Playcraft PSMG 5401 Manual

Junior 54” 2 in 1 pool table / hockey table

JUNIOR 54" 2 IN 1

POOL TABLE / HOCKEY TABLE

ITEM NO PSMG 5401

IMPORTANT NOTICE!

Please read through this instruction manual to familiarize yourself with all parts and

assembly steps.

Should you require product support , please contact us toll free at (888) 367-3095 or via

email at support@playcraft.com.

Table of Contents

Need help?

Do you have a question about the PSMG 5401 and is the answer not in the manual?

Page 1 JUNIOR 54” 2 IN 1 POOL TABLE / HOCKEY TABLE ITEM NO PSMG 5401 IMPORTANT NOTICE! Please read through this instruction manual to familiarize yourself with all parts and assembly steps. Should you require product support , please contact us toll free at (888) 367-3095 or via...
Page 2 Parts List 1/4'' Bolt 1/4" Washer 3/4'' Washer 3/4'' Hex Nut Pool Table 8 pieces 2 pieces 8 pieces 2 pieces 1 piece #10. 1-1/4" Flat Head 5/8" Screw Pedestal Support Puck Catcher Pedestal 2 pieces 2 pieces 27 pieces Screw - 6 pieces 2 pieces #15.
Page 3 Attach the air hockey table section (#27) to the pool table section ( #1) using screws ( #26). Please be sure to thread the air hockey plug through the sidewalls in the pool table section (#1) as shown in the illustration before securing with the screws ( #26) Pedestal assembly #9A/9B...
Page 4 Attaching the table locks #9A/9B Outside face...
Page 5 Assembling the base Attach the now completed rotating system to the now completed base. Place felt on the bottom of hockey striker after removing the backing from the adhesive.
Page 6 Release the table locks installed in step 3 to rotate the table function between air hockey and billiards. Be sure to use the table locks to secure the table before playing your selected game. 180 TURN Open Close Thank you for choosing Playcraft!
