  • Page 1 ÃÀÇ ÏËÈÒÀÑÛ GAS COOKER AE44 ÏËÈÒÀ ÃÀÇÎÂÀß ÒÎÂÀÐ ÑÅÐÒÈÔÈÖÈÐÎÂÀÍ...
  • Page 2: Important Precautions

    OPERATING AND MAINTENANCE INSTRUCTIONS Dear customer! Thank you for purchasing the appliance from our new range of gas cookers. The following information will help you understand the features of the appliance and use it safely. We hope the appliance will serve you successfully for a long period of time.
  • Page 3 does not apply to faults resulting from the incorrect use of the appliance. It is recommended to have the appliance checked by the authorized service personnel every two years. Such professional maintenance will extend the useful life of the appliance. If you should smell gas, immediately shut the gas pipe cock and cut the gas supply.
  • Page 4 Manufacturer does not recommend using any additional accessories, instance flame extinguishing protectors, or efficiency increase gadgets. Do not move the cooker by holding the hob. The manufacturer declines responsibility for any damage caused by violating the instructions and recommendations set herewith. Do not use pressure vapor cleaner for cleaning the appliance.
  • Page 5: Control Panel

    Different models are equipped with different accessories. Any additional accessories (grids, baking trays, grill pans, adjustable feet) are available in authorized shops or our service outlets. CONTROL PANEL 1 - Left front burner control knob 2 - Left rear burner control knob 3 - Right rear burner control knob 4 - Right front burner control knob 5 - Oven control knob...
  • Page 6: Operation

    The manufacturer declines responsibility for any injuries to persons or damages to the appliance resulting from improper usage of the appliance. OPERATION CAUTION: The appliance is not a toy and may be operated only adult persons accordance with these instructions. Do not leave small children without supervision in a room where the appliance is installed.
  • Page 7 LIGHTING THE BURNERS WITH HIGH VOLTAGE GAS IGNITION KNOB Press the appropriate burner control knob slightly towards the appliance and turn it anti-clockwise to the use another hand and press the gas ignition knob on the control panel and keep it pressed until it ignites the flame. SHUTTING THE HOB BURNERS OFF whether the flame is extinct COOKING...
  • Page 8 CAUTION: Before opening the hob lid any spilled liquid must be removed from the lid surface. Do not close the hob lid if the burners are still hot! INSTRUCTIONS FOR USING THE GLASS ATTENTION! Glass lid may crack if it is heated. Before closing the lid switch off all burners.
  • Page 9: Oven Operation

    OVEN OPERATION 1 - OFF 2 - MAXIMUM POWER 3 - MINIMUM POWER (SAVING) The gas supply to the oven burner is controlled by a tap protected with a thermoelectric flame sensor. The power input of the oven burner as well as the temperature of the oven space can be controlled by IGNITION OF THE OVEN BURNER Open the oven door.
  • Page 10 SHUTTING THE HOB BURNERS OFF whether the flame is extinct BAKING / ROASTING FOOD Preheat the oven for a period of 10 - 15 min before putting yeast dough to bake. After preheating food oven. Baking/roasting time at MAXIMUM POWER depends on the type and mass of food.
  • Page 11: Minute Minder

    INSERTING OF GRID IN THE OVEN MINUTE MINDER Awaiting cooking time (oven or hob burners) is possible to set on mechanical minute minder in range of 0 115 minute. Required time to be set by turning of the knob. First turn the knob to the right to max.
  • Page 12: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Before attempting any cleaning or maintenance set all position and let the cooker cool down completely. CLEANING THE CABINET Clean the exterior with a damp sponge and some detergent. Fat stains can be removed with warm water and special detergent for enamel.
  • Page 13: Bulb Replacement

