
specifications" - operating temperature range).
1
EN
Manual in .pdf

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the sti441C and is the answer not in the manual?

Questions and answers

Related Manuals for Terra sti441C

Summary of Contents for Terra sti441C

  • Page 1 DVB to IP streamer sti441C 1. Product description DVB-T/T2/C to IP streamer (in the text - module) designed to broadcast in multicast on an IP network the services (TV or Radio programs) issued from FTA or encrypted digital reception. The IP streams can be viewed using an IPTV set-top box or a software video player.

  • Page 2: External View

    4. External view 1.2 CAM 2 1.1 CAM 1 sti441C sti441C ETHERNET RESET STATUS TERRA - - + + - - + + TS/IP TS/IP 1 - CA modules slots. Double PCMCIA sockets 1.1 - first module CAM 1 1.2 - second module CAM 2 2 - ◄...

  • Page 3: Installation Instructions

    5. Installation instructions Read the safety instructions first. All settings can be made using the web browser via the control Ethernet interface. Disconnect the power supply unit from the mains before making all connections of modules. Fasten the module on DIN RAIL or individual holder. Connect all necessary RF, powering and control cables.
  • Page 4 ■ Free space of installed amplifiers must be at least 10 cm. 10 cm ³ 10 cm ³ ■ Mounting bracket on DIN rail should be connected to main potential equalization bus. Mounting on a wall by screws Mounting on a bracket (ordering number 01960) Perpendicular to the wall Parallel to the wall Figure 2.

  • Page 5: Mounting On Din Rail

    Mounting on DIN rail Figure 3. Mounting to DIN rail sti441C sti441C sti441C ETHERNET ETHERNET ETHERNET RESET STATUS RESET STATUS RESET STATUS TERRA TERRA TERRA - - + + - - + + - - + + TS/IP TS/IP TS/IP Figure 5.
  • Page 6 7. Operating 7.1 Initial configuration All modules leave the factory with this control Ethernet interface IP address: 192.168.1.10. In order to avoid conflicts with other IP addresses, it is necessary to perform an initial configuration in local mode. Subsequently, it will be possible to access the modules via the local area network (LAN), either to re-programme it or to check is operating status.
  • Page 7 In the left of each configuration screen, you will see a main menu table Using it, you can switch between the different configuration menus. The “System menu” lines contain several submenu. Also, common elements for all screens are module title and login information strings .
  • Page 8 Four demodulators can be set up in this section. Each demodulator has a corresponding input table. The “Demod. 1-4” tables (see Figure 9) consist of following parameters: “Modulation standard” - used to select between the “Off”, “DVB-T”, “DVB-T2” and “DVB-C” modulation standards. “Off”...
  • Page 9 7.4 Transport Streams 1 Gbps Ethernet link on the TS/IP receiving end is supported only. 10/100 Mbps Ethernet link Note: on the receiving end is not supported. This is the home page (see Figure 10) for configuring device output streams. It consists of two tables: “Input services”...
  • Page 10 Scrambled services in the devices with CA module support are displayed with icon. After pressing on this icon additional submenu appears. This submenu allows to descramble service with selected CA module. When the service is selected for descrambling, the icon changes to Figure 11.
  • Page 11 After change of service parameter the icon appears. Press them to apply changes. In the last line on the “Output streams“ table a list box with all input services, grouped by the input source, is displayed. You can select service from this list box, set required IP address and port and press the “Append“ button to add new stream to output streams.
  • Page 12 7.5 USB This screen (see Figure 14) is used to select a USB flash drive partition, browse files and select file for streaming. In a “File” list box selected file name is displayed. You can select them from this list box. Files with TS extension are marked by icon and can be selected for streaming by mouse click.
  • Page 13 As an example, above “CA module menu” table shows the menu for a particular CAM. Click on the corresponding band to access different options. Click on the “Exit” button to return to previous menu. In the “Services descrambled by CAM” table are all services passed thru CA module. You can see bitrates and descrambling statuses of services.

  • Page 14: System Menu

    Once the different data values have been entered, click on “Update” to conclude the streaming settings. The “SAP/SDP settings” table is used to configure the announcement and service description SAP/SDP channel. “Enable” - check the box if you wish to transmit the service information by SAP/SDP protocol. “Sending period”...

  • Page 15: Change Password

    Just check the “Log filtering” checkboxes. Messages will be filtered automatically. The “Erase Logs” button will delete all logs from the system. The “Download” button creates a logs.json file that can be added as an attachment for help. Messages will be exported in English, regardless of language selection. Each entry has a log time when the event occurred.

  • Page 16: Firmware Upgrade

    The web interface will check the contents of the file as soon as you select the file and prevent the import of invalid content. If the contents of the file are correct, the screen will display the type of device and its description from which the file was exported.

  • Page 17: Restart The Device

    7.8.7 Restart the device The device can be restarted by selecting the “Restart the device” menu. A confirmation message, shown in Figure 23, will appear on the screen confirming that you really want to do this. Figure 23. Restart the device There are two types of restart –...

  • Page 18: Reset Button

    7.8.11 Date, time Figure 26 shows the two NTP servers as a date / time source. Figure 26. “Date, time” table ”Local Time” shows the time the device currently has, estimating possible DST offset. If the time on this line is not correct, make sure you select the correct country (see section 7.8.10).

  • Page 19: Technical Specifications

    Technical specifications Type sti441C Number of channels RF input DVB-T/T2/C frequency range 47-862 MHz AGC range/impedance 45-80 dBµV / 75 Ω DC output for preamplifier 12 V 100 mA IP output standard IEEE 802.3 1000 Base T* bit rate up to 200 Mbps...
