Summary of Contents for Big Dog MAVbase PR-W3PI
- Page 1 PR-W3PI...
- Page 2 INTRODUCTION Thank you for purchasing the PR-W3PI. Your new Power Distribution Unit (PDU) by Big Dog Power provides filtered AC power to your equipment. 3 individually controlled outlets provide up to 2380 Joules of surge Protection. Wi-Fi and Wired LAN connections give flexibility with placement and network connectivity. The built in Self-Healing functions of the PR-W3PI will keep your network connected equipment going by automatically rebooting and maintaining the equipment.
- Page 3 LED Indicators “G” or On: PDU is grounded properly Ground Off: PDU is not grounded “P” or Blue: Good / Protected and Clean power Power Red: Bad, No Protection “N” or Blinking Red: No Network Connection Network Solid Blue: Good Network Connection Rapid Blinking Red: PDU failure requires reboot or reset Outlet...
- Page 4 Wi-Fi Setup If using the Wi-Fi connection, follow these instructions Step 1) Plug in the included power cable to the PDU and to the AC mains outlet on the wall. a) Wait approximately 15-30 seconds, the power button will begin to flash. Step 2) Scan for Wi-Fi on your Wi-Fi enabled device with a web browser Step 3)
- Page 5 Do not use this product with extension cords, multioutlet power strips, multioutlet extenders, or UPS devices (other than a Big Dog Power UPS). The power capacity of these accessories can be overloaded by this product and may result in a risk of fire, or property damage.
- Page 6 Warning – No user-serviceable parts inside If the PDU is not operating properly, do not remove any part of the unit (cover, etc.) for repair. Unplug the unit and consult the warranty section of the owner’s manual. Caution – Exposure to heat Do not expose the PDU to direct sunlight or place it near wall heaters, space heaters, or in an enclosed space prone to temperature increase.
- Page 7 FCC Part15C+RSS247 To assure continued FCC compliance: 1. Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. 2. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
- Page 8 © Copyright 2022 Ethereal Home Theater, LLC. The information contained herein is subject to change without notice. This document contains proprietary information protected by copyright law. No part of this document may be photocopied or reproduced without prior written consent. metrahometheater.com metraav.com MAVBase.com...
