Component Details
Item No.
Part Number
1
*Style Index
2
*Style Index
3
613-801
4
604-601
5
126-707
3/8 x 1 ½" Button Head Bolt
6
126-703
3/8 x 1" Button Head Bolt
7
126-701
3/8 x 1 ¼" Button Head Bolt
8
316-601
9
126-602
10
126-505BPK
11
516-400
*Note: Refer to the style index for part identification.
Version: ECSquare_v1
Accessible Square Table with Standard
Description
QTY
Bench Plank
3
Table Top
1
Bench Leg
8
Cross Brace
1
4
12
8
3/8 Washer
40
3/8" Nylon Lock Nut
12
7/32 Allen
1
LocTite
1
Total
96
www.sportsplayinc.com
Frame
4
Detail B
8
2
7
3
602-671 & 602-672
Detail A
5
8
3
Detail C
8
3
6
1
1
