Summary of Contents for Playcraft Fairfield Wheaton PTWHEBRI08
- Page 1 Wheaton Model: PTWHEBRI08 - Wheaton 8’, Briar...
- Page 2 page 1 Congratula�ons on selec�ng a Wheaton slate pool table - part of the Fairfield Collec�on by Playcra�. Please contact us ia email at support@playcra�.com should you require any assistance. Please carefully read all safety instruc�ons and direc�ons before proceeding Your table is designed for use indoors in a climate controled environment only.
-
Page 3: Parts List
page 2 Parts List - cabinet *images not to scale IMAGE DESCRIPTION SPECIFICATION UNIT TABLE LEG 724*200*200 ASSEMBLY CABINET POSITION LONG FRAME 1940*290*87 ASSEMBLY CABINET POSITION SHORT FRAME 830*290*87 ASSEMBLY CABINET POSITION SHORT BEAM 1022*100*40 ASSEMBLY CABINET POSITION LONG BEAM 784*80*40 ASSEMBLY CABINET... -
Page 4: Specification
page 3 Parts List - hardware *images not to scale IMAGE DESCRIPTION SPECIFICATION UNIT ø10*60 HEXAGON BOLT ASSEMBLY FOR CONNECTING THE LEG AND FRAME POSITION M10*30*2 FLAT WASHER ASSEMBLY FOR CONNECTING THE LEG AND FRAME POSITION 4.2*60 FLAT HEAD SCREW ASSEMBLY FOR CONNECTING THE CROSS BEAM AND FRAME POSITION... - Page 5 page 4 Step 1 NOTE: The tops of the legs and cabinet aprons must be at the same height Step 2 NOTE: The tops of the cross beam supports must be at the same height as the tops of the aprons and legs...
- Page 6 page 5 Step 3 NOTE: When inserting the slate adjusting bolts, the head of the bolt should be even with the top of the cross support or slightly below. It should not be higher than the top of the cross support Step 4 NOTE: When attaching the slate connector blocks, the top of the blocks should be the same height as...
- Page 7 page 6 Step 5 NOTE: Place the slate onto the frame and center carefully along the length and across the width. Adjust the slate leveling bolts or use shims to adjust the height of the slates so the joints are at the same height Step 6 NOTE: Attach the billiard cloth...
- Page 8 page 7 Step 7 NOTE: Cover the cushions with billiard cloth. Use care when attaching pockets and placing the aprons on the slate Step 8 Note: Align the side rails #2, #3, #5 and #6 ( H13 & H14 ) so they are in a straight line and at ninety degrees relative to the end rails before tightening the rail bolts...
-
Page 9: Customer Service
page 8 Complete Customer Service For ques�ons on assembly or for missing or damaged parts, please contact us via email at support@playcra�.com. Please visit our website at www.playcra�.com to see more industry leading Playcra� and Playcra� Sport game tables. Thank you for choosing Playcra�! Global Merchants, Inc.
