Component Details
Item No.
Part Number
1
*Style Index
2
*Style Index
3
613-801
4
604-601
5
126-707
3/8 x 1 ½" Button Head Bolt
6
126-703
3/8 x 1" Button Head Bolt
7
126-701
3/8 x 1 ¼" Button Head Bolt
8
316-601
9
126-602
10
126-505BPK
516-400
11
*Note: Refer to the style index for part identification.
Version: ECSquare_v1
Square Table with Standard Frame
Description
QTY
Bench Plank
4
Table Top
1
Bench Leg
8
Cross Brace
1
4
16
8
3/8 Washer
40
3/8" Nylon Lock Nut
12
7/32 Allen
1
LocTite
1
Total
96
www.sportsplayinc.com
Detail A
4
Detail B
8
2
7
3
602-646
5
8
3
Detail C
1
8
3
6
1
Advertisement
Table of Contents
Related Manuals for SportsPlay 602-646
Summary of Contents for SportsPlay 602-646
- Page 1 602-646 Square Table with Standard Frame Component Details Detail A Item No. Part Number Description *Style Index Bench Plank *Style Index Table Top 613-801 Bench Leg 604-601 Cross Brace 126-707 3/8 x 1 ½” Button Head Bolt 126-703 3/8 x 1” Button Head Bolt 126-701 3/8 x 1 ¼”...
- Page 2 602-646 Square Table with Standard Frame Important NOTE: Do not completely tighten any bolts until the unit is completely assembled. Please keep a copy of these instructions in your files. There is important replacement part information in them that will assist Assembly Instructions you in the event a part is ever needed.
- Page 3 Please identify your style and it’s corresponding part number before you contact your distributor or the manufacturer for replacement parts. Currently, SportsPlay Equipment offers two style options for this unit. Rolled edge with perforated steel and rolled edge with expanded steel. 613-601ER To identify your product style you must first define the edge.
