Please read through these assembly instructions carefully to ensure that you can assemble your new purchase
without stress. These detailed instructions will guide you on how to prepare and assemble your bedroom
DIFFICULTY
WE ADVISE YOU DO NOT USE POWERED DRILLS TO ASSEMBLE ANY BOLTS ON THIS

EQUIPMENT PROVIDED

Hardware Pack: containing – 4x (M6) 10mm button head bolts; 2x 38mm screws; 1x allen key
There are additional bolts and hardware that are pre-installed to your components as required.
*NOTE: The hardware pack may contain more items than required. Please contact our sales team if you have any
questions/concerns.
Bed Frame Parts:
Slat System: See the attached document "Amendment to instructions for all SilverLynx beds".
NOT PROVIDED: Flat Head Screwdriver
