SINGLE SWING
USER AND ASSEMBLY MANUAL
Tips : It will take 2 people around 30 mins to assemble this product.
!
WARNINGS!
- Misuse and abuse of this product can result in injury.
- Read instructions before assembly or using this product. Retain Instructions.
- Always inspect product before use, checking for worn, defective or missing parts.
- Suitable for age 3-8yrs. Max user weight 45 kg.
- Do not stand on the swing.
- Assembly by adults.
- Adult supervision at all times.
- Only for outdoor and domestic use.
- Before you start assembly please check all parts are included, if any parts are missing or
you need advice, please call Customer Help Line: (+44) 0330 0904 420.
SW-001

Advertisement

loading
Need help?

Need help?

Do you have a question about the SW-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SPORTSPOWER SW-001

Summary of Contents for SPORTSPOWER SW-001

  • Page 1 - Adult supervision at all times. - Only for outdoor and domestic use. - Before you start assembly please check all parts are included, if any parts are missing or you need advice, please call Customer Help Line: (+44) 0330 0904 420. SW-001...
  • Page 2 Before you start... We suggest you spend some time reading this guide before follow - • ing the simple step-by-step assembly instructions. • Do not discard any of the packaging until you have checked that you have all parts and fittings listed. When discarding packaging take care and consideration for others and the environment.
  • Page 3 PART LIST TOP BAR LEFT TOP LEG RIGHT TOP LEG LOWER LEG CROSS BAR SWING SEAT ANCHOR PLASTIC CAP...
  • Page 4 10cm M8×102mm M6×42mm M6×50mm "U" BOLT BOLT BOLT...
  • Page 5 10cm SPRING WASHER SPRING WASHER ARC WASHER FLAT WASHER...
  • Page 6 10cm ALLEN KEY SPANNER...
  • Page 7 step 1 NOTE: ENSURE YOU ATTACH THE SEAT CONNECTOR TO THE U BOLT. x 4 x 4...
  • Page 8 step 2 #1 PLEASE INSERT LOWER LEG (4) BEFORE ATTACHING CROSS BAR (5) FIRST. #2 THEN INSERT THE PLASTIC CAP (8) INTO CROSS BAR (5). #3 THE CROSS BAR (5) NEED TO BE ATTACHED TO THE OUTSIDE OF THE SWING FRAME. x 4 x 4...
  • Page 9 step 3 x 4 x 4...
  • Page 10 step 4 Anchor the swing in the ground. 6-8CM...
  • Page 11 ASSEMBLY SEAT ADJUSTABLE GUIDE THE LENGTH OF THE ROPE IS ADJUSTABLE FOR THE HEIGHT OF THE CHILD THROUGH THE SEAT CONNECTOR. TO ADJUST, LOOSEN THE KNOT ON THE SEAT CONNECTOR, PULL ROPE THROUGH THE HOLES AND TIGHTEN AGAIN. MAKE SURE THAT THE KNOTS ARE TIGHT AND THAT BOTH ROPES ARE ADJUSTED SO THAT THE SEAT IS HORIZONTAL.
  • Page 12 • Check all parts of the product at regular intervals, especially the top beam, frame legs, ropes and ride supports.If you nd any problems do not allow children • NOT suitable for children under 36 months. Small parts to use the product until it is t for use. If these checks choking hazard.

  • Page 13: Product Warranty

    User’s Manual). (c) Defects, damages or accidents due to the malfunction, connection to or use of non-Sportspower or unauthorized parts. In such event, Sportspower reserves the right to cancel the Limited Warranty coverage immediately.
