- Page 1 Vehicle GPS Tracker (4G LTE+GSM+GPS+SMS) GT08L User Manual (Version 1.) Copyright © 2021 Shenzhen ANB Technology Co., Ltd. All rights reserved.
-
Page 2: Table Of Contents
Index Contents 1. Description............................3 2. Package Contents ........................... 3 3. Features and Specifications......................3 4. Knowledge before Usage........................ 4 4.1 Factory Default Setting......................4 4.2 Power Supply and consumption....................5 4.3 How to Insert Sim card......................5 5. Installation............................5 5.1 Wiring Diagram........................5 5.2 LED working status.......................6 6. -
Page 3: Description
1. Description GT08L is a IP67 Rated 4G LTE/GSM/GPS tracker for car, motorcycle, scooters and e-bikes. It's with superior receiver sensitivity, fast TTFF and 4G LTE design. And it can continuously report current position to backend server. It has a built-in acceleration sensor, which can detect the moving/static and driving behavior. -
Page 4: Knowledge Before Usage
Internal backup battery 120mAh/4.2V Data transmit 4G LTE/GSM/SMS Communication 1: Red for network LED indicator 2: Green for GPS 1: ACC detect Input 2: SOS detect 3: Reserved (high trigger) Immobilizer(cut engine) relay or buzzer Output One input AD Built-in accelerometer Accelerometer FIBOCOM L610 4G chip... -
Page 5: Power Supply And Consumption
4.2 Power Supply and consumption This device is expected to connect with a DC power source with range of 8-100V DC. Working current maximum 2A input. Device working current < 18mA @24V DC 4.3 How to Insert Sim card Before inserting the sim card, please make sure the sim card 4G and SMS and GPRS activated. The device will automatically turn on after inserting the SIM card. -
Page 6: Led Working Status
6.1 Device ID GT08L doesn’t need configure device ID. GT08L use 121 + the last eight digits of IMEI as ID. On the unit case side is with a bar code sticker. please use this code as device ID when you register device tracking platform. -
Page 7: Configure Data(4G/Gprs) Parameter
6.2 Configure data(4G/GPRS) Parameter SMS Setting Command: (ip,1,1,url,port,T) url: IP or domain name of the tracking server. port: port of the tracking server. T: data transmit mode. T=1 is using TCP mode. T=0 is using UDP mode. Default as 1. Example: (ip,1,1,198.11.175.123,9016,1) SMS query Command:... -
Page 8: Time Zone Localization Setting
6.5 Time zone Localization Setting GT08L can configure the timezone of TCP data and SMS data separately, but TCP data uses GMT time by default. SMS setting Command: (timezone,1,00:00,hh:mm) hh: mm is SMS data timezone hour and minute. Example: Setup time zone with 8. -
Page 9: Query Device Setting Status
6.10 Query google location link SMS command: *WHERE2# Device reply: ID:012151781737 http://maps.google.com/maps?hl=en&q=+22.59682,+113.84461 6.11 Recover factory setting By SMS command or GPRS command, GT08L can be initialized to be factory default setting status. SMS Command: (reset) 6.12 Remote reboot SMS command: (reboot,1) 6.13 Set overspeed alarm... -
Page 10: Setup Motion Sensitivity Threshold
Example: (acc,1,1,1) SMS query command: (acc,0) 6.16 OTA Operation GT08L allow user to do firmware upgrading via GPRS connection. Details operation command and procedure, please consult with your seller. Copyright © 2021 Shenzhen ANB Technology Co., Ltd. All rights reserved.