    OVEN Clean the oven walls with a damp sponge and detergent. To clean stubborn stains burned into the oven wall use a special detergent for enamel. After cleaning carefully wipe the oven dry. Clean the oven only when it is completely cold. Never use abrasive agents, because they will scratch enameled surface.
  • Page 14 OVEN Procedure for cleaning of internal glass door.
  • Page 15: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS In case of any defects to the appliance during the warranty period, do not attempt to repair it by yourself. Make a claim to the nearest authorized dealer or place of purchase, and make sure you can produce the endorsed Certificate of Warranty.
  • Page 16 INSTALLATION INSTRUCTIONS AND SETTINGS The appliance must be installed in accordance with valid local regulations, and shall be placed only in well vented spaces. IMPORTANT PRECAUTION: Any movement of the appliance from the existing installation requires shutting supply disconnecting the appliance from electric mains power. After installation the qualified personnel should perform the following: Leakage test on gas couplings, and correct electric...
  • Page 17 The appliance is designed for installation in the line of kitchen cabinets. The cooker can be located in the standard kitchen with a minimum space of 20 m If the kitchen is smaller (but not less than 15 m as a minimum) it is necessary to provide a hood.
  • Page 18: Connection To Gas Supply

    CONNECTION TO GAS SUPPLY GAS SUPPLY The appliance may be connected to gas supply by only by the authorized personnel. Connection must comply with the local standards and requirements. The gas supply pipe must be fitted with the accessible gas shut- off cock, located before the coupling with the cooker.
  • Page 19 1 - Connection ending 2 - Knee 3 - Connection hose (connection from the right) 4 - Connection hose (connection from the left) 5 - Fixing clamp 6 - Back cover of the cooker IMPORTANT PRECAUTION: In case of left side connection (seen from the front) the hose must be connected by means of a clamp fixed in the back cover opening.
  • Page 20 HOB BURNER SETTINGS MINIMUM OUTPUT ADJUSTMENT Before starting adjustments disconnect appliance from the mains power supply. Adjustments must be carried out with the tap at the "SAVING" position. The minimum gas output is correctly adjusted when the inner cone of the flame arrives at the height of 3 to 4mm.
  • Page 21 ADJUSTMENT OF OVEN BURNER MINIMUM POWER On completion of this operation, proceed as follows: Remove the oven bottom. Oven control knob Lift off the oven control knob. For propane/butane fully tighten screw G and for natural gas Oven temperature selector Disconnect the cooker from the mains power supply.
  • Page 22: Conversion To Another Type Of Gas

    increases the height. The adjustment is correct when the body of the flame is about 3 to 4 mm high. Replace the knob and set it to the switch off position, then replace the oven base. If the flame sensor does not operate properly, check its position according to fig.
  • Page 23: Leveling The Appliance

    CONNECTION TO THE MAINS POWER The appliance is fitted with power cord plug for connection to the mains. Power socket to which the appliance is connected must be accessible at all times. Faulty power cord must be immediately replaced with a new one.
  • Page 24 NOTICE The manufacturer reserves the right to make minor changes in these instructions for use resulting from technological changes which have no impact on the functioning of the appliance. Burner Small Medium Rapid Oven Natural gas G20 13 mbar / G 20 G 20 Nozzle diameter /...
  • Page 25 ACCESSORIES FOR ORDERING Cover - glass - white SAP 254207 Cover - glass - brown SAP 254222 Cover lacquered - white SAP 254190 Cover lacquered - brown SAP 254204 SERIAL NUMBER X XX X XXXX X XX X XXXX X XX X XXXX Year of production Week of the year Purpose of usage of appliance...
  • Page 26 TECHNICAL DATA GAS COOKER PS 103 MW PS 113 MI PS 113 MBR PS 113 MW PS 111 MW Dimensions: height / width / depth 850 / 500 / 605 (mm) Package dimensions: height/ width / depth 950 / 570 / 716 (mm) Burner input power 1,00...
  • Page 27 SAP 431817 PS - 151C / PS 103 MW, 152C / PS 111 MW, PS 113 MW, PS 113 MBR, PS 113 MI EN RU BY KK / 2013 02 09...
